Husqvarna Banner Line ® Handheld. general purpose bits • The Banner Line® Handheld bit is used for general purpose drilling with a handheld drill. • These bits have thin-wall tubing making them lightweight and easy to control. Use when wet cutting only. • Total segment height of the handheld bits is .300" (.200" diamond depth; .100" segment base).
Diameter Inches 1 1-1/4 1-1/2 1-5/8 1-3/4 2 2-1/4 2-1/2 2-3/4 3 3-1/2 4
premium
mm 25 32 38 42 44 51 57 63 70 76 89 100
D
Item No. 542751170 542751172 542751174 542751175 542751176 542751178 542784451 542784452 542784453 542784454 542784456 542784457
List Price $119.00 139.00 159.00 177.00 186.00 197.00 215.00 242.00 254.00 265.00 311.00 352.00
Handheld Bit Specifications Core Bit Size
1" - 4"
Thread Size
5/8" - 11
Core Travel
10"
CORE DRILLS
Wet Cutting laser weld
Husqvarna Dri Bits™. general purpose, masonry bits • DRI5 is designed for drilling brick when using an angle grinder. Also can be used for fast
drilling of block, brick or soft aggregate concrete on angle grinders or hand held drills. Not recommended for hard concrete or steel. • DRI8 is designed for long life drilling in lightweight block or concrete block materials on hand drills or angle grinders. Can also be used for long life drilling of brick on hand drills. Not recommended for cured concrete or steel. • The specially designed barrel vents keep bits cool and provide fast removal of cuttings. Use these bits on core drilling machines or right angle grinders (mount bits directly onto standard 5/8"-11 grinder spindles). • These bits drill faster than conventional carbide-tipped percussion bits for a smoother finish and little patching. • Total segment height is .320" (.250" diamond depth; .070" segment base). wet or dry Cutting laser weld
Diameter Inches 1 1-1/4 1-1/2 1-3/4 2 2-1/4 2-1/2 3 3-1/2 4 4-1/2 5 6
mm 25 32 38 44 51 57 63 76 89 100 114 127 152
super premium
DRI5 542750636 542750637 542750638 542750639 542750640 542750641 542750642 542750643 542750644 542750645 542750646 542750647 542750648
D
DRI8 542750649 542750650 542750651 542750652 542750653 542750654 542750655 542750656 542750657 542750658 542750659 542750660 542750661
Max rpm / Min rpm 6,000/2,300 6,000/2,300 5,000/1,600 5,000/1,600 5,000/1,200 5,000/1,200 5,000/1,200 5,000/800 5,000/800 5,000/700 5,000/700 2,500/700 2,500/600
DRI5
DRI8
Dri Bit™ Specifications Overall Length
10-1/2"
Core Travel
10"
Thread Size
5/8" - 11
List Price $128.00 130.00 139.00 150.00 165.00 180.00 192.00 234.00 267.00 277.00 346.00 408.00 495.00
113
