Hestra product catalogue

Inspiring shop fittings that promote sales

Shopinteriors and fittings are more than practical storage solutions for products – they are also a key part of a store’s brand. With smart, appealing fittings, a store can become more attractive and inspire more customers to make purchases. At Hestra, we have extensive experience in helping retailers create the perfect store environment.

It is over 120 years since Natanael Petersson founded Hestra Inredningar and created Hestra’s first interior fittings. Since then we have become one of the leading shop fitters in the Nordic region, and we strive continuously to remain at forefront of the industry.

We help you throughout the project

Our dedicated project teams are put together ahead of each project A dedicated project manager has overall responsibility, and a project coordinator is always on site with detailed information about your orders and deliveries. An architect, designer, order processor and sourcing manager are linked to the project team, and contribute their expertise to ensure you are provided with high-quality fittings that promote sales in your store and enhance your brand.

CONCEPT DEVELOPMENT

A completely new concept or updating of an existing one? Collaboration between the architect and the designer ensures we find the right style and expression, transforming your vision into reality. We always use the latest tools in VR, AR and 3D visualisation to support optimal decisions through the concept development process.

LAYOUT

Get help from our professional store decorators. We design stores every day of the year, and we have extensive experience in a wide range of industries. The right layout leads to better sales, it’s that simple!

MANUFACTURING

We have our own comprehensive manufacturing facility in Småland with production in wood, sheet metal and tubing. We also have a wide network of subcontractors who help us make a reality of the product you want, regardless of materials or volumes.

LOGISTICS

Here at Hestra, we store, pack and dispatch large amounts of interior fittings every day to countless towns and cities across Northern Europe. With up-to-date equipment and extensive experience, we’ll find the right logistics solution for you.

INSTALLATION

With our long experience, we install interior furnishings and fittings all over Northern Europe. We work with our own installers and a wide network of experienced external partners.

WE ARE WHERE YOU ARE

With our own staff in Sweden, Norway, Denmark and Finland, the Nordic region is our base. But we also operate in the rest of Europe and the world.

Choice of colour

Colour is something that virtually everyone has an opinion about. Different concepts require different colour schemes. Think about what you want to achieve in terms of both the interior and the ambience you aim to create.

The easiest way to ensure harmonious surroundings is to choose colours from the same scale on the colour wheel. Then work with contrasts and signals to achieve the desired effect. The interior fittings play an important role here. Bear in mind that dark surfaces require more light, so take care to choose the correct level of lighting. With the wrong choice of lighting, light-coloured surfaces can be dazzling. Small colour swatches often do not convey the intense, dominating effect created by large expanses of colour. Feel free to contact us at Hestra for a complete interior design proposal with solutions for colour, light and function. Being a customer should be simple.

What are NCS and RAL?

NCS, the Natural Colour System, is an international colour notation system, based on how people see colour. It is used in fields such as architecture and design. Each colour in the NCS system has its own code, for example S 1050-Y50R. The ‘S’ indicates NCS second edition. The first two figures in the notation (10) indicate the percentage of blackness. The second two figures (50) indicate the percentage of chromaticness. The last figures indicate the hue. Y stands for Yellow, R for Red, G for Green and B for Blue.

RAL is originally a German colour system and stands for Reichs Ausschuss für Lieferbedingungen. The RAL system is now used internationally. There are just over 200 colours in the RAL Classic range, and even more in the RAL Design range. RAL codes do not specify how colours should be mixed, although these days they are organised systematically.

357 GREEN BEIGE, MATT TEXTURED

176 BEIGE, MATT TEXTURED

444 BEIGE, MATT TEXTURED

125 SPARKLING GREY, TEXTURED

237 BEIGE, MATT TEXTURED

375 RED, MATT TEXTURED

559 BLUE, MATT TEXTURED

142 DARK GREY, MATT TEXTURED

553 BLACK, MATT TEXTURED

Most of our products are stocked in white-010, and many are also stocked without a surface finish and can be coated to order.

Choosing the right materials

We know the value of choosing the right materials to ensure results that are both appealing and practical. This makes it important to understand the properties and possibilities of the various materials. The shop fit tings we produce meet strict criteria for wear resistance, practicality and appearance. If you would like to create your own concept, our architects are ready to assist you..

Interior fittings straight from Småland

Hestra specialises in producing store fittings that meet customers’ unique needs and requirements. Our entire production is tailored toward offering highquality store concepts with precision and attention to detail.

With constantly updated know-how and a comprehensive fleet of machinery, we can offer customers complete solutions. At our production facility we saw, mill, edge mould, treat and put together our wood products, and we bend, weld and punch and laser cut our sheet metal and tubing items.

Our aim is to deliver high-quality interior fittings that exceed our customers' expectations. We work hard to offer fast, efficient logistics solutions, which means our customers can rest assured that their products will be delivered on time and according to their requirements.

We have solid industry knowledge and ample experience of unique projects. Quality and precision are key factors for us, and we always strive to deliver optimal solutions to our customers’ requirements. Thanks to our offering, customers can rely on us for on-time delivery of high-quality fittings that are tailored to their needs and strengthen their brand.

