FIGURE 6-11. HYDRAULIC DIAGRAM - TOW

FIGURE 6-11. HYDRAULIC DIAGRAM - TOW

FIGURE 6-11. HYDRAULIC DIAGRAM - TOW

ITEM PART NUMBER QTY DESCRIPTION

Ref HYDRAULIC DIAGRAMS 2791788 Ref 5ft 9in Frame 2791789 Ref 6ft 6in Frame 16 2220605 2 Fitting, Tee 17 2220468 3 Fitting, Straight 18 Ref Hose Options: 18 2751391 1 5ft 9in Frame 18 2751410 1 6ft 6in Frame 19 Ref Hose Options: 19 2751428 2 5ft 9in Frame 19 2751010 2 6ft 6in Frame 21 2220385 1 Fitting, Tee 22 2220619 1 Fitting, Reducer 23 2220635 1 Fitting, Swivel 24 2220609 1 Fitting, Reducer

REV

B B
