A
B
A large selection of slurry collectors.
C
V-shaped slurry collectors.
E
D
U-shaped slurry collectors.
F
Anchoring kit, incl large nut, holding screw, pointer and 5 anchors.
H
I
Drill motor spanner.
Washer quick release, to release the drill motor thread from the drill bit. G
Pressurised water tank holds 15 litres and comes with a 3-meter hose.
WT 10 – battery-powered water tank.
J
Large selection of adapters to suit various threads.
Extensions, for deep drilling with standard drill bits.
Accessories. A A A A A A A B C D
Slurry collector, 65 mm Slurry collector, 110 mm Slurry collector, 160 mm Slurry collector, 180 mm Slurry collector, 210 mm Slurry collector, 260 mm Slurry collector, 310 mm Slurry collector V-shaped, 700 mm Slurry collector U-shaped, 212 mm Quick release ring
531280000 531280001 531280002 531280296 531280003 531280004 531280005 531280007 531280329 543039182
E E F G H I J J J J
Anchoring kit Anchor kit, expanders Pressurised water tank Water pump, WT 10, 230 V Drill motor spanner, 32 mm Adapter drill bit *, 1 1 / 4" F – 1 / 2" G F Extension drill bit *, 200 mm, 1 1 / 4" F – 1 1 / 4" M, steel Extension drill bit *, 300 mm, 1 1 / 4" F – 1 1 / 4" M, steel Extension drill bit *, 500 mm, 1 1 / 4" F – 1 1 / 4" M, steel Extension drill bit *, 1000 mm, 1 1 / 4" F – 1 1 / 4" M, steel
502434801 502435401 506326302 965971003 531140952 543046426 543046501 543046502 543046504 543046505
* See page 158 for more drill bit accessories.
Available drill stands. RECOMMENDED DS 450
DS 70 ATS
Drill diameter, max mm
450
650
Travel, max mm
635 / 1635
680
Weight, incl. carriage, kg
23.3 / 30
37
Read more on page
143
142
131