Working with nature

At Hestra, we are proud of our work with sustainability and environmental management. We have long understood the vital importance of taking care of our planet. We believe our commitment plays a small but crucial role in creating a more sustainable future, and we are constantly striving to reduce our environmental impact.

We have in-house production in Sweden, both for wood and metal. At our production facilities, we can guarantee the quality of every step of the manufacturing process. We also reduce

transport distances and help minimise both our own and your climate impact.

By using waste heat from a nearby company, and by having solar panels on the roof and our own wind turbines for green electricity production, we are largely self-sufficient in terms of energy. Moreover, our future aim is for all the energy we consume to be produced by us. We can proudly say that we are doing everything we can to reduce our use of fossil fuels.

Needless to say, we are also environmentally certified according to ISO 14001.

Seven tips for a successful shop interior

UNDERSTAND YOUR CUSTOMERS

Before planning your store interior, make sure you have a clear picture of your customers and what they’re looking for in your store. This will help you choose the optimal interior fittings and create an atmosphere that inspires customers to make purchases.

BE FLEXIBLE

It’s important to be able to adapt your store fittings to the season, campaigns and other factors. Be prepared to make changes to the fittings to keep your store up-todate and relevant.

ELEVATE YOUR BRAND

Shop fittings should strengthen your brand and create a cohesive experience for customers. The colour scheme, choice of materials and design should reflect your brand identity.

CHOOSE THE RIGHT LIGHTING

Lighting can be used to highlight products and create the right mood in your store. Choose lighting that complements your store's style and creates an inviting atmosphere.

CREATE MOVEMENT

Shop fittings with the right layout guide customers through the store and encourage them to explore the products. Create a layout for your store that is clear and easy to understand, and think carefully about where the goods are positioned. Use signage to guide customers.

SMART CHOICE OF COLOUR

Colour can create different moods in the store. Choose colours that suit your brand and the style of your interior, and that highlight your products. Through strategic colour choices, aim to create a visual hierarchy in the store where some areas are highlighted more than others.

FOCUS AREA

Create a focus area in your store by highlighting a specific product or service. Use a combination of lighting, colour and signage to attract customers’ attention and increase sales of that product or service. This can also help create a unique element in your store that people remember and makes them come back.

The largest range of basic shop fittings in the Nordic region

We sometimes create fittings that are entirely unique for a customer. However, in many of the stores we build, we create concepts based on our extensive basic range. To this, we add details and colours that enhance your concept and create a look and style that distinguishes your store from other store chains.

We collaborate with our customers to understand their specific needs and visions, in order to create a store interior that not only works well, but also reflects their unique brand identity. This catalogue presents a large part of our basic range. Please get in touch if you have questions or comments. We’ll help you find the right solution for your store.

Counters 47 series

An attractive, functional counter is a key part of a successful store interior, and we have excellent counters to offer our customers.

Our 47 series is a range of high-quality counters that can easily be adapted to different store concepts. These counters are characterised by great flexibility and high-quality detailing, such as noise-reducing, self-closing drawers. The drawers, shelves and other accessories can be easily combined and moved. The counters are delivered fully assembled.

ENDLESS POSSIBILITIES:

Wide variety of countertops and edgings

Plenty of accessories

Various front designs

Fitted with adjustable feet and ready-prepared for cabling.

Bases are made of brushed aluminium laminate as standard.

1. Cashier counter, low 600

With 1 fully opening drawer with soft close and 1 movable shelf Length 602 mm

Depth 635 mm Height 944 mm 47 06 60

2. Cashier counter, low 800

With 1 fully opening drawer with soft close and 1 movable shelf Length 802 mm

Depth 635 mm Height 944 mm 47 08 60

3. Cashier counter, low 1200

With 1 fully opening drawer with soft close and 2 movable shelves Length 1186 mm

Depth 635 mm Height 944 mm 47 12 60

4. Cashier counter, low 1800

With 1 fully opening drawer with soft close and 3 movable shelves Length 1770 mm

Depth 635 mm Height 944 mm 47 18 60

5. Outer corner counter, low broken 45° Length 374+374 mm Depth 635 mm

Height 944 mm 47 45 60

6. Outer corner counter, low, straight 90°

Length 780+780 mm Depth 635 mm

Height 944 mm 47 90 66

7. Cashier counter, high 600

With 1 fully opening drawer with soft close and 1 movable shelf Length 602 mm

Depth 635 mm Height 1104 mm 47 06 70

8. Cashier counter, high 1200

With 1 fully opening drawer with soft close and 2 movable shelves Length 1186 mm

Depth 635 mm Height 1104 mm 47 12 70

9. Cashier counter, high 1800

With 1 fully opening drawer with soft close and 3 movable shelves Length 1770 mm

Depth 635 mm Height 1104 mm 47 18 70

10. Outer corner counter high broken 45° Length 374+374 mm Depth 635 mm

Height 1104 mm 47 45 70

11. Outer corner counter, high, straight 90°

Length 780+780 mm Depth 635 mm

Height 1104 mm 47 90 76

Wide choice of materials

We offer a wide choice of materials for the countertops, ends and fronts of our counters. This allows you to create a unique counter that will blend perfectly into your store environment. Our standard range is presented here, and has been carefully selected to cater to most needs. If you would like more information or have specific requests, feel free to contact one of our sales representatives. We will help you find the perfect combination of materials for your needs and requirements.

