FIGURE 3 7. SUPPORT/ROTATOR AND JIB ASSEMBLIES (AJ & AJP
ITEM PART NUMBER QTY
DESCRIPTION
Ref JIB ASSEMBLIES (AJ & AJP) 0259440 Ref Jib Assemblies E45AJ & M45AJ 0259441 Ref Jib Assemblies E40AJP & M40AJP 1 0060044 1 Rotator Assembly (See ROTATOR ASSEMBLY for Breakdown) 2 Ref Rotator Assembly Options (See ROTATOR ASSEMBLY for Breakdown): 2 Not Required 0 Rotator Assembly E45AJ & M45AJ 2 0060046 AR Rotator Assembly E40AJP & M40AJP 3 0641407 2 Bolt 1/4in-20NC x 7/8in 4 0641608 6 Bolt 3/8in-16NC x 1in 5 0641610 6 Bolt 3/8in-16NC x 1 1/4in 6 0641616 4 Bolt 3/8in-16NC x 2in 7 0641618 2 Bolt 3/8in-16NC x 2 1/4in 8 0641810 AR Bolt 1/2in-13NC x 1 1/4in 9 0961947 2 Bushing, Garmax 10 0961951 2 Bushing, Garmax 11 1320259 2 Clamp, Block 12 1683779 1 Jib Cylinder Assembly (See CYLINDER SECTION for Breakdown) 13 3311405 2 Locknut 1/4in-20NC 14 3311501 8 Nut 5/16in-18NC 15 3311605 12 Locknut 3/8in-16NC 16 3422791 2 Pin 17 3422794 2 Pin 18 3571406 1 Plate, Jib Cover 19 4711600 AR Flatwasher 3/8in Narrow 20 4711800 AR Flatwasher 1/2in Narrow 21 4740362 4 Flatwasher 1/4in 22 4751600 12 Flatwasher 3/8in 23 4845926 1 Link (Upper) 24 4845927 2 Link (Lower) 25 4846050 1 Support Weldment 26 Ref Pivot Options: 26A 4845925 1 Pivot E45AJ & M45AJ 26B 4846073 1 Pivot E40AJP & M40AJP 27 0100011 AR Loctite #242 (Not Shown) Ref SUPPORT AND ROTATOR ASSEMBLY 0259366 Ref Support and Rotator Assembly E45AJ & M45AJ 0259939 Ref Support and Rotator Assembly E40AJP & M40AJP 119 3841203 1 Keeper, Pin 120 3841143 2 Keeper, Pin 122 Ref Pin Options: 122 3422793 1 Pin E45AJ & M45AJ 122 3422814 1 Pin E40AJP & M40AJP 123 3020022 AR Grease 127 0641610 1 Bolt 3/8in-16NC x 1 1/4in 129 Ref Platform Level Cylinder Assembly Options (See CYLINDER SECTION for Breakdown): 129 1683760 1 Platform Level Cylinder Assembly E45AJ & M45AJ 129 1683924 1 Platform Level Cylinder Assembly E40AJP & M40AJP
REV
C C
3 2
ITEM PART NUMBER QTY DESCRIPTION
134 3422669 1 Pin 135 3311805 1 Locknut 1/2in-13NC 136 0641607 1 Bolt 3/8in-16NC x 7/8in 137 3422792 1 Pin 138 Ref Jib Assembly Options (Includes Items 1-27): 138 0259440 1 Jib Assembly E45AJ & M45AJ 138 0259441 1 Jib Assembly E40AJP & M40AJP 139 0641810 1 Bolt 1/2in-13NC x 1 1/4in 144 0100011 AR Loctite #242 (Not Shown)
