PRODUCT RANGE 2023

The power of style

The world is full of examples of power. And of style. Ferruccio Lamborghini demonstrated that there can only be strength in unity, in life as in work.

In 1948, Lamborghini used military surplus material purchased from the American armed forces to create a tractor that would go down in history - a machine that met the needs for agriculture at the time with Italian flair, which matched solid engineering with stylish looks. It was the dawn of Lamborghini Trattori.

With time, research and passion, the brand became synonymous with innovation in the production of agricultural machinery. The brand became world-renowned for imbuing an ingenious blend of grit and technology in agile, robust and effective tractors of extraordinary class. harmonious lines and livery featuring the colours of our spirit: black and white.

The power of style, by Lamborghini.

2
3 Contents
R VRT
R
Spire Trend Spire VRT Crono Spire Strike Spire F Trend Spire F VRT Spire F Spire F Target Spire S/V Spire S/V Target Sprint VINEYARDS, ORCHARDS, COMPACT TRACTORS FRONT LOADER SDF SMART FARMING SOLUTIONS page 4 page 14 page 22 page 23 Spire S/V VRT OPEN FIELD
Spark
Spark
Powershift/RVshift
4 Spark R VRT Technical data SPARK R VRT 115 R VRT 125 R VRT 135 R VRT Engine FARMotion 45 Emission level Stage V Cylinders / Displacement n°/cc 4 / 3849 Max. power (ECE R120) kW/HP 88.4 / 120 95 / 129 100.8 / 137 Max. power with Boost (ECE R120) kW/HP 93 / 126 100 / 136 105 / 143 Power at rated speed (ECE R120) kW/HP 83.8 / 114 90.1 / 123 95.6 / 130 Rear linkage lifting capacity (STD/OPT) Kg 5000/7000 Wheelbase mm 2510 Width (max.) mm 2431 Total unladen weight Kg 5500

Extreme configurability in a tractor means that it can cater effectively for the needs of any application. This was the principle guiding in the development of the new Spark R VRT, a family of 3 models with power outputs from 120 to 143 HP.

An infinite choice of ratios for unrivalled precision and efficiency. The VRT transmission combines state of the art technology with extraordinary efficiency to meet the needs of any task imaginable. A wide choice of options lets the customers tailor the ideal machine for their specific requirements. With a Load Sensing hydraulic system capable of delivering up to 120 l/min of oil, even implements with very high flow rate demands are no challenge for the Spark R.

A highly comfortable working environment makes your job simpler, more enjoyable and less tiring. This is why the new 4-pillar cabs of the TopVisionPro family have been improved even further, setting a new benchmark in this class. Mechanical cab suspension and front axle suspension are also available for total comfort whether working in the field or driving on public roads.

TECHNICAL SPECIFICATIONS

• Stage V Common Rail, 4-cylinder, turbo-intercooled engine with DOC+DPF+SCR exhaust gas post-treatment system

VRT transmission with 3 driving strategies (Auto/Manual/PTO)

• Front axle suspension with automatic axle management (ASM)

• Hydraulic Engine Brake (HEB)

• Hydraulic system with up to 5 rear spool valves and Power Beyond couplers

5
6 Spark R Powershift/RVshift Technical data SPARK R POWERSHIFT RVSHIFT 115 125 135 115 RVSHIFT 125 RVSHIFT 135 RVSHIFT Engine FARMotion 45 FARMotion 45 Emission level Stage V Stage V Cylinders/Displacement n°/cc 4 / 3849 4 / 3849 Max. power (ECE R120) kW/HP 85.6 / 116 93 / 126 99.8 / 136 89.3 / 121 95 / 129 100.8 / 137 Max. power with Boost (ECE R120) kW/HP 93 / 126 100 / 136 105 / 143 93 / 126 100 / 136 105 / 143 Power at rated speed (ECE R120) kW/HP 81.2 / 110 88.2 / 120 94.6 / 129 84.7 / 115 90.1 / 123 95.6 / 130 Rear linkage lifting capacity (STD/OPT) Kg 5000 / 7000 5000 / 7000 Wheelbase mm 2480 2510 Width (max.) mm 2431 2431 Total unladen weight Kg 4600 5000 5500

The new Spark R Powershift and RVshift Series were specifically conceived to deliver outstanding performance in any situation, from the most heavy duty soil preparation tasks, sowing, fertilising and applying protective crop treatments to harvesting or transport.

