FEATURED FUNCTIONS

The required functions are the performing hall, the concert hall, the outdoor amphitheatre, and movie cinemas.

Considering the nature of these functions, they all require long-span structures with an unobstructed line of sight from the seats to the stage, or screen. Separating these functions into their own building is an ideal solution for the project layout.

Roof Plan

DUAL-LAYER WALKWAY

A dual-layer walkway plays a key role in this complex since it serves various types of users. The upper level serves as a plaza for public activities and as the main circulation between functions. The lower path is air-conditioned and features restaurants and food kiosks for the audience. It is also used as a main circulation when it rains.

PROJECT’S SECTIONS

As each building has its own orientation, the custom section cut is made to illustrate the vertical spatial relationship in one drawing. The water feature is also drawn to the underground through the wall outside the full-height glass panel in the middle. This also provides natural light for the underground walkway.

The outdoor amphitheatre in the middle is designed for outdoor events. The only access is through the lower walkway. This allows some events to use the ticketing scheme to control the number of audiences and profit from the event as well.

The hall designs are massive as they need to support

- 1000 seats for the Concert Hall

- 1700 seats for the Grand Theatre

- 4 standard-size cinemas