Fronts and end panels

Countertops

Black Vulcano-738

Navarra Ash-745

White-171

Acacia-083

Grey Twist-086

Light grey-005

Sanremo Oak-684

Dark grey-004

Cento-756

Oak-H327-084

Caviar Black-755

ERGONOMIC COUNTERS

Create a more ergonomic workplace with our heightadjustable counters. In the retail sector, it is common for many employees to work at a single workplace behind the cashier counter. A height-adjustable counter helps to prevent back, neck and shoulder problems caused by an incorrect working position over a long period of time.

1. Cashier counter, universally adjustable height

1200

With 1 fully opening drawer with soft close and 1 movable shelf Length 1186 mm Depth 635 mm

Height 944-1144 mm 47 12 62

2. Cashier counter, universally adjustable height

1800

With 1 fully opening drawer with soft close and 2 moveable shelves Length 1770 mm Depth 635 mm

Height 944-1144 mm 47 18 62

3. Information counter, universally adjustable height

1200

Length 1186 mm Depth 635 mm Height 944 mm

Countertop height 644-944 mm 47 12 82

4. Information counter, universally adjustable height

1800

Length 1770 mm Depth 635 mm Height 944 mm

Countertop height 644-944 mm 47 18 82

1. Wrapping counter 1200 With 1 shelf, wrapping paper holder 400 mm and 570 mm, and waste drawer with soft close Length 1186 mm Depth 635 mm Height 944 mm 47 12 61

2. Wrapping counter 1800 With 1 shelf, wrapping paper holder 400 mm and 570 mm, and waste drawer with soft close Length 1770 mm Depth 635 mm Height 944 mm 47 18 61

3. Information counter, high 1200 Length 1186 mm Depth 635 mm (600/100) Height 737/1104 mm 47 12 72

4. Information counter, high 1800 Length 1770 mm Depth 635 mm (600/100) Height 737/1104 mm 47 18 72

5. Display counter, low Grooves on front for hangers, brochure racks, etc With 1 movable shelf Length 602 mm Depth 635 mm (437mm) Height 944/1417 mm 47 06 63

6. Display panel for low counter For mounting on front of counter Grooves for hangers, brochure racks, etc Width 605 mm Height 1140 mm 47 06 64

7. Collection counter With stainless steel countertop Length 602 mm Depth 614 mm Height 420 mm 47 06 40

8. Sales stand 1 drawer, door and 2 movable shelves Base cabinet in white 010 or black 114, countertop in speckled black 154 or mid-grey twist 086 Height 1050 mm Width 1100 mm Depth 600 mm Sales stand, right 40 08 65

1. Column protector Zinc For mounting on front of counter

4. Cable passage Ø80 mm Grey 49 12 61 White 49 12 61-010 Black 49 12 61-114

5. Wrapping paper holder For fitting to underside of countertop/shelf

8. Glass hood Glass hood for display on counter 47 45 45

9. Dumper bin for cashier counter Grey black Fixes to countertop with screws Triangular dumper bin for displaying products on cashier counter 47 06 65-553

2. Cover cap Dark grey 49 03 14-004 White 49 03 14-010

Black49 03 14-114

3. Cable passage Ø60 mm

Grey 49 12 60

White 49 12 60-010

Black 49 12 60-114

Chrome 49 97 64

6. String holder For fitting to underside of countertop/shelf 70 16 54

7. Pull-out keyboard shelf White. For fitting to underside of countertop. Depth 310 mm

Length 485 mm 47 06 55-010

Divider for the above dumper bin Fists the above dumper bin 47 06 66-553

Coupling screw For connecting counter modules together 49 90 51

OPTIMUM USE OF THE CHECKOUT AREA

The area around the cashier desk and the store entrance shape customers’ opinion of a store. It’s crucial for this area to have a clear vision style and project the right feel. The cashier desk is an excellent sales space that can be used for new products, small items with a high turnover rate, and seasonal goods. Replace the products at regular intervals to ensure customers find something new every time they visit.

1. Desk, universally adjustable height Length 1771 mm Depth 724 mm Height 1150 mm

Worktop height 735-1145 mm 47 18 77

2. Desk Adjustable height 780–1180 mm Two lengths

Desk top speckled black -154, Acacia -083 or light grey twist -086 Front edge screen available as an accessory Delivered knock-down

Desk top 1828 x 826 mm 42 13 48

Desk top 1400 x 826 mm 42 13 44

Silver-coloured frame 680x1180 mm 42 00 29-2

3. Chair High With wheels, footrest, black faux leather seat and backrest Height adjustable 635–815 mm 50 90 20-111

Standard height With wheels Seat and backrest in black faux leather Adjustable height 50 90 38-111

4. Standing chair Padded seat Height adjustable 510–840 mm 54 99 31

5. Folder shelf, open

6. Folder shelf with doors

7. Folder shelf with doors

8. Drawer unit with wheels Dark grey 3 drawers with soft close Width 250 mm Depth 400 mm Height 550 mm 47 25 40-004

9. Drawer unit with wheels 3 lockable drawers. Width 400 mm. Depth 600 mm. Height 550 mm. Grey. 42 00 31

10. Bar/standing table White tabletop and grey base Ø650 Height 1080 mm 55 80 10

11. Bar stool Hay Hee, wire Standard colour black-111, although also available in white, grey, rust, beige and racing red Height 750 mm 55 80 11-111

Choose ready-made standard products and combine them any way you want.

