FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION
ITEM PART NUMBER QTY
DESCRIPTION
Ref WHEEL DRIVE INSTALLATIONS 0254710 Ref Wheel Drive Installations 30electric U/L Models 0257551 Ref Wheel Drive Installations 30electric Non-U/L Models
REV
8 1
0254485 Ref Wheel Drive Installations 35/40electric U/L Models
8 0257549 Ref Wheel Drive Installations 35/40electric Non-U/L Models 1 0254485 Ref Wheel Drive Installations n35/n40electric U/L Models Prior to
October 1994
8 0255111 Ref Wheel Drive Installations n35/n40electric U/L Models Oct 1994
to Present
3 0257548 Ref Wheel Drive Installations n35/n40electric Non-U/L Models 1 0254599 Ref Wheel Drive Installations 45electric U/L Models 7 0257550 Ref Wheel Drive Installations 45electric Non-U/L Models 1 1 Ref Drive Hub Assembly Options: 1 2780185 1 Drive Hub Assembly 30electric (See DRIVE HUB ASSEMBLY for Breakdown) 1 2780198 1 Drive Hub Assembly 35/40/45electric (See DRIVE HUB ASSEMBLY for Breakdown) 1 2780198 1 Drive Hub Assembly n35/n40electric Non-U/L Models (See DRIVE HUB ASSEMBLY for Breakdown) 1 2780198 1 Drive Hub Assembly n35/n40electric U/L Models Prior to October 1994 (See DRIVE HUB ASSEMBLY or Breakdown) 1 2780206 1 Drive Hub Assembly n35/n40electric U/L Models October 1994 to Present (See DRIVE HUB ASSEMBLY for Breakdown) 2 0920090 2 Drive Brake Assy (See DRIVE HUB ASSEMBLY for Breakdown) 3 3160186 2 Drive Motor Assembly 3 2900811 2 Repair Kit (Includes All Bearings, Brushes, Springs and Wavy Washer 1 Per Motor) 3 7012546 2 Field Coil Kit (1 Per Motor) 4 3321801 18 Nut 1/2in-20NF 4 0100011 AR Loctite #242 5 4711800 22 Flatwasher 1/2in Narrow 6 0641811 4 Bolt 1/2in-13NC 7 0641608 8 Bolt 3/8in-16NC x 1in 8 4711600 8 Flatwasher 3/16in Narrow 9 4761600 8 Lockwasher 3/16in 10 0630016 AR Bolt, Wheel Options: 10 0630016 10 Bolt, Wheel 30electric 10 0630016 12 Bolt, Wheel 35/40/45electric 11 3990053 1 Sensor, Tach Drive 11 7012609 1 Boot, Rubber 12 4761800 4 Lockwasher 1/2in 13 3790240 2 O-Ring 14 2220273 2 Fitting, Reducer (SN 32280 to Present) 15 2180819 2 Vent, Breather (SN 32280 to Present) Ref TIRE AND WHEEL INSTALLATION OPTIONS - MODEL
30electric
0252430 Ref Tire and Wheel Assembly (Foam-Filled) 0252349 Ref Tire and Wheel Assembly (26x7x20 Non-Marking) 101 0252431 4 Tire and Wheel Assembly (Foam-Filled) (Sold as an Assembly Only) 101 4520139 4 Tire, Replacement 101 4520151 4 Tire and Wheel Assembly (26x7x20 Non-Marking) (Sold as an A
ITEM PART NUMBER QTY
DESCRIPTION
Assembly Only) (SN 43598 to Present) Ref Note: Assemblies may require ballast/foam filling to
manufacturer's specifications prior to installing on a machine. Refer to Operation and Safety or Service and Maintenance Manuals.
Ref Purchase individual tire and/or rim only if able to foam fill
tire and wheel assembly, otherwise, purchase complete assembly.
