Husqvarna DXR 140.
DEMOLITION
The boom is capable of rotating 360°, which enables Husqvarna’s smallest demolition robot the ability to work on multiple surfaces while the body of the machine stays secure. Applications. • Perfect for demolition and smaller excavation work
Shown with optional breaker attachment.
Product specifications. DXR 140 Item no.
966529302
List price
$140,000.00
E
Attachments not included.
inconcrete and brick constructions, both indoors and out. It is also suitable for pile-driving, staircases and roof applications. • Efficient in tough, dirty environments such as metal processing plants. • Small design enables work in confined spaces, such as basements. Benefits. • 360° of rotation, based on a hydraulic/electrical swivel
Technical specifications. Power, hp (kW)
11 (15)
Weight, lbs (kg)
2,132 (967)
Reach, ft (m)
12 (3.7)
Flow 60 Hz, g/min (l / min)
13.6 (52)
System pressure, nominal maximum, psi (bar)
2,901 (200)
System pressure, increased maximum, psi (bar)
3,626 (250)
• • •
Variable flow to tools and system, g/min (l / min) 0 – 13.6 (0 – 52) Pump type
Variable load-sensing axial piston pump
Width, machine body, in (mm)
30.35 (771)
Length, machine body, in (mm)
63.5 (1,614 including dozer blade)
Height, machine body, in (mm)
33.6 (854)
Type
Modular, digital CAN-based PLC
Terminal
Portable remote control
Communication
Radio or cable
Radio
Industrial Bluetooth, class 1
Range, radio, ft (m)
Up to 328 (100)
Battery
High-capacity Li-ion 2500 mAh
* Reach measured on machine with breaker SB 152, from center of rotation to tip of breaker, with machine’s arm at maximum extension, in horizontal position.
• • •
• • • •
152
technique, allows a more flexible work area. Individually controlled outriggers enable it to work on uneven surfaces or close to walls. Stronger working lights with a new generation of LED spotlights provide exceptional illumination. Only 31 inches (770mm) wide; it fits through most normal-size doorways. Low machine profile does not block the line of sight. Rugged design protects it from sharp objects and falling overhead debris. The remote control can be operated by one-hand and the 3-1/2 inch color display enables the operator to easily see what is shown. Bluetooth Technology is less sensitive to interference, ensuring the machine and operator are always synchronized. A sturdy harness with a curved alloy bar attached to the remote control enhances comfort and control. The power unit’s location above the undercarriage and the automatic grease pump provide for easy service. Operator can adjust the flow and pressure of the tool attachment to run other hydraulic equipment. With Husqvarna’s global service network operators always have access to servicing and product specialists.
