Sintered wire.
The active part of the beads is a ring of sintered diamonds whose composition is like the segments used in blades. It is a long-life wire.
Husqvarna C 760.
QUALITY INDICATOR
2
THE PREMIUM WIRE, COMPLETE POWER RANGE ■ ■
Designed for low- and medium-hardness reinforced concrete. Features a high diamond concentration.
PRODUCT NUMBER
NUMBER OF BEADS / M
DIAMETER BEADS, MM
ASSEMBLY
CUTTING SYSTEM
543 07 34-47
44
10.3
Springs + rubber, sintered beads
Wet
Accessories for diamond wires. PRODUCT OUTER NUMBER DIAMETER, MM A CONNECTOR, CYLINDER 16
INNER DIAMETER, MM
LENGTH, MM
CABLE DIAMETER, MM
TYPE
PRESS, TONNE
DIES PRESS
FLEXIBILITY
5 4 3 0 8 0 7 19
5.1
16
5
CYL9
4.5
PC(HT45)H5F-66 *
25.4
5.1
20
5
CYL9
4.5
PC(HT45)H5F-66 *
25.4
5
24
5
SCR
4.5
PC(HT45)H5F-70 **
25.4
5
27
5
CRD
4.5
PC(HT45)H5F-70 **
25.4
9
CONNECTOR, CYLINDER 20
543021670
9
B CONNECTOR, SCREWED
543021515
9.5
C CONNECTOR, CARDAN
5 4 3 0 2 1 5 84
9.5
* Explanation of code: H5F-66 means that the die length is 5 mm and the distance between parallel sides of the hexagon is 6.6 mm. ** Explanation of code: H5F-70 means that the die length is 5 mm and the distance between parallel sides of the hexagon is 7.0 mm.
Husqvarna has a complete range of connectors designed for the wires. There are also appropriate hydraulic hand presses and corresponding dies for crimping the connectors.
D
C
A
PRODUCT NUMBER SPARE PIN FOR CARDAN
543021590 D PRESS, CEMBRE 4.5 TONNE
B
543000670 E DIES, PRESS 66
543002889 E DIES, PRESS 70
543002878
E
41