– Fast, smart and convenient!

Hestra 1000

The system that offers infinite potential to vary and change. To sell, you need to be seen. You also need to be able to reconfigure your store quickly and simply. Our basic Hestra 1000 fittings are designed to provide maximum flexibility, regardless of your sector. The products are stocked in white -010, but can also be ordered in many other colours.

With Hestra 1000 you get stable, high-quality shop fittings at an advantageous price. The design makes it easy to supplement and reconfigure your store interior. Year in, year out.

Hestra 1000 is based on 600 and 900 mm modules. Depending on your needs and use, you can make adaptations to enhance functionality.

IT’S ALL IN THE DETAILS

The key to creating a salespromoting, brand-enhancing store environment is to make all the details work together to achieve a greater impact. It’s not rocket science, but it does increase sales.

The system is dimensioned to offer optimal strength and robustness It also offers reassurance for the future. Thanks to our standardised measurements, you can combine Hestra 1000 with parts from the rest of our range to great advantage.

Your customers will enjoy spending time in a customised store with effective displays – and their desire to buy will increase accordingly!

HESTRA 1000

A completely free-standing fixture that is easy to assemble. No need for bolts or screws. Simply hook everything together. Any unevenness in the floor can be compensated for with our adjustable feet. The smart design gives you maximum stability and flexibility when you rearrange your store layout.

DYNAMIC DISPLAYS

Using a combination of modules measuring 300, 600 and 900. Use 900 shelves at the bottom, attract attention with the 600 module, and generate added sales with the 300 module.

1A. Wall panels perf. metal

600 module Height 2100 21 21 60-010

900 module Height 2100 21 21 90-010

Inner corner, Height 2100 21 21 65-010

Outer corner, Height 2100 21 21 70-010

For upright 2500 21 23 90-010

1B. Wall panels plain metal

300 module, Height 2100 20 21 30-010

600 module Height 2100 20 21 60-010

900 module Height 2100 20 21 90-010

Inner corner, Height 2100 20 21 65-010

900 module for upright 2500 20 23 90-010

1C. Lattice wall panel, metal White, 873 x 2100 mm 25 21 90-010

Fittings for lattice wall panel, metal 23 00 10-802 (4 fittings per wall panel plus 1 pc 23 09 00-802).

2A. Wooden panels

Select codes ending in 114 for black and in 010 for white DL Plain black DL, 600 module Height 2100 20 21 69-114

Plain black DL, 900 module Height 2100 20 21 99-114

Plain black DL, Inner corner Height 2100 20 21 79-114

2B. Frontwall wood

Grooved wooden panel Strengthened with aluminium profiles. Select codes ending in 114 for black DL and in 010 for white DL

FW white DL, 300 module, Height 2100 62 21 32-010

FW white DL, 600 module, Height 2100 62 21 62-010

FW white DL, 900 module, Height 2100 62 21 92-010

FW white DL, Inner corner, Height 2100 62 21 72-010

3. Frontwall metal, between uprights

Slat height 96 mm, 22 pcs required per module, for upright height 2300 mm

Front panel 600 White 60 06 10-010

Front panel 900 White 60 09 10-010

Front panel inner corner White 60 05 10-010

Suspension profile, L=2208 mm, assembled with distancing stays, 2–3 pcs required per module 60 23 00-48

Distancing stays not included!

4A. Wall bracket

Used for screwing upright to wall Adjustable

Wall distance up to approx 60 mm 19 00 01-802

Wall distance up to approx 300 mm 19 00 00-802

4B. Wall bracket/Upright bracket

Hooks into rear perforation on upright 19 00 20-802

Used in combination with the above wall bracket

4C. Wall bracket

Round plate L 70mm

Zinc 190021-802

Grey-black 190021-553

White 190021-010

5. Distancing stays for wall panels

300 module 23 02 75-000

600 module 23 06 00-000

900 module 23 09 00-000

For outer/inner corner panels 23 06 50-000 (3 distance stays per module are required)

