FIGURE 6-11. TELESCOPE (MAIN BOOM) HYDRAULIC DIAGRAM

FIGURE 6-12. TELESCOPE (TOWER BOOM) HYDRAULIC DIAGRAM (GAS AND DIESEL MACHINES)

ITEM PART NUMBER QTY DESCRIPTION REV

2791489 Ref TELESCOPE (TOWER BOOM) HYDRAULIC DIAGRAMS D 1 2751006 1 Hose 2 2220473 2 Fitting, 90 3 2220507 1 Fitting, 90 4 2220741 1 Fitting 5 2220635 1 Fitting, Tee 6 2751111 1 Hose 7 2220446 2 Fitting 8 2751155 1 Hose 9 2220604 3 Fitting, Tee 10 2220703 2 Fitting, 90 11 4640037 1 Valve, Check 12 2750911 1 Hose 13 2220280 1 Fitting, Nipple 14 2220609 2 Fitting, Reducer 0100020 AR Sealant, Pipe

FIGURE 6-12. TELESCOPE (TOWER BOOM) HYDRAULIC DIAGRAM (GAS AND DIESEL MACHINES