With its adjustable PowerShuttle, compact dimensions, outstanding agility and high hydraulic flow, the Spark R also shines in any application with a front loader. An ultramodern functional design, Powershift or RVshift (like Full Powershift) transmissions, a host of integrated SDF Smart Farming Solutions as options (such as 8” iMonitor, ISOBUS and Auto-guidance) complement each other to perfection in the models of the Spark R, to offer the ideal answer to the functional needs of every possible application, together with excellent operator comfort and low running costs.

As well as all this, other features and functionalities such as a choice of extremely efficient 4-cylinder Stage V engines with minimised maintenance, highly configurable hydraulic systems, 50 kph versions, front axle suspension with all-wheel braking, rear lifts with maximum capacities from 5000 to 7000 Kg, high maximum gross vehicle weights and new TopVision cabs also count among the many class-beating strengths of the new Spark R.

TECHNICAL SPECIFICATIONS

• Stage V Common Rail, 4-cylinder, turbo-intercooled engine with DOC+DPF+SCR exhaust gas post-treatment system

Powershift transmission: an essential and precise transmission. The base transmission variant consists of a 5 speed mechanical gearbox, up to 3 stage Powershift and up to 4 work ranges

RVshift transmission: high technology manageable through a single and simple joystick. The RVshift transmission offers a choice of 20+16 speeds selectable as easily as with a Full Powershift transmission

Front axle suspension with automatic axle management (ASM)

Hydraulic Engine Brake (HEB)

• Hydraulic system with up to 5 rear spool valves and Power Beyond couplers

7
8 Strike Technical data STRIKE 95 100 105 115 125 Engine FARMotion 45 FARMotion 35 FARMotion 45 Emissions Stage IV Cylinders/Displacement n°/cc 4 / 3849 3 / 2887 4 / 3849 Max. power (ECE R120) kW/HP 70 / 95 75 / 102 78 / 106 85 / 116 93 / 126 Power at rated speed (ECE R120) kW/HP 66.4 / 90 71.1 / 97 74 / 101 80.6 / 110 88.2 / 120 Rear linkage lifting capacity (STD/OPT) Kg 3600 / 4525 3600 / 4855 4855 / 5410 Wheelbase mm 2400 2350 2400 Total unladen weight Kg 3950 3800 3950 4250 4350

A select tractor line that breaks down any barriers between you and your work. Five different models with technical specifications suited to any task, from sowing to heavy duty traction work. With the same eye for stylish design, in true Lamborghini Trattori tradition.

A team split into five for you: The Strike 125 for heavy duty applications and traction work, the Strike 115 for general utility work and secondary tillage, and the Strike 95-100-105 for sowing and weeding work. Each model offers a choice of perfectly matched engines, transmissions and power shuttles, and each is conceived to be a valuable asset in tackling the day to day challenges of your job.

Superior performance is ensured by FARMotion 35 or FARMotion 45 engines, conceived and developed specifically for agricultural applications and matched seamlessly with the choice of transmissions available.