6. Wall upright Steel tubing, white lacquered as standard Available with or without foot

25 x 50 x 2.5 mm

Height 2100 mm I without foot 10 21 01-010

Height 2100 mm L with foot 480 mm 10 21 51-010

Height 2300 mm I without foot 10 23 01-010

Height 2300 mm L with foot 480 mm

10 23 51-010

Height 3600 mm I without foot 10 36 01-010

25 x 70 x 2.5 mm

Height 2300 mm L with foot 480 mm

10 23 70-010

Height 2500 mm L with foot 480 mm

10 25 70-010

Height 3600 mm I without foot 10 36 02-010

7. Rack, corner 90°. can be connected

Height 2300 mm Without foot 10 23 90-010

8. Base feet, white.

For 330 shelf, 280 mm 19 09 33-1-010

For 430 shelf, 380 mm 19 09 43-1-010

For 530 and 600, shelf 480 mm 19 09 53-010

For 600 shelf, 555 mm 19 09 55-1-010

For 270 and 530 shelf, 750 mm 19 09 75-1-010

9. Set of stays, white

Can be used instead of panels

Set of stays, 600 module Height 160 mm

23 05 75-010

Set of stays 900 module Height 160 mm

23 08 75-010

10. Corner connector

Each 90° outer corner requires 3 pcs 19 00 02-802

11. Top cover 900 mm Secures wall panels

25 x 50 23 09 95-010

25 x 70 23 09 97-010

1. End system

stable and flexible end solution that provides considerable freedom to select the height and width of an end module Requires uprights, distancing stays, skirting boards and top covers on the wall panels to the rear 900 mm

Upper beam, 900 module 28 09 01-010

Lower beam, 900 module 28 09 02-010

Upper beam with bear grip 900 mm, white 81 13 08-010

Select I-uprights, panels, etc

NOTE! Don’t forget to secure with top cover when loaded For 25 x 50 use 23 09 95, for 25 x 70 use 23 09 97

2. Profile frame Decorative strip to frame your Hestra 1000 wall

Installed with mounting glue or self-drilling screws

White, 38 x 70 x 3000 mm 19 00 65-010

Mounting plate for attaching to top of upright

19 00 67

Supplementary parts

3. Upright extension

6. Panel

Plain panel that can be combined with an upright extension Height 1000 mm, cc 900 20 09 90-010

Height 698 mm, cc 900 20 07 90-010

7. Extension panel

Lattice panel in metal that can be combined with an upright extension Height 698 mm, cc 900 25 07 90-010

Standards are delivered in desired lengths Contact a sales representative for more information

4. Upright expansion

To be combined with I-upright

25 x 50 for desired length 19 00 07-802

25 x 70 for desired length 19 00 10-802

5. Blind corner

For use as support when building wall fittings from a

corner Easy to cut to size in situ

8. Adjustable foot

1. Front skirting Height 190 mm, dark grey

300 mm for L/T-upright 57 03 10-004

600 mm for L/T-upright 57 06 00-004

900 mm for L/T-upright 57 09 00-004

600 mm for I-upright 57 06 01-004

900 mm for I-upright 57 09 01-004

Skirting board, inner corner 45°

For 280 mm foot 57 03 04-004

For 380 mm foot 57 03 03-004

For 480 mm foot 57 03 01-004

For 555 mm foot 57 03 02-004

2. End skirting

Height 190 mm, dark grey

End skirting boards for 25 x 50 upright.

Left, L-upright with feet 280 mm 57 03 90-004

Right, L-upright with feet 280 mm 57 03 91-004

Left, L-upright with feet 380 mm 57 04 90-004

Right, L-upright with feet 380 mm 57 04 91-004

Left, L-upright with feet 480 mm 57 05 90-004

Right, L-upright with feet 480 mm 57 05 91-004

Skirting board, outer corner 45°, feet 480 mm

57 10 01-004

Skirting board, outer corner 90°, feet 480 mm

57 08 00-004

End skirting boards for 25 x 70 upright

Left, L-upright with feet 480 mm 57 05 92-004

Right, L-upright with feet 480 mm 57 05 93-004 Left, L-upright with feet 555 mm 57 05 94-004 Right, L-upright with feet 555 mm 57 05 95-004 Skirting board, outer corner 45°, feet 480 mm 57 10 04-004

3. Skirting drawer Made from sheet metal in grey and fitted with wheels Placed under bottom shelf, providing extra storage space

Divider for skirting drawer, depth 480 mm 57 05 10-803

4. Wall upright White lacquered Screwed to wall or beams

Height 1612 mm 10 16 02-010 Height 2188 mm 10 23 02-010 Height 2600 mm 10 26 02-010

5A. Wall upright

x 30 x 2 mm 2 slits for a suspension rail Length 2188 mm 10 23 05-010

5B. Suspension rail

2000 mm 10 23 07-010

CANOPIES FOR COMMUNICATION

A canopy can be an excellent way to highlight your brand concept. Smooth, profiled, level or angled? Bright or muted colours? Adapt your choice to your business concept or product range. Frame it. Light it. Present it!

