The Kellfri TV04 tipping trailer is a flexible tipping trailer for the farm, perfect for loading and easy to clean. The swivel ball coupling means that the trailer is suitable for use in uneven terrain. Foldable sides and removable headboard and tailgate make the trailer perfect for transporting long logs/wood. Height adjustable parking jack allows you to disconnect the trailer when loaded.
Product no.
23-TV04
Dimensions
2500 x 1300 x 820 mm
Floor dimensions
1250 x 1000 x 350 mm
Tyres
22x11-8 offroad tyres
Max. load
320 kg
Weight
123 kg
Tow bar
50 mm tow bar ball hitch
Materials
Steel frame, aluminium floor
ATV tipping trailer, 1.5 tonnes Flexible and sturdy bogie trailer for your ATV. Perfect on the farm, in the garden and in terrain. Winch-assisted tipping. The trailer is galvanised, equipped with a tiltable floor, as well as fold-down tailgate and sides. Substantial wheels and a ground clearance of 290 mm allow for smooth manoeuvres in difficult ground conditions. Max. load 1500 kg. 50 mm ball coupling supplied as standard. Product no. Total length Floor length Width Headboard height Weight Load capacity Tyres Tipping angle Ball coupling Ground clearance
23-TV15ATV 3040 mm 2010 mm 1330 mm 300 mm 310 kg 1500 kg 22 x 11-10 55째 50 mm 290 mm
ATV equipment AND equipment for Land, roads and properties
TV04 tipping trailer
accessories 23-TV15ATVFH Extension sides Height 30 cm Weight 27 kg
ATV log skidder A log skidder for your ATV with rotating spiked rail with removable and foldable bolsters. The supplied winch allows you to pull a log towards you and lift it into the spiked rail in one movement. Galvanised. Equipped with swivel tow bar. Product no.
21-LUW07
Length Spiked rail width inner Track width Height Weight Tyres
2450 mm 610 mm 1170 mm 1900 mm 70 kg 22*11-8
