14.11 Ermeto Test Nipples and Test Hoses
14.11 Test nipples and test hoses Cone Coupling M16
Manometer direct adapter
MAVMD-MA3 Part No.
MAVMD1/4MA3 MAVMD1/2MA3
VKA 3
Female thread BSPP
Female thread Working Metric pressure
1/4 1/2
M16x2 M16x2
630 630
Manometer direct adapter
EMA 3-R Part No.
Male thread BSPP
Working pressure
EMA3/1/8ED
1/8
630
EMA3/1/4ED
1/4
630
EMA3/3/8ED
3/8
630
EMA3/1/2ED
1/2
630
Metric with coupling M16
EMA 3-M Part No.
EMA3/10X1ED EMA3/12X1.5ED EMA3/14X1.5ED EMA3/16X1.5ED EMA3/18X1.5ED
Pipe
DIN Series
Working pressure
VKA3/06LA3C VKA3/08LA3C VKA3/10LA3C VKA3/12LA3C
6 8 10 12
L L L L
315 315 315 315
VKA3/15LA3C VKA3/18LA3C VKA3/22LA3C VKA3/28SA3C
15 18 22 28
L L L L
315 315 160 160
VKA3/42LA3C VKA3/06SA3C VKA3/08SA3C VKA3/10SA3C
42 6 8 10
L S S S
160 630 630 630
VKA3/12SA3C VKA3/16SA3C VKA3/20SA3C VKA3/25SA3C
12 16 20 25
S S S S
630 400 400 400
VKA3/30SA3C
30
S
400
Manometer Coupling M16
Male thread Metric
M M M M M
Part No.
SMA3
Working pressure
10x1 12x1,5 14x1,5 16x1,5 18x1,5
630 630 630 630 630
Part No.
Female Thread BSPP
Working Pressure
MAV1/4MA3 MAV1/2MA3
1/4 1/2
630 630
Hose with Coupling M16
Ermeto M16
GMA 3
214
SMA3
Part No.
Pipe O.D. DIN mm Series
GMA3/06L GMA3/08L GMA3/10L GMA3/12L GMA3/15L GMA3/18L GMA3/22L GMA3/08S GMA3/10S GMA3/12S GMA3/16S GMA3/20S GMA3/25S
6 8 10 12 15 18 22 8 10 12 16 20 25
L L L L L L L S S S S S S
Mento Hoses and Couplings Catalogue
Working pressure
315 315 315 315 315 160 160 630 630 630 400 400 400
Part No.
Length mm
Working Pressure
SMA3-200X SMA3-300X SMA3-400X SMA3-630X
200 300 400 630
630 630 630 630
SMA3-800X SMA3-1000X SMA3-1500X SMA3-2000X
800 1000 1500 2000
630 630 630 630
SMA3-2500X SMA3-3200X SMA3-4000X
2500 3200 4000
630 630 630
