Filtration Automation of the Future

Sometime in the future most filter applications will be automated to the extent that when filters are ready to be replaced the action will be automatic. Furthermore, the replacement period will be based on need and not on interval.

There will still be room for individual experts, but they will increasingly be specialists who are remotely monitoring operations. One such example is the use of fabric filters to capture both dust and SO2 in coal fired boiler systems. The plant operations are remotely monitored by the specialists. When maintenance challenges go beyond the routine, they intervene with solutions. In one case, this resulted in changes to the bags being offered by suppliers. So, there will always be a need for experts, but they will perform at a very high level and focus on exceptions rather than normal challenges.

The fabric filter industry has long relied on instrumentation to determine performance. The so-called bag detector has been in use and visually measures leaks from broken bags. But we have moved to where there are many parameters which can be used to trigger a replacement before a bag breaks. Filter manufacturers in the future will maintain special expertise in what can be called a guide function.

An automation system consists of three functions: guide, control, and measure.

The big revenues are in the control segment which includes computers, motors, and other electrical gear.

Measurement includes the instruments used to measure air, liquids, and solids. The guide function includes the software which is the brains of the operation. This is where filter manufactures can lead rather than follow. The best guide strategy is based on the most detailed knowledge of filter parameters and challenges. How long can an excess temperature of 400°F be sustained prior to shut down? What is the best pulsing sequence and duration for cleaning bags?

The guide function is a small but key segment of the automation system. Filter suppliers will be well served to dominate this space and deal on equal terms with the control suppliers. Otherwise, at some point, the big control suppliers could be main contractors and filter companies just subcontractors.

There are many revenue possibilities obtainable from IIOT and Remote O&M. The big difference is the service and automatic replacement of filter elements as part of annual contracts. With a cost reduction sharing system, both supplier and customer can benefit.

The increased ability to measure contaminants will continue to shape and expand the filter market. In the pharmaceutical, hospital, food and other life sciences applications, it is now possible to measure viable particles continuously. Previously total particles could be continuously monitored but live particles could not be separately identified.

The life sciences industry could only measure the danger by use of settling plates. They accumulated life organisms in a culture. Over a 24-hour period these plates would provide the viable particle load but only for the previous day and not in real-time. New instruments now allow measurement of total particulate and the viable segment separately.

The whole science of measurement and setting limits is challenging. For example, high-efficiency air filters have been analyzed based on the most penetrating particle size but there is debate on the most penetrating particle size and if that is 0.1 microns rather than 0.2 microns. The theory is that the Brownian movement of very small particles makes them more easily captured.

There are also issues with efficiency of electrostatically charged filters once the dust loading starts to diminish the electrostatic charge. New ambient measurement abilities are changing the market and protection of people from contaminants. One example is the ability to measure total ambient particulate. Regulations require that ambient particulate levels are a certain level in micrograms per cubic meter. But lead, and other metals have much greater harm potential than silica or some other particles.

The city of St. Louis, MO USA was meeting its ambient particle limits. Then it installed monitors able to measure just the lead content. When the wind was blowing from the direction of a lead smelter, the lead percentage of the total dust in the ambient air increased substantially. So, the assessment of harm is now much more accurate due to new monitors. The performance of air pollution control equipment is measured with stack monitors. They are very accurate in measuring the dust quantity per unit of exhaust gas. But surprisingly measuring the quantity of gas exhausted is not that easy. Thermal, differential pressure, and ultrasonic options are used but provide slightly different results depending on stack gas conditions. There are other anomalies as well. Mercury limits are set by measuring the vapor phase mercury in the exhaust. The reasoning is that nearly all the mercury is in the vapor phase. How the systems remove the mercury involves converting the mercury to a particulate. So, theoretically the polluting plant only has to convert vaporous mercury to a particulate and then can emit it from the stack without penalty.

Mercury in the vapor phase travels from gold mines in Chili to the Arctic Circle. Mercury on a particle surface will be deposited much nearer to the emitting plant. This local versus global analysis also applies to CO2 vs. CO vs. NOx. By operating at higher temperatures, the NOx is reduced but the CO2 is increased. The NOx is a local health hazard whereas the CO2 is a global hazard for the future. The industry needs guidance on the harm of CO2 vs. NOx

Artificial intelligence is quickly impacting the filter industry in a variety of ways. It is already possible to make better filter decisions using AI. This will quickly expand to where all the available case histories of the various suppliers will be instantly analyzed and advise the purchaser of the best choices.