1. Flush sheet metal canopy

White lacquered Height 200 mm Install directly on the upright or combine with an image frame

600 mm 59 06 20-010

900 mm 59 09 20-010

1800 mm 59 18 20-010

Canopy inner corner, 2 x 45° 59 06 65-010

Canopy end Depth 700 mm 59 07 20-010

Canopy bracket Requires 1 pc/screw 59 70 20-010

Lighting fixture. Requires 2 pcs/fitting. 59 70 22-010

Stabilisation stay, galvanized steel

900 mm 59 09 21-803

1800 mm 59 18 21-803

2. Lighting box

Arched lighting box for easily exchangeable graphics Tilted for optimal viewing angle Lighting box LED 15 Watt

Lighting box 287x894 mm 51 30 31-010

3. Image frame height 500 mm

900 module Front graphic dimensions

898 x 500 mm 51 05 90-010

600 module Front graphic dimensions

598 x 500 mm 51 05 60-010

Inner corner Angled Front graphic dimensions

650/518 x 500 mm 51 05 65-010

Plastic front for image frame

900 x 500 mm 51 15 90

600 x 500 mm 51 15 60

Inner corner height 500 mm 51 15 65

Fillings for image frames height 500 mm

module 885 x 490 mm 51 03 96-010 600 module 585 x 490 mm 51 03 95-010

Inner corner 639, 5 x 510,5 x 490 mm 51 03 97-010

Fillings for image frames height 500 mm 900 module 885 x 490 mm 51 03 96-010

4. Image frame height 350 mm

900 module Front graphic dimensions

898 x 350 mm 51 09 35-010

600 module Front graphic dimensions

598 x 350 mm 51 06 35-010

Inner corner Angled Front graphic dimensions

650/558 x 350 mm 51 35 65-010

Plastic front for image frame

900 x 350 mm 51 19 35

600 x 350 mm 51 16 35

Inner corner height 350 mm 51 45 65

Fillings for image frames

Height 350 mm 900 module

885 x 340 mm 51 03 94-010

Height 350 mm 600 module

585 x 340 mm 51 03 85-010

Inner corner height 350 mm

639 5 x 550 x 340 mm 51 03 86-010

Image frames (images 3 and 4) to be positioned level (5°) or angled (20°). For filling with background graphics (referred to here as filling) with a thickness of up to 4 mm, or graphics at the front with a thickness of up to 6 mm. For thinner front graphics, use a plastic front.

5. Top sign 740 x 150 mm With graphic holder, white, for top cover incl. fittings. Graphic dimensions 740 x 148 mm, thickness up to 3 mm 51 74 16-010

Plastic front Support for thin graphics 51 74 17

6. Light fitting LED Osiris White lacquered 600 mm 51 09 76

900 mm 51 09 72

1800 mm 51 09 71

On/Off cord Osiris for light fitting, 2 5 m� 51 04 00 Extension cord 2 m 51 09 73

7. Lighting canopy LED Anubis White lacquered 600 mm 51 09 77-010

900 mm 51 09 78-010

1800 mm 51 09 79-010

On/Off cord 3000 mm. 51 09 81

Bracket for Anubis 700 mm Angled upwards Left/right 51 09 95-010

700 mm Straight Left/right 51 09 96-010

Light plate, LED

350 x 900 mm suitable for image frame 510935 51 35 90

Transformer for up to 6 LED panels 51 35 91

Portal - front uprights

These front uprights can be installed directly on an existing Hestra 1000 fitting without the need to dismantle anything.

The system comprises an upper and lower stay, a front upright and a top rail, and can be built in 900- and 1800 sections.

Front uprights and top rails can ideally be fitted with LED strips to illuminate the merchandise.

IMPORTANT TO KNOW:

• The bottom shelf must always be at least one size deeper than the shelves above it. For example: With a 530 bottom shelf, the depth of the other shelves in the section must be max. 430 mm.

• If lighting is to be used, the driver kit and extension cable must be specified. One 75W driver can be used for a maximum of five 900 sections. One extension cord per driver must also be specified (for the last front upright in each driver group).

• If using a 2486 mm upright, a front upright extension (224mm) can be used.

1. Front upright for 2300 upright

Grey-black

Front upright (incl lighting) 2071 mm

80 86 35-1-553

Front upright (excl lighting) 2071 mm

80 86 35-553

2. Front upright extension, for 2500 upright

Grey-black

Extension 224 mm 80 86 36-553

3. Top rail

Grey-black

For 900 section (incl lighting) 80 86 45-1-553

For 900 section (excl lighting) 86 04 88-553

For 1800 section (excl lighting) 80 86 60-553

4. Upper stay

Grey-black

For 430 bottom shelf 80 86 64-553

For 530 bottom shelf 80 86 65-553

For 600 bottom shelf 80 86 66-553

5. Lower stay

For 430 bottom shelf 80 86 68-553

For 530 bottom shelf 80 86 69-553

For 600 bottom shelf 80 86 70-553

6. Acrylic sign for S-hook

600 mm 80 86 14

900 mm 80 86 15

1200 mm 80 86 28

S-hook 80 86 09-553

7. Sign (hooked)

Grey-black

600 mm 80 86 10-553

900 mm 80 85 16-553

1200 mm 80 86 25-553

Driver kit 75 W 51 35 91

120 W 51 35 95

Cable ties (3 pcs/driver) 49 89 10

Cable ties (2 pcs/driver) 49 93 90

Extension cord / Inline connector

Black

Extension cord 2 metres 86 04 95-SV

Extension cord 1 metre 80 86 44-SV

Inline connector 2 sockets 51 35 94

CHOOSE THE RIGHT FLOOR PANEL

Floor panels are available in a range of materials and designs. Choose the optimal function and visual expression. Easy to hook into place between uprights.

