700-1700-1800 SERIES 700-1700-1800 SERIES
TEST EQUIPMENT 1200 SERIES
F-R-Ls 1000/1100 SERIES
PRESSURE GAGES 900 SERIES
DRIVEWAY SIGNALS 800 SERIES
AIR COUPLERS & PLUGS 700/1700/1800 SERIES
1000/1100
82
TOOL & COMPRESSOR OILS, MINI F-R-Ls, FILTERS, REGULATORS, LUBRICATORS, COMPRESSOR ACCESSORIES
SERIES
ELECTRONIC COMPRESSOR TANK DRAINS
1139-1 • 1139-2
• Attaches to air compressors to automatically drain water from tanks to deliver dry air to air tools and pneumatic equipment • Two 2-way direct-acting valves with manual test switch • Separate adjustments for interval and duration • Includes Y-strainer to trap large debris and sludge
1139-1 1139-2 1139-3
Part Number NPT Max Working Pressure Manual Override Operating Temps Power Cord
1139-1 1139-2 1/4” 1/2” 230 PSI YES 40°F to 140°F 6.5 Feet
Part Number NPT Max Working Pressure Manual Override Operating Temps Power Cord
1139-3 1/4” 200 PSI YES 40°F to 140°F 6 Feet
Adjustable cycle time: 0.5-4.5 minutes Adjustable drain time: 0.5-10 seconds
AUTOMATIC CONDENSATE DRAINS
1180-1 • 1180-2
• Continuously drains accumulated water and oil from drain lines, receiver tanks, condensate drop-legs and filters • Equipped with top-threaded port to receive drop-leg air lines • Protective stainless steel screen with umbrella baffle Length: 6 1/2” x width: 2 3/4” Weight: 1 lb Boxed Part No.
1180-1 1180-2
1180-1 1180-2
Per Retail Part No. Card s-1180-2
Operating Temp
Drain Type
1/4” 1/2”
Metal Bowl
175 PSI
40°F to 140°F
Automatic Float
• Muffler -filters use a porous sintered bronze, bonded to a copper plated steel pipe threaded fitting • 40 micron exhaust mufflers diffuse air and muffle noise from exhaust ports of air tools, cylinders and valves to an acceptable OSHA noise requirements • Maximum operating pressure: 150 PSI • Maximum air flow: 20 SCFM @ 100 PSI • Operating temperature: 40°F to 300°F Boxed Pkg Part No.
Bulk Pkg Part No.
1086-2 1086-4 1086-6 1086-8
1086-2BK 1086-4BK 1086-6BK 1086-8BK
s-1163-14 • s-1163-18 • s-1163-19 s-1163-20 • s-1163-21 s-1163-38 • s-1163-50 Plastic Silencers Part # s-1086-14 s-1086-38 s-1086-50
Max Air Pressure
PNEUMATIC EXHAUST MUFFLERS
1086-2 • 1086-4 1086-6 • 1086-8
1086-2 1086-4 1086-6 1086-8
1
Bowl Type
NPT
Port Size 1/4” 3/8” 1/2”
Retail Pkg Per Part No. Card s-1086-2 s-1086-4 s-1086-6
1 1 1
NPT
Length
Hex
1/8” 1/4” 3/8” 1/2”
1 1/8” 1 3/8” 1 1/2” 1 7/8”
7/16”
Weight (lbs)
9/16” 7/8”
SILENCERS • For use on exhaust ports on pneumatic valves and tools • Quick and inexpensive way to reduce work area noise • Features a 50-mesh self-cleaning, stainless steel screen Aluminum Silencers Part # Port Size s-1086-18 1/8” s-1086-19 1/4” s-1086-20 3/8” s-1086-21 1/2”
0.02 0.04 0.05 0.10
