vacuum pump Pulleys V-BELT CRANKSHAFT PULLEY • Ideal for driving alternators and/or vacuum pumps at optimum speed • Fits any 1" dia. crank-driven mandrel with 1⁄8" x 1⁄8" keyway • CNC machined from billet aluminum with hard-coat anodized finish • May be used with Moroso Vacuum Pumps Nos. 22640, 22641, 22642, 22644, 22840, 22842, 22843 and Vacuum Pump Pulley No. 64885 Part # 23520 23523
Description 2.5" V-Belt Crankshaft Pulley 4" V-Belt Crankshaft Pulley
No. 23523
No. 23520
• Fits Moroso Racing Vacuum Pumps or similar "smog" pumps that use OE-style, 3-bolt mounting pattern • Precision machined from the highest grade aircraft aluminum and hard-coat anodized for extended service life • Deep V-groove ensures belt retention under all racing conditions • Machined with six holes to reduce weight • 5" diameter pulley uses stock (3-bolt) mounting pattern with 1.16" bolt circle • Use with Moroso Vacuum Pump Nos. 22640, 22641, 22642, 22644, 22840, 22842 and 22843 Part # 64885
No. 64885 Drive Kits on pgs. 108-109
Description Vacuum Pump V-Belt Pulley
Vacuum Pump Pulley, Offset V-Belt • Allows Moroso Vacuum Pumps to be installed in cars with minimal drive mandrel space • Hard coat anodized • Offset 7⁄8", 5" diameter pulley uses stock (3-bolt) mounting pattern with 1.16" bolt circle • Use with Moroso Vacuum Pump Nos. 22640, 22641, 22642, 22644, 22840, 22842 and 22843 part #
Description
64887
Vacuum Pump Pulley, Offset
VACUUM PUMPS & ACCESSORIES
VACUUM PUMP V-BELT PULLEY
No. 64887
VACUUM PUMP PULLEY Gilmer Type, 28 Tooth • Fits Moroso Racing Vacuum Pumps or similar "smog" pumps that use OE-style, 3-bolt mounting pattern; accepts standard gilmer belts with 3⁄4" width or less • Precision machined from aircraft-quality aluminum with hard-coat anodized finish for extended service life and features direct, bolt-on installation • Use with Moroso 3- or 4-Vane Racing Vacuum Pump Nos. 22640, 22641, 22642, 22643, 22644, 22840, 22842, 22843 and interchangeable drive components Part # 64886
Description Vacuum Pump Pulley, Gilmer Type, 28 Tooth
Part # 97172
available options Crankshaft Pulley
No. 64886
VACUUM PUMP PULLEY Gilmer Type, 36 Tooth • Fits Moroso Racing Vacuum Pumps or similar "smog" pumps that use OE-style, 3-bolt mounting pattern; accepts standard Gilmer belts with 1⁄2" width or less • Precision machined from aircraft-quality aluminum and features direct, bolt-on installation • Use with Moroso 3- or 4-Vane Vacuum Pump Nos. 22640, 22641, 22642, 22643, 22644, 22840, 22842 and interchangeable drive components Part # 64888
Description Vacuum Pump Pulley, Gilmer Type, 36 Tooth
Part # 97172
available options Crankshaft Pulley
It’s Your Passion For Racing That Drives Us!
No. 64888
137