Ref TIRE AND WHEEL INSTALLATION OPTIONS - MODEL
35electric, 40electric & 45electric
0256837 Ref Tire and Wheel Assy (G78-15 Foam-Filled/6in Rim) 0254866 Ref Tire and Wheel Assy (LT215/85R16 Foam-Filled/8in Rim) 0254120 Ref Tire and Wheel Assy (22x6x16 Solid) 0254874 Ref Tire and Wheel Assy (6.50x16 Solid Non-Marking) 0254121 Ref Tire and Wheel Assy (22x6x16 Solid Non-Marking) 151 0256836 4 Tire and Wheel Assy (G78-15 Foam-Filled/6in Rim) (Models 35electric & 40electric) 151 4520184 4 Tire, Replacement 151 0254865 2 Tire and Wheel Assy (LT215/85R16 Foam-Filled/8in Rim) (Models 35electric & 40electric) 151 4520265 4 Tire, Replacement (p/n was 4520156) 151 0253784 4 Tire and Wheel Assy (ST225/75R15 Foam-Filled/8in Rim) (Models 35electric, 40electric & 45electric) 151 4520148 4 Tire, Replacement 151 4520198 4 Tire and Wheel Assy (7.50x15x20 Static Conductive/ 8in Rim) (Model 45electric) 151 4520154 4 Tire and Wheel Assy (22x6x16 Solid) (Models 35electric & 40electric) 151 4520155 4 Tire and Wheel Assy (22x6x16 Solid Non-Marking) (Models 35electric & 40electric) 151 4520159 4 Tire and Wheel Assy (6.50x16 Solid Non-Marking) (Models 35electric, 40electric & 45electric) Ref Note: Assemblies may require ballast/foam filling to
manufacturer's specifications prior to installing on a machine. Refer to Operation and Safety or Service and Maintenance Manuals.
Ref Purchase individual tire and/or rim only if able to foam fill
tire and wheel assembly, otherwise, purchase complete assembly.
Ref HUBCAP INSTALLATION (OPTIONAL) 0252754 Ref Use on Model 30electric 0253864 Ref Use on Model 35electric/40electric with 8in Rim/ Pneumatic
and 8in Rim/ Foam-Filled Tires. Use on Model 45electric with 8in Rim /Foam-Filled Tires. REV
B B
0256832 Ref Use on Model 35electric/40electric/45electric with 6in Rim. 0254155 Ref Use on Model 35electric & 40electric with Solid Tires. B 201 Ref Hubcap Options: 201 1670633 4 Hubcap Model 30electric 201 1670633 4 Hubcap Model 35electric/40electric with 8in Rim/ Pneumatic & 8in Rim/ Foam-Filled Tires. Use on Model 45electric with 8in Rim /Foam-Filled Tires. 201 1670808 4 Hubcap Model 35electric/40electric/45electric with 6in Rim 201 1670692 4 Hubcap Model 35electric & 40electric with Solid Tires. 202 Ref Bolt Options: 202 0630455 8 J-Bolt 5/16in-18NC - Model 30electric 202 0630465 8 J-Bolt 5/16in-18NC - Model 35electric/40electric with 8in Rim/
ITEM PART NUMBER QTY
DESCRIPTION
Pneumatic and 8in Rim/Foam-Filled Tires. use on Model 45electric with 8in Rim/Foam-Filled Tires. 202 0630513 8 J-Bolt 5/16in-18NC - Model 35electric/40electric/45electric with 6in Rims 202 0641518 8 Bolt 5/16in-18NC x 2 1/4in - Model 35electric & 40electric with Solid Tires 203 4761500 8 Lockwasher 5/16in 204 Ref Nut, Acorn 5/16in-18NC Options: 204 3300356 8 Nut, Acorn 5/16in-18NC Model 30electric 204 3300356 8 Nut, Acorn 5/16in-18NC Model 35electric/40electric with 8in Rim/ Pneumatic and 8in Rim/Foam-Filled Tires. use on Model 45electric with 8in Rim/Foam-Filled Tires. 204 3300356 8 Nut, Acorn 5/16in-18NC Model 35electric/40electric/45electric with 6in Rims 204 Not Required 0 Nut, Acorn 5/16in-18NC Model 35electric & 40electric with Solid Tires 205 Ref Nut 5/16in-18NC Options: 205 3311501 8 Nut 5/16in-18NC Model 30electric 205 3311501 8 Nut 5/16in-18NC Model 35electric/40electric with 8in Rim/ Pneumatic and 8in Rim/Foam-Filled Tires. use on Model 45electric with 8in Rim/Foam-Filled Tires. 205 3311501 8 Nut 5/16in-18NC Model 35electric/40electric/45electric with 6in Rims 205 Not Required 0 Nut 5/16in-18NC Model 35electric & 40electric with Solid Tires