TECHNICAL SPECIFICATIONS

• FARMotion 35 (3 cyl.) or FARMotion 45 (4 cyl.) Stage V engines with turbo intercooler, Common Rail injection and electronic engine governor

Hydraulic reverse shuttle with SenseClutch (control with five levels of responsiveness) and Stop&Go system

• Manual transmission, with 2-stage (Hi-Lo) or 3-stage Powershift (HML) with APS function Max. speed of 40 km/h achievable at engine economy speed (Overspeed)

• Two hydraulic system configurations available: single pump 55 l/min or double pump 90 l/min on demand 4-speed power take-off, Auto PTO (with electronic lift) and ground speed PTO with independent output shaft

• 4-wheel braking with wet discs on all four wheels and Hydraulic Parking Brake (optional for HD models only) SDD system (Steering Double Displacement)

• Mechanical or electronic lift with up to 8-way hydraulic distributors with flow regulator High-visibility cab roof

Optional factory-fitted Light or Ready Kits for future installation of a front loader

9

• Independent front axle suspension

10
FARMotion 45 Stage V 4-cylinder engine with turbo intercooler and Common Rail injection
VRT continuously variable transmission with SenseClutch hydraulic reverse shuttle (with 5 user-selectable responsiveness levels)
Up to 5 auxiliary electrohydraulic distributors and 100 l/min hydraulic system with Load Sensing pump
Up to 4 mid-mounted position hydraulic couplers and an additional 2 front couplers
Front lift with double acting cylinders fed by an independent distributor
PTO with up to 3 speed modes (540/540EC0/1000) and ground speed PTO
HPB parking brake and integral braking on all 4 wheels
4-pillar cab with MaxCom armrest, InfoCentrePro and iMonitor
Pressurised cab also available with Category 4 air filtration system
Technical data SPIRE VRT 95 VRT 105 VRT 115 VRT Engine FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 4 / 3849 Max. power with Overboost (ECE R120) KW/HP - - 93 / 126 Max. power (ECE R120) kW/HP 70 / 95 78 / 106 85 / 116 Power at rated engine speed (ECE R120) kW/HP 66.4 / 90 74 / 101 80.6 / 110 Rear linkage lifting capacity (max.) Kg 4310 Wheelbase mm 2271 Overall rear width (min.-max.) mm 1745-2180 Total unladen weight Kg 4200 Spire VRT
SDF Smart Farming Solutions fully integrated
11 Spire
FARMotion 45 Stage V 4-cylinder engines with turbo intercooler and Common Rail injection
Mechanical transmission 30+15 or 3-stage Powershift (HML) 45+45
Hydraulic reverse shuttle with SenseClutch (control with five levels of responsiveness) and Stop&Go system Lift with mechanical or electronic control with up to 6-way hydraulic distributors Lifting capacity 3000 Kg (optional 3600 Kg) 3-speed power take-off and ground speed PTO All wheel braking system with wet disc brakes on all four wheels Technical data SPIRE 95 105 Engine FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 4 / 3849 Max. power (ECE R120) kW/HP 70 / 95 78 / 106 Power at rated engine speed (ECE R120) kW/HP 66.4 / 90 74 / 101 Rear linkage lifting capacity (max.) Kg 3600 Wheelbase mm 2271 Total unladen weight Kg 3575

• FARMotion 35 Stage V engines with turbo intercooler and Common Rail injection

• 15+15 speed or 30+15 speed manual transmission with underdrive and supercreeper gear (max. speed 40 km/h at engine economy speed)

• Up to 56 l/min. hydraulic system and hydraulic distributors with 6 rear outlets Mechanically controlled lift with 2500 Kg capacity (or 3500 Kg in optional configuration) with the new EasyLift system control 3-speed power take-off and ground speed PTO

• All wheel braking system with wet disc brakes on all four wheels Cabin with highly ergonomic control layout