Layout suggestion 1

Layout suggestion 2

Layout suggestion 3

Layout suggestion 4

1A. Floor panel, perforated 900 module Height 1400 mm 21 14 90-010 900 module Height 1000 mm 21 10 90-010

Corner 663 x 1400 mm 21 14 70-010

600 module Height 1400 mm 21 14 60-010 900 module Height 1600 mm, only for upright (12 18 70) and (11 18 70) 21 16 90-010

1B. Floor panel, plain 900 module Height 1400 mm 22 14 90-010

600 module Height 1400 mm 22 14 60-010

900 module Height 1000 mm 22 10 90-010

Outer/inner corner, 663 x 1400 mm 22 14 70-010

900 module Height 1600 mm, only for upright (11 18 70) and (12 18 70) 22 16 90-010

2A. Floor panel, wooden Plain panel, white-010, black-114 900 module Height 1400 mm 62 14 99-114

2B.

panel, Frontwall

2 panels are required per module, plus 2 distancing stays 23 09 00-000 or 23 06 00-000.

3. Frontwall metal, between uprights

Mounting frame, 900 module 60 14 90-48

Mounting frame, 600 module 60 14 60-48

Fits 50-70 uprights 1460 mm or 1620 mm in height

Frontwall metal, front panel

Slat height 96 mm, 13 pcs are required for height

1460 mm, 14 pcs for height 1620 mm Stocked in white (-010)

900 module 60 09 10-010

600 module 60 06 10-010

Milled panels Floor panel, milled horizontally Available in white -010 and white stained ash -066

4. Floor-standing upright (I) White lacquered steel tubing 25 x 50 x 2 5 mm

Height 1110 mm ( I ) without foot 11 11 00-010

Height 1460 mm ( I ) without foot 11 14 00-010

Height 1620 mm ( I ) without foot 11 16 00-010

5. Floor-standing upright (L) 25 x 50 x 2 5 mm for 530/600 mm deep shelves

Height 1110 mm (L) with foot (480) 11 11 50-010

Height 1460 mm (L) with foot (480) 11 14 50-010

Height 1620 mm (L) with foot (480) 11 16 50-010

25 x 70 x 2 5 mm

Height 1460 mm (L) with foot (480) 11 14 70-010

Height 1460 mm (L) with foot (555) 11 14 71-010

Height 1620 mm (L) with foot (480) 11 16 70-010

Height 1620 mm (L) with foot (555) 11 16 71-010

Height 1834 mm (L) with foot (480) 11 18 70-010

6. Floor-standing upright (T)

25 x 50 x 2 5 mm

Height 1460 mm (T) with foot (2 x 280) 12 14 30-010

Height 1460

9. Top cover for perforated and plain metal panels

600 module 23 00 60-010

900 module 23 00 90-010

Outer/inner corner 23 00 65-010

Metal top cover for Frontwall panel

900 module 60 01 61-010

600 module 60 01 60-010

10. End skirting boards for T-uprightHeight 190 mm, dark grey

Skirting board for 25 x 50 upright.

END PANELS

Perforated panels, cc 600 och

900 mm and plain combination panels, 300-600-900 mm. Hestra’s end panels make it easier to create attractive and interesting end panel displays. Choose according to your needs from the standard accessories in the catalogue. Used correctly, the end panels are among the most important display areas in the store

For upright 1460 mm

Plain 900 mm, 300-600-900 27 14 90-999-1

Plain 600 mm 27 14 60-999-1

For upright 1620 mm

Plain 900 mm, 300-600-900 27 16 90-999-1

Plain 600 mm 27 16 60-999-1

For upright 1460 mm

Perforated 900 mm 27 14 91-999-1

Perforated 600 mm 27 14 61-999-1

For upright 1620 mm

Perforated 900 mm 27 16 91-999-1

Perforated 600 mm 27 16 61-999-1

Accessories for 300 module

Hanger bar 300 mm 53 03 00-801

Adjustable metal shelf, incl brackets Length 300 mm Depth 300 mm 39 03 30-010

Metal panel with a wooden back

For upright 1460 mm

Plain 900 mm 26 14 90-999

Plain 600 mm 26 14 60-999

For upright 1620 mm

Plain 900 mm 26 16 90-999

Plain 600 mm 26 16 60-999

For upright 1460 mm

Perforated 900 mm 26 14 91-999

Perforated 600 mm 26 14 61-999

Perforated 200 mm 26 14 21-999

For upright 1620 mm

Perforated 900 mm 26 16 91-999

Perforated 600 mm 26 16 61-999

Perforated 200 mm 26 16 21-999

Grooved Frontwall

For upright 1440 mm

Frontwall 600 mm 26 14 67-999

For upright 1620 mm

Frontwall 600 mm 26 16 67-999

All end panels on this page are stocked in white, but are also available to order in other colours. Contact us!

