Retention Force Dynamometer
Dyna Force Measuring device for pulling force of machine tool spindle.
Belleville Springs
• Periodical measurement avoids reduced rigidity leading to vibrations, loss of machining quality, shortened tool life
Collet Longer taper shank to e nhance reliability Long taper supports itself in long span and stabilizes the value of measurement.
Only one display for all taper sizes One common display can be used for all taper sizes.
50
40
Taper
30
Specification Corresponding JIS, DIN, ANSI
Fig. 1
Cable
Case
Fig. 2
Set Model
Contents of Set Measuring Device Fig. Display SNT30 -DF10 NT30 -DF10 1 SBT30 -DF10 BT30 -DF10 2 DFA-1 SNT40 -DF30 NT40 -DF30 1 (AA batteryx2) SNT50 -DF50 NT50 -DF50 1 -DF30 * -DF30 1 1. 2. 3. 4. 5.
Display
L
ØD1
ØD1
H
ØD2
H
L
ØD2
Measuring device
Taper Size Rated Capacity
ØD1 ØD2 L
H
Weight (kg)
Order No.
30
65
58 46 66 90 70
20 26 24 33 20
1.5 1.6 2.5 6.0 3.9
805.845 805.442 804.949 805.423 805.846
Cable DFC-1 40 (2 m) 50
10kN (980 kgf)
30kN (2 940 kgf) 73 50kN (4 900 kgf) 96 30kN (2 940 kgf) 73
80 98 90 110 86
Each component is also available separately. Please contact BIG KAISER agent if individual component is required. SBT30-DF10 is designed exclusively for machines not capable of automatic tool change. SBT30-DF10 is suitable for BT/BBT30 machines only. Pull stud bolt is to be ordered separately. For DIN, ISO, ANSI & CAT standard machines, e xclusive pull stud bolt for dyna force is required. SNT50-DF30 marked with * is a light-weight model.
Exclusive pull stud bolts for Dyna Force An exclusive pull stud bolt is needed for a machine spindle in DIN, ANSI or CAT standard. Pull stud bolts in MAS and JIS standards can be used. These pull stud bolts are not suitable for the SBT30-DF10. Standard No. DIN69872 ISO7388 ANSI B5.50 ASME B5.50
12
Type A Type B
Shank No. 30 Model DF-PDV30 DF-PAV30 DF-PCV30
Order No. 804.683
804.680 804.684
Shank No. 40 Model
Order No.
Shank No. 50 Model
Order No.
DF-PDV40A
804.685
DF-PDV50A
804.686
DF-PAV40
804.681
DF-PAV50
804.682
DF-PCV40
804.687
DF-PCV50
804.688