12 Spire Trend
Technical data SPIRE TREND 70 TREND 80 TREND 90 TREND 100 TREND Engine FARMotion 35 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 Max. power (ECE R120) kW/HP 48.9 / 66 55.8 / 76 67 / 91 75 / 102 Power at rated speed (ECE R120) kW/HP 48 / 65 55.2 / 75 63.5 / 86 71.1 / 97 Rear linkage lifting capacity (max.) Kg 3050 Wheelbase mm 2100 Total unladen weight Kg 2520
13 Crono
New front nose bonnet design in keeping with Lamborghini Trattori style
35 Stage V engines with turbo intercooler, Common Rail injection and electronic governor
Mechanical transmission with 5 gears (15+15 or 15+15 ECO with creeper) Rear
with up to 3 speeds: 540/540ECO/1000 Electrohydraulically engaged four-wheel drive and differential lock Hydraulic system up to 56 l/min and independent steering pump New
system to control the mechanical rear lift Technical data CRONO 70 80 90 100 Engine FARMotion 35 Emission level Stage V Cylinders/Displacement n°/cc 4 / 2887 Max. power (ECE R120) kW/HP 48.9 / 66 55.8 / 76 67 / 91 75 / 102 Power at rated speed (ECE R120) kW/HP 48 / 65 55.2 / 75 63.5 / 86 71.1 / 97 Rear linkage lifting capacity (max.) Kg 3500 Wheelbase (4WD / 2WD) mm 2100 / 2166 2100 /Total unladen weight (4WD / 2WD) Kg 2950 / 2750 3050 / -
• FARMotion
PTO
EasyLift

14 Spire F VRT
FARMotion 35 or 45 Stage V, 3 or 4-cylinder turbo intercooled engine
VRT continuously variable transmission with three modes: Auto/Manual/PTO
reverse shuttle with SenseClutch (with five settable responsiveness levels)
Hydraulic
Three speed PTO (540/540ECO/1000) and ground speed PTO. Auto PTO function
system with various configuration options: with 84
pump or 100
Load Sensing pump. Up to 9 rear and mid-mounted position distributors with electronic control Hydrostatic brakes on all four wheels
front axle suspension with independent wheels Four pillar cab with flat platform and high visibility roof, with Category 4 compliant pressurised ventilation system
Hydraulic
l/min
l/min
Exclusive
Exclusive MaxCom armrest fully integrated into the seat
SDF Smart Farming Solutions fully integrated Technical data SPIRE F VRT 90 F VRT 95 F VRT 100 F VRT 105 F VRT 115 F VRT Engine FARMotion 35 FARMotion 45 FARMotion 35 FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 4 / 3849 3 / 2887 4/3849 Max. power with Overboost (ECE R120) kW/HP - - - - 93 / 126 Max. power (ECE R120) kW/HP 67 / 91 70 / 95 75 / 102 78 / 106 85 / 116 Power at rated engine speed (ECE R120) kW/HP 63.5 / 86 66.4 / 90 71.1 / 97 74 / 101 80.6 / 110 Rear linkage lifting capacity (max.) Kg 3800 Wheelbase mm 2044 2174 2044 2174 Overall rear width (min.-max.) mm 1440-1670 Total unladen weight Kg 3635 3860 3635 3860

• FARMotion 35 and 45 Stage V, 3 or 4 cylinder engines with turbo intercooler, Common Rail injection and electronic governor

• Mechanical shuttle or PowerShuttle with SenseClutch (control with five levels of responsiveness) and Stop&Go system

Mechanical transmission from 12+12 up to 30+15 or Powershift transmission: 30+30 (Hi-Lo) or 45+45 3-stage Powershift (HML)

Up to 68 l/min hydraulic system

Hydrostatic braking on all four wheels

4-post cab with flat floor suspended on Hydro Silent-Block. Cat.4 filtration available

Platform version with 2-post foldable ROPS available. Platform suspended on Hydro Silent-Block

• Design perfectly in keeping with the image of Lamborghini Trattori

15 Spire F
Technical data SPIRE F 90 F 95 F 100 F 105 F 115 F Engine FARMotion 35 FARMotion 45 FARMotion 35 FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 4 / 3849 3 / 2887 4/3849 Max. power (ECE R120) kW/HP 67 / 91 70 / 95 75 / 102 78 / 106 85 / 116 Power at rated engine speed (ECE R120) kW/HP 63.5 / 86 66.4 / 90 71.1 / 97 74 / 101 80.6 / 110 Rear linkage lifting capacity (max.) Kg 3940 Wheelbase mm 2044 2174 2044 2174 Overall rear width (min.-max.) mm 1440-1670 Total unladen weight Kg 2590 2650 2590 2650 Total unladen weight with cab Kg 3460 3515 3460 3515

