120075 Dual Keyway
Poles
3
Features and Benefits • Dual keyway connector with ½"-20 UNC coupler • Screw terminal connection accepts up to 18 AWG conductors • Easy field installation of quick-disconnect design • For use with all standard dual keyway ½"-20 UNF receptacles and cordsets
Mechanical Connector Face: Nylon 6/6 Molded Body: Nylon 6/6 Contact: Gold plated Copper alloy Coupling Nut: Nickel plated Brass Grommet: Nitrile rubber Maximum Conductor Size: 18 AWG
Electrical Voltage: 250V AC/DC Current: 3P—4.0A
Environmental Protection: IP67
Male
Female
Old Part No. 7A3006-31 7A3007-31
Order No. 120075-0017 120075-0019
Old Part No. 7A3000-31 7A3001-31
Order No. 120075-0014 120075-0016
7A3006-32
120075-0018
7A3000-32
120075-0015
Brad® Micro-Change® (M12) Ultra-Lock® Sealed Distribution Box 120119/130007/130008
Features and Benefits • Available in a variety of formats for backward compatibility with different connector styles • Accepts Ultra-Lock and threaded M12 cordsets Electrical Voltage (IEC 60 664-1): 1 0-30V DC Insulation Resistance (IEC 60 512-2): >109 ohms Rated Current T Amb. 40C (IEC 60 512-3): 2 A per I/O Current: 12.0A Contact Resistance (IEC 60 512-2): <5 milliohms
Single I/O Per Port with/Integral Mini-Change Connector Old Part No. BKY401P-FBB BKY601P-FBB BKY801P-FBB
Order No. 120119-0002 120119-0010 120119-0017
Description 18/3 22/8 PVC MI 18/3 22/8
www.molex.com/link/ultralock.html
Straight 90 degree
With PG 7 Cable Fitting (0.13 - 0.26" O.D. [3.3-6.6mm] cable)
Straight
With PG 9 Cable Fitting (0.16 - 0.32" O.D. [4.1-8.1mm] cable)
Mechanical Body: PBT Contact Carrier: PBT Shell Material: Nickel over Brass Contact: Phosphor Bronze Contact Plating: Gold over Nickel Cable Jacket: PUR O-Ring: Viton Environmental Pollution Degree (IEC 60 664-1): 3 Protection: IP67/69K
Old Part No. BKY403P-FBB BKY603P-FBB BKY803P-FBB
Order No. 120119-0005 120119-0013 120119-0020
Description 4-Port, 5-Pole/ 5 wire-dual 1/0 per port 6-Port, 5-Pole/ 5 wire-dual 1/0 per port 8-Port, 5-Pole/ 5 wire-dual 1/0 per port
Suggested home-run cable assembly for above junction boxes
Mini-Change® 90° Female Single-Ended Home Run Cable Order No. 130008-0279 130008-0282
Description
Double I/O Per Port with/Integral Mini-Change Connector
Description 4-Port, 5-Pole/ 4 wire-single 1/0 per port 6-Port, 5-Pole/ 4 wire-single 1/0 per port 8-Port, 5-Pole/ 4 wire-single 1/0 per port
Suggested home-run cable assembly for above junction boxes Old Part No. 302101A04M050 302101A04M100
Orientation
Industrial Products
Brad® Micro-Change® (½"-20 UNF) Field Attachables
Mini-Change Female Length (m) 5.0 10.0
Old Part No. 208000A04M050 208000A04M100 301000A04M050 301000A04M100 301001A04M050 301001A04M100
Order No. 130007-0176 130007-0177 130008-0073 130008-0075 130008-0489 130008-0112
Description MC 8P FP 5M 8 PVC MICRO MPIS MC 8P FP 10M 8 PVC MICRO MPIS MC 10P FP 5M PVC HOME RUN MC 10P FP 10M PVC HOME RUN MC 10P FP 90D 5M PVC HOME RUN MC 10P FP 90D 10M 22/10 PVC
Length (m) 5.0 10.0 5.0 10.0 5.0 10.0
MX10
S-37
