FIGURE 3 4. MAIN BOOM ASSEMBLY (E40AJP & M40AJP

FIGURE 3-4. MAIN BOOM ASSEMBLY (E40AJP & M40AJP)

FIGURE 3-4. MAIN BOOM ASSEMBLY (E40AJP & M40AJP)

ITEM PART NUMBER QTY

DESCRIPTION

0801225 Ref MAIN BOOM ASSEMBLY (E40AJP & M40AJP) 1 0801224 1 Base Weldment 2 0801226 1 Weldment, Fly Boom 3 1683911 1 Cylinder, Telescope (See CYLINDER SECTION for Breakdown) 4 1180353 1 Carrier, Power Track 4 7006139 AR 1ft Repair Section 4 7006151 AR Feet, Mounting 4 7006152 AR Pin Kit (Includes 1 Link Pin, 4 Different Size Washers and 1 Retaining Ring) 5 4846180 1 Weldment, Push Tube 6 3340878 10 Pad, Wear 7 3340884 4 Pad, Wear 8 4070864 12 Shim 18 Gauge 9 4070863 8 Shim 11 Gauge 10 3340886 2 Pad, Wear 11 3422804 1 Pin 12 3760115 2 Ring, Retaining 13 0641606 30 Bolt 3/8in-16NC x 3/4in 14 0961948 2 Bearing 15 0641605 8 Bolt 3/8in-16NC x 5/8in 16 0641608 22 Bolt 3/8in-16NC x 1in 17 0641818 4 Bolt 1/2in-13NC x 2 1/4in 18 4761800 4 Lockwasher 1/2in 19 1670959 1 Cover 20 4761400 3 Lockwasher 1/4in 21 3311401 3 Nut 1/4in-20NC 22 4711600 12 Flatwasher 3/8in 23 3311605 4 Locknut 3/8in-16NC 24 0100011 AR Loctite #242 (Not Shown) 25 0961950 2 Bearing 26 3520082 2 Plug (Not Shown) 27 4070997 2 Shim 16 Gauge 28 4070998 2 Shim 18 Gauge

REV

2-B