16 Spire F Target
FARMotion 35 engine, Stage V, without the need of AdBlue refill
Mechanical or PowerShuttle transmission
5-speed transmission with 3-speed Powershift and 3 ranges, 45 FWD + 45 REV in total
3-speed rear PTO and front PTO available 54 or 64 l/min hydraulic pump Independent front axle suspension available Front axle with front brakes Available also in platform version with foldable ROPS Technical data SPIRE F TARGET 80 F TARGET Engine FARMotion 35 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 Max. power (ECE R120) kW/HP 55.8 / 76 Power at rated engine speed (ECE R120) kW/HP 55.2 / 75 Rear linkage lifting capacity (max.) Kg 2800 Wheelbase mm 2011 Overall rear width (min.-max.) mm 1441-1620 Total unladen weight Kg 2730 Total unladen weight with cab Kg 2995

• FARMotion 35, turbo intercooled engine, with Common Rail, electronic regulation and viscostatic fan. Stage V compliant only with DPF

17
F Trend
Spire
Technical data SPIRE F TREND 70 F TREND 80 F TREND Engine FARMotion 35 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 Max. power (ECE R120) kW/HP 48.9 / 66 58.8 / 76 Power at rated engine speed (ECE R120) kW/HP 48 / 65 55.2 / 75 Rear linkage lifting capacity (max.) Kg 3050 Wheelbase mm 1996 Overall rear width (min.-max.) mm 1340-1640 Total unladen weight Kg 2325
• 8+8 speed transmission with 4 speed main gearbox, or 10+10, 15+15 or 30+15 speed transmissions with 5 speed main gearbox 40 km/h max. speed 2-speed PTO and ground speed PTO Four-wheel wet disc braking Hydraulic steering with independent pump Modern design

• Powerful, compact and efficient 3 or 4 cylinder FARMotion 35 and 45 engines conceived specifically for farming

• VRT continuously variable transmission with 40 Km/h ECO mode, hydraulic reverse shuttle with 5 selectable responsiveness levels (SenseClutch) and PowerZero function Hydraulic systems with a huge choice of optional equipment to configure the tractor perfectly for the needs of the individual farm and for working with any implement 3-speed PTO (540/540ECO/1000) and ground speed PTO Hydrostatic braking on all four wheels 4 pillar cab suspended on Hydro Silent-Block with flat platform and available with Cat. 4 Simple and intuitive to use, with the MaxCom multifunction armrest with integrated joystick and InfoCentrePro high resolution display

• Independent front axle suspension

18 Spire S/V VRT
Technical data SPIRE S/V VRT 90 S/V VRT 95 S/V VRT 100 S/V VRT 105 S/V VRT 115 S/V VRT Engine FARMotion 35 FARMotion 45 FARMotion 35 FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 3 /2887 4 /3849 3 /2887 4/3849 Max. power with Overboost (ECE R120) kW/HP - - - - 93 /126 Max. power (ECE R120) kW/HP 67 /91 70 /95 75 /102 78 /106 85 /116 Power at rated engine speed (ECE R120) kW/HP 63.5 /86 66.4 /90 71.1 /97 74 /101 80.6 /110 Rear linkage lifting capacity (max.) Kg 2600 Wheelbase mm 2086 2216 2086 2216 Overall rear width (min.-max.) mm 1265-1515 Total unladen weight Kg 3565 3620 3565 3620

• FARMotion 35 and 45 with engine speed memory function

• Mechanical transmission from 12+12 up to 30+15 or Powershift transmission: 30+30 (Hi-Lo) or 45+45 3-stage Powershift (HML)

• Mechanical shuttle or hydraulic reverse shuttle with Stop&Go system Linkage with electronic control with a maximum lifting capacity of 2600 Kg Hydraulic system with up to 68 l/min flow 3-speed power take-off (540/540ECO/1000) and ground speed PTO

