CORE DRILLS
CORE DRILLS
DMS 180
DMS 180.
Item No.
966916101
List price
$1,273.00
Item No. ( Vacuum pump assembly)
966916102
List price
$1,890.00
Technical specifications. Power, hp (kW)
2.3 (1.8)
Voltage/amperage, V/amps
115/15
Maximum bit diameter with spacers, in (mm)
6 (150)
Speeds
1
Travel length, in (mm)
19 (480)
Spindle speeds full load, rpm
800
Rated output, watts
1,750
Sound pressure level, dB(A)
89
Sound power level, dB(A)
102
Spindle thread, outer
1-1/4-7
Weight, lbs (kg)
51 (23)
Recommended generator size, watts
3,500
Applications.
Accessories.
• Ideal for core drilling up to 6" in diameter.
“Wing” style quick anchoring attachment
542192150
• Used to angle drill.
“Pro” style quick anchoring attachment
542192145
122.00
Vacuum pump with fittings
541400078
656.00
Benefits.
Vacuum plate gasket
578932101
• Single-speed gearbox with electronic overload
Adapter cord 20A twist to 15A straight
542173120
26.00
protection guards against overheating and extends motor life. • Combo base with base and slot gasket are standard for vacuum mounting. • Mechanical clutch reduces risk of motor damage. • 19" drilling stroke accommodates standard wet core drilling bits. • Integrated handle increases portability. • V-groove roller carriage facilitates accurate alignment, which requires minimal adjustment and improves drilling performance.
Slurry vacuum ring - 5" bit capacity
541402591
181.00
Water tank (metal - 4 gallon)
582017401
253.00
Water tank (plastic - 4 gallon)
506326302
89.00
WT 15 pressurized water tank
966708302
391.00
Wheel kit
541405089
62.00
Core Bit quick disconnect
543052878
130.00
WT 15 pressurized water tank.
Core bit quick disconnect ring.
DIAMOND BITS - PAGE 88
DMS 180 $122.00
16.00
Water tanks.
5” Slurry vacuum ring and bit capacity.
83
