THE ULTIMATE CLUB SYSTEM
KV2 SL SERIES SLIMLINE WIDE DISPERSION SPEAKER SYSTEM
SL412
GTD | 330II www.gtd-china.com
Slim and discreetly profiled the new SL Series incorporates KV2 Audio’s VHD Active Driven philosophy
GTD has released the new 330II moving head. Features include an Osram Sirius HRI 330W integrative lamp source; a 6,700K colour temperature; a 1,500 hour lifespan and a parallel beam angle of 0º to 3º. With its integrated aspheric optics, the user can very easily switch between the beam effect and spot effect when operating the luminaire. It offers a two prisms system, one eight-facet prism with one 16-facet composite-prism and bi-directional rotation in variable speed. The HRI also encompasses 16+1 fixed gobos, 12 rotating gobos, 14 dichroic colour filters, a pan of 540° / 630° and a tilt of 270°. It includes high-precise optical lens, linear adjustment focus, and independent frost. Also three-phase motors with moving control, which are fast moving with very low noise and an LCD control panel. There are 20 / 18 / 15 control channels, DMX 512 wireless optional, smart cooling and energy saving systems.
JBL | VTX V20 / S25 www.jblpro.com
SL2.15
The VTX V20 dual 10-inch line array loudspeaker and VTX S25 cardioid-arrayable dual 15-inch subwoofer. Both offer sonic clarity, high power density and precise coverage in compact form factors, providing rental sound companies, event sound designers and system integrators even more flexibility. The VTX V20 features a three-way system design with proprietary D2 dual diaphragm dual voice coil compression driver and differential drive low frequency transducer technology along with patent-pending ultra-linear motor technology employed for midrange components. The VTX V20 has high power density with each line array element featuring two 2261H 10-inch differential drive woofers, four 2164H 4-inch ultra-linear mid-range transducers and three D2415K dual drivers.
FULL & WIDE SOUND EXACTLY WHERE IT’S REQUIRED
KLING & FREITAG | GRAVIS 8 / 15 www.kling-freitag.biz The Gravis 8 and Gravis 15 complement the full-range speaker Gravis 12+. Based on the existing housing design, the 8-inch / 1-inch and 15-inch / 1.4-inch systems significantly extend the range of application. The Gravis 8 is designed for near-field sonication, and also for use as front-fill, side-fill and delay speakers. With a maximum sound pressure of 129dB, the Gravis 8 is clearly tuned for maximum performance. The Gravis 15 achieves, additional to the extended low frequency range, up to 5dB more SPL than a Gravis 12+. In the crossover frequency, the bundling of both sound sources is largely identical, which has a positive effect on the enforcement of the system in the short and medium throw distances. All housing of the Gravis series has two monitor angles of 35° and 55°.
Just 300mm deep, the SL Series can be installed against a wall or in it...dramatically reducing the venue floorspace required.
The new KV2 SL412 and SL2.15 speakers incorporate an eye-catching, slim and stylish cabinet design. Using KV2’s VHD technology, the SL412 loudspeaker utilises 4 x 12” low mid-range components with a single 8” mid-range and 3” large format NPVD compression driver. The cabinet’s configuration keeps low mid frequencies in a controlled pattern, greatly reducing problem room resonances. Cabinets can be designed and supplied with custom colors, grill templates and logos, offering a flexible and true designer-integrated product. The system is driven by proprietary KV2 amplification. The KV2 SL3000 powers a pair of SL412s and the VHD3200 which can drive up to four SL2.15 subs. SL Series - The Ultimate Club System
Maximum SPL: 137dB ______________________________________ Freq Resp +/- 3dB : SL2.15 40Hz - 500Hz, SL412 70Hz- 22kHz ______________________________________ Dispersion: H110° x V40° ______________________________________ Power: VHD3200 - 1600 Watts x2 ______________________________________ Power: SL3000 - Low 1000W x2, Mid 200W x2, High 100W x2 ______________________________________ Crossover Points: SL2.15 - 70Hz, SL412 - 400Hz & 2.5kHz ______________________________________
SL412 - H670mm (26.38”) W1080mm (42.52”) D300mm (11.81”) ______________________________________ Weight: SL412 - 60kg (132.28lbs)
Need more info? Want to locate your nearest KV2 Professional? uuWWW.KV2AUDIO.COM