Hydrostatic brakes on all four wheels 4-post cab with flat floor, Cat. 4 filtration and pressurisation and Hydro Silent-Block suspension

• Independent front wheel suspension

• Design with sloping bonnet

19
Spire S/V
Technical data SPIRE S/V 90 S/V 95 S/V 100 S/V 105 S/V 115 S/V Engine FARMotion 35 FARMotion 45 FARMotion 35 FARMotion 45 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 4 / 3849 3 / 2887 4/3849 Max. power (ECE R120) kW/HP 67 / 91 70 / 95 75 / 102 78 / 106 85 / 116 Power at rated engine speed (ECE R120) kW/HP 63.5 / 86 66.4 / 90 71.1 / 97 74 / 101 80.6 / 110 Rear linkage lifting capacity (max.) Kg 2600 Wheelbase mm 2086 2216 2086 2216 Overall rear width (min.-max.) mm 1270-1515 Total unladen weight Kg 3265 3320 3265 3320

20 Spire S/V Target
FARMotion 35 engine, Stage V, without the need of AdBlue refill
5-speed transmission with 3-speed Powershift and 3 ranges, 45 FWD + 45 REV in total
Mechanical or PowerShuttle transmission
3-speed rear PTO and front PTO available 54 or 64 l/min hydraulic pump Independent front axle suspension available Front axle with front brakes Available also in platform version with foldable ROPS Technical data SPIRE S/V TARGET 80 S TARGET 80 V TARGET Engine FARMotion 35 Emission level Stage V Cylinders/Displacement n°/cc 3 / 2887 Max. power (ECE R120) kW/HP 55.8 / 76 Power at rated engine speed (ECE R120) kW/HP 55.2 / 75 Rear linkage lifting capacity (max.) Kg 2600 Wheelbase mm 2050 Overall rear width (min.-max.) mm 1269-1463 1166-1317 Total unladen weight Kg 2650 2610 Total unladen weight with cab Kg 2850 2830

• Perkins Stage V, 4-cylinder, liquid-cooled, naturally aspirated or turbocharged engines

• Maximum power of 51 or 59 HP available at just 2400 rpm

• 12+12 speed or 16+16 speed manual transmission with synchronised PowerShuttle and creeper gear, top speed 30 km/h

• Max. speed attainable at reduced engine speed

• Independent hydraulic steering circuit

• Hydraulic system with 30 l/min. pump and up to 6 hydraulic couplers

• 2-speed power take-off (540/540ECO or 540/1000) and ground speed PTO

• Front lift and front PTO 1000

• Front and rear electrohydraulic differential lock Available also in platform version with foldable ROPS

21 Sprint
Technical data SPRINT 50 BASSO 50 60 Engine Perkins Emission level Stage V Cylinders/Displacement n°/cc 2 / 2216 Max. power (ECE R120) kW/HP 38 / 51 43.5 / 59 Power at rated engine speed (ECE R120) kW/HP 38 / 51 43.5 / 59 Rear linkage lifting capacity (max.) Kg 1320 Wheelbase mm 1800 Width (min.-max.) mm 1375-1610 Total unladen weight Kg 1450 1550 1600 Total unladen weight with Cab Kg - 1800 1850

FRONT LOADER

A wide range of loaders and attachments.

The front loaders are designed specifically for the 50 to 143 HP range of tractors. As well as a solid, robust structure, they offer a wide selection of attachments for carrying out a full range of agricultural handling and storage tasks to perfection. With Lamborghini Trattori front loaders the strain on the tractor is significantly reduced. Thanks to technical know-how the implement is in an ideal position to have less impact on the front axle. The loader is designed for maximum implement loading capacity and no trickle losses, with a maximum tilting angle, on the ground between 41° and 45°, raised up to 63°. Thanks to the Z-kinematics the driver profits from the best view and maximum performance. Moreover, he can drive smoothly even on bumpy terrain with the Comfort-Drive damping system that reduces the shocks on loader and implement. Assembly, disassembly and maintenance works are quick and easy jobs, as well as using the wing with all kinds of implements. With the unique Return-to-Level feature the implement returns to a predefined optimum position just at the touch of a button.

