Dustextractor

Field lamp

This is fitted to the operator's platform so light is thrown on the cutterbar (Fig. 100). Dust extractor

A suction-blower with dust suction pipe assists to keep dust away from operator's platform (Fig. 101). Publications regarding all auxiliary equipment will besupplied on request by the producer or his agents.

.Tables

Flat Sieves

CLAAS Part No. Size of hole Used for

671 598.0 5.6mm 0 ( 7/32 in.) Rye, Wheat, Winter Barley 671 596.0 12 mm 0 ( 1/2 in.) Wheat, Millet, Beet Seed, Turnip Seed, Barley, Lupine, Rye, Field Peas, Spinaeh, Durra, Sorghum, Milo 671 597.0 16 mm 0 ( 5/8 in.) Barley, Wheat, Field Beans, Dwarf Beans, Peas, Peas with Oats, Oats, Maize, Beet Seed, Rice, Soy Beans, .Sunflowers

674 150.0 674 151.0 2.5mm 0 ( 3/32 in.) Poppy Seed, Sesame 4.5mm 0 ( 3/16 in.) Clover, Poppy Seed, Flax, Spinaeh, Rape Seed, Sesame

671 595.0

6 mm 0 ( 1/4 in.) Rape Seed, Clover, Caraway Seed, Flax, Radish Seed, Mustard, Seradella, Spinaeh, Lucerne, Sesame 674 152.0 9 mm 0 ( 3/8 in.) .Spring Barley, Lupine, Rye, Wheat, Vetch, Turnip Seed, Millet 674 674 674 153.0 154.0 155.0 20 25 30 mm mm mm 0 0 0 ( (1 (1 3/4 3/16 in. in.) in.) } Maize, Broad Beans

Special sieves

674 156.0 14 mm 0 ( 9/16 in.) Depressed 674 157.0 16 mm 0 ( 5/8 in.) Depressed 674 158.0 18 mm 0 ( 11/16 in.) Depressed 673903.0 Frogmouth sieve With long lips To replace

Lower sieve Lower sieve Upper or lower sieve Upper sieve

Above sieve recommendations are based on our experiences. Each harvesting condition, however, requires the selection of a sieve, which is best suited for that particular condition.
