Blind Riveters, Rivet-Nut Tools & Hydraulic Pumps Michigan Pneumatic HcS Series pumps are built to last. Constructed of high quality, industrial grade materials, these pumps can be depended upon for high production assembly work. Heavy steel box with removable front panel for quick inspection. Convenient features include externally adjustable air pressure, top mounted oil filler cap, flush mounted air and hydraulic pressure gauges, and sight glass to monitor oil level. The spring loaded handles allow for easy packing and transportation.
The MPT HcS Series high-volume hydraulic pumps are designed for accurate, repeatable fastener installations once oil pressure and air pressure have been regulated. These versatile pumps can easily be converted to overhead, suspended pumps for trolley-mounted moving assembly line applications. Other special modifications can be made at additional costs.
Michigan Pneumatic
Model MP-HcS-1000HD
Hydraulic Riveter Pump Designed to replace the Chicago Pneumatic Model CP-0805ARDR power rigs. Considerably quieter and faster than any competitive product. Powers all CP pneudraulic, riveting and broaching tools such as the CP-503, 505, 505A, 507, 507A and 509A. Comes equipped with an 8 ft. hose and an overhose protector. Longer length hoses available. Riveter and yoke not included.
Length ...................................... 18-1/4" Width ........................................ 12-1/4" Height ....................................... 22-1/4" Weight ........................................95 lbs.
Michigan Pneumatic
MP-7403-ST
MP-7403-ST (only): 2020-05 2020-06 2020-04
Jaw Set Jaw Pusher Jaw Case
MP-7503-ST (only): 3057-62 3057-08A 3057-061A
Jaw Set Jaw Pusher Jaw Case
Pressure ..................................7000 psi volume ........................ 100 cu. in./min. Rec’d Hose Size ............................3/8" Air Inlet Thread ..............................1/2"
Model MP-7403-ST Model MP-7503-ST
Pneumatic/Hydraulic Riveters Rugged tools suitable for setting steel rivets. Lightweight design for pulling most size rivets. Air relief prevents overloading. The most practical and versatile rivet tools in the industry. Model MP-7403-ST includes nosepieces for 3/32", 1/8", 5/32" and 3/16" rivets. Model MP-7503-ST includes nosepieces for 3/32", 1/8", 5/32", 3/16", 7/32" and 1/4" rivets.
Model Capacity Height Weight Rec’d Hose Size Air Inlet Thread Avg. Air Consumption
PoP®
MP-7403-ST 3/16" Steel 10" 3.25 lbs. 1/4" 1/4" 3.5 cfm
MP-7503-ST 1/4" Steel 13" 4.625 lbs. 3/8" 1/4" 4.5 cfm
Model PNT800L-Pc-T Model PNT1000L-Pc-T
POP NUT™ Tools Lightweight tools designed for installing POP NUT™ blind rivet nuts and other blind threaded inserts utilizing the setting force. Controlling the setting force eliminates application and nut damage due to “double stroking.” Available with unified or metric threaded mandrel. Sold with one nose assembly of your choice. Please specify.
PNT1000L-Pc-T
PNT800L-Pc-T 88
Model Thread Size Height Weight Rec’d Hose Size Air Inlet Thread
PNT800L-PC-T 8-32 to 3/8"-16 10.4" 3.99 lbs. 1/4" 1/4"
PNT1000L-PC-T 1/4"-20 to 1/2"-13 11.6" 6.11 lbs. 1/4" 1/4"
