FIGURE 2 16. GENERATOR INSTALLATION 110V (DEUTZ
ITEM PART NUMBER QTY
0250229 Ref GENERATOR
DESCRIPTION
1 4843410 1 Weldment, Generator Mount 2 Ref Pulley Options: 2 3580111 1 Pulley (Prior to August 1991) 2 3580134 1 Pulley (August 1991 to June 1995) 3 2460011 1 Generator and Control Box Assembly 3A 7012558 1 Generator 3A 7026199 1 Armature with Slip Rings 3A 7012513 4 Cap, Brush Holder 3A 7020108 4 Brush 3A 7020109 4 Holder, Brush 3A 7012514 1 Fan 3A 7020110 1 Bell, Front 3A 7020111 1 Bell Rear 3A 7020190 2 Bearing 3B 7003657 1 Box, Control Ref Note: Replacement 110V Control Box comes with 2 std
Receptacles p/n 4460190. Optional Industrial Twist Lock Receptacles p/n 4460027 must be ordered separately.
3B 4360542 1 Breaker, Circuit (was p/n 7020194) 3B 2920162 1 Lamp 3B 7020191 1 Switch, Toggle 3B 3520028 1 Plug, Hole 3C 2420203 1 Voltmeter (was p/n 7010699) 3D 3580134 1 Pulley 4 3251476 1 Decal - Generator 5 1060012 AR Cable 12/4 (Prior to August 1994) 6 4460134 1 Connector (Prior to February 1991) 7 4460023 1 Connector Terminal 8 7027887 1 Key, Woodruff 9 0100011 AR Loctite #242 (Not Shown) 10 4751500 1 Flatwasher 5/16in 11 4761500 2 Lockwasher 5/16in 12 0361815 1 Arm, Adjustable 13 0701414 1 Bolt, Metric 14mm x 30mm 14 0701012 2 Bolt, Metric 10mm x 25mm 15 0480059 1 Belt 16 3580158 1 Pulley 18 Ref Bolt Options: 18 0641508 3 Bolt 5/16in-18NC x 1in (Prior to May 1991) 18 0681510 2 Bolt 5/16in-18NC x 1 1/4in (Grade 8) (May 1991 to Present) 19 3311501 1 Nut 5/16in-18NC 20 0901633 1 Bracket, Box Mount 21 4300068 2 Stud (Welded on Part) 22 4751400 4 Flatwasher 1/4in 23 4761400 4 Lockwasher 1/4in 24 3311401 4 Nut 1/4in 25 0641406 2 Bolt 1/4in-20NC x 3/4in 26 4812000 2 Flatwasher, Metric 10mm 33 0681610 2 Bolt 3/8in-16NC x 1 1/4in (Grade 8) (June 1992 to Present)
REV
L
ITEM PART NUMBER QTY
DESCRIPTION
34 4761600 2 Lockwasher 3/8in (June 1992 to Present) 35 4751600 2 Flatwasher 3/8in (June 1992 to Present)