• Rugged and durable: Profiline Front Loaders made of fine grain steel

• Mechanical level control system, Return-to-Level optional. Maximum load height up to 4.3 m

The loader and the relative mounting structure do not impede access to maintenance points

• Optional Quick-Fix quick hitch coupler for connecting the front loader and the relative connectors quickly and simply High lifting force throughout the entire lifting cycle

• Intuitive, precise control with joystick or single lever control

• The Comfort-Drive function protects the operator and implements against extreme vibration

22

Precision is the basic prerequisite for productivity.

SDF Smart Farming Solutions combines a large number of digital solutions for efficient and comfortable operation of tractors. These solutions include reliable and extremely precise Auto-guidance systems, ISOBUS applications and a number of data management systems. The iMonitor is a simple to use centralised controller which plays a key role in the majority of these solutions and applications.

SDF Guidance

Auto-guidance systems feature increasingly as standard equipment in the tractors used by many farms today, due to the evident advantages they offer: saving resources, increasing convenience and productivity as well as reliable precision. Operators can trust its high reliability even in difficult working conditions such as fog or night time. Anyone who has ever worked with a steering system will never want to be without it again. Many precision farming applications are based on satellite navigation. Our receivers use free, internationally available signals which offer different accuracy levels depending on the correction service and the receiver model. Our customers can choose the system that best suits their operation.

SDF Data Management

Efficient data management is becoming increasingly important to optimise work processes. No matter which type of data our customer want to work with, whether it’s machine or agronomic data: SDF provides various applications for reliable transfer and insight of valuable data. Using standard file formats, customers can keep an overview at all times and data are transferred in a coordinated manner. This ensures maximum compatibility while our customers are always master of their decisions.

SDF Fleet Management

Optimise operations. Increase efficiency. The new SDF Fleet Management offers customised solutions to manage relevant machine data at a glance. Our customers like farmers, contractors or any other users benefit from full control of their machines by accessing various valuable data. The browser-based SDF Fleet Management application is the central interface to insight telemetry data for Lamborghini Trattori machines. Machine data like fuel level, position or speed are transferred in real time into the application where users can monitor, analyse and optimise the use of their machinery. Error messages can be transmitted to dealer’s service manager to prevent upcoming issues and decrease even machine downtime.

Agrirouter

For reliable online data exchange between different endpoints, Lamborghini Trattori provides an interface to the Agrirouter. It is a universal data exchange platform that allows farmers and contractors to exchange data like field boundaries or guidelines between machinery and any agricultural software applications (e.g. an FMIS) from a wide range of manufacturers.

ISOBUS

Electronics make agricultural machinery safer, more powerful, more precise and more efficient. ISOBUS connectivity lets the operator use multiple applications to control different implements individually from a single monitor. iMonitor is the central controller for all ISOBUS applications and can perform many different tasks intuitively and easily, such as assigning AUX-N functions, generating and handling application maps and automatically controlling up to 200 different sections. A great number of functions are even available without activation. TIM automises various functions between tractor and implement to increase comfort, efficiency and ensures highest level of work quality. A wide range of Lamborghini Trattori tractor models are already TIM-ready and can easily be activated for full usage of tractor implement management.

• Superior compatibility

Maximised profitability

23
HIGHLIGHTS
Increased productivity Easy to use Secure data
Added convenience
precision
connectivity
Unprecedented
Advanced
More efficient task management

The technical data and images contained herein are indicative only. Lamborghini Trattori reserves the right to modify its products at any time without prior notice.

Lamborghini Trattori is a brand of

12/22 www.lamborghini-tractors.com
Produced by Marketing & Communication DepartmentCode 308.8364.3.2-10