Glass expander fitting (for 70 upright) 25 x 50 mm, zinc 51 00 67-802 Glass clip 51 00 68

Wheel fitting

Start section single 190036-010

Mid-section double 190037-010

4. End shelf Curved For 900 module end panel Perforated end shelf with integrated skirting boards Depth 430 mm 39 30 43-010

5. End podium Curved For 50 upright 530 mm bottom shelf

6. End skirting For

7. Top shelf bracket

10. Fittings for glass panel Attached with expander fittings and glass clips in floor panel. Ideal for creating visibility in aisles. Contact us for customised solutions and price

11.

1. End panels Metal panel

2. End panels

3. End panels

At Hestra we have gathered together all areas of expertise. Project management, conceptdevelopment, production and logistics. Feel free to drop by and see our display.

Hestra has been creating sales-promoting shop fittings since 1900. Our ambition is to always be at the forefront in helping our customers to design stores that sell. This applies regardless of whether you have one store or a hundred, fully customised fittings or a concept created using our standard range.

Pay us a visit. We know all about stores.

1. Top sign

740 x 150 mm With graphic holder, white, for top cover incl. fittings. Graphic dimensions 740 x 148 mm, thickness up to 3 mm 51 74 16-010

Plastic front Support for thin graphics 51 74 17

2. Product category sign

900 x 150 mm Folded transparent plastic for thin graphics Graphic dimensions 895 x 150 mm 51 00 06

Sign holder for 25 x 50 mm upright White 51 00 05-010

3. Display panel with grooves for graphics

Graphic dimensions 898 x 110 mm

Thickness up to 2 mm 51 09 11-010

Graphic dimensions 898 x 210 mm

Thickness up to 4 mm 51 19 21-010

Graphic dimensions 898 x 297 mm

Thickness up to 5 mm 51 09 29-010

Plastic front for display panel Support for thin graphics

4. Placard holder for upright

Easy to attach to top of upright With hooks for plastic pocket For upright top length 500 mm 25 x 50 mm 55 50 10-802

Plastic pocket 500 x 700 mm 55 50 07

5. L-placard holder

Single, for pallet display Moveable hooks make it easy to use a hole punch and printer Height adjustable 1900–2300 mm. Zinc finish 802 Placard holder for placard up to 50 x 70 cm

Length 500 mm 55 50 01-802

Plastic pocket 500 x 700 mm 55 50 07

6. T-placard holder

Double, for pallet display Moveable hooks make it easy to use a hole punch and printer For placard width max 50 cm Height adjustable 1900–2300 mm. Zinc finish 802. Length 2 x 500 mm 55 50 03-802

Plastic pocket 500 x 700 mm 55 50 07

7. Triangular sign

200 x 200 mm Held in place with upright tubing

51 20 20-010

Upright tubing 25 x 50 mm

51 03 50-801

Upright tubing 25 x 70 mm

51 03 70-801

Height 300 mm

Height 300 mm

8. Sign holder with magnet

Pack of 10 Portrait

A6 55 50 86

A5 55 50 85

A4 55 50 84

A3 55 50 83

9. Sign holder for shelf

With magnet Portrait

A6 55 50 96-133

10. Sign holder

Adjustable height Comes complete with foot

Zinc 802

A4 55 50 04-802

A5 55 50 05-802

11. Sign holder with magnetic foot

For A5/A5 excl acryl 55 50 09-125

12. Sign holder with round foot

For A6/A5/A4 excl acryl 55 50 12-802

Acrylic for sign holder

A4 55 05 08

A5 55 05 09

A6 55 05 06

13. Placard holder gripper

Two grippers per placard required

900 mm 55 50 22-010

600 mm 55 50 23-010

Max. graphic thickness 8 mm.

Suitable for height of 350 mm +/- 32 mm.

1. Wooden shelf White Pack of 5

Length 900 mm

Depth 270 mm 37 09 27-010

Depth 330 mm 37 09 33-010

Depth 430 mm 37 09 43-010

Depth 530 mm 37 09 53-010

Depth 600 mm 37 09 60-010

Length 600 mm

Depth 270 mm 37 06 27-010

Depth 330 mm 37 06 33-010

Depth 430 mm 37 06 43-010

Depth 530 mm 37 06 53-010

Depth 600 mm 37 06 60-010

Wooden shelf for 2-grip bracket, Length 900 mm. For light products

4. Brackets for wooden shelf

Made of 2.5 mm thick metal with white epoxy finish. The brackets can be positioned level or angled 20°

Sold in packs of 10 pairs

Depth 210 mm left 38 00 21-010

Depth 210 mm right 38 00 22-010

Depth 270 mm left 38 00 27-010

Depth 270 mm right 38 00 28-010

Depth 330 mm left 38 00 33-010

Depth 330 mm right 38 00 34-010

Depth 430 mm left 38 00 43-010

Depth 430 mm right 38 00 44-010

Depth 530 mm left 38 00 53-010

Depth 530 mm right 38 00 54-010

Depth 600 mm left 38 00 60-010

Depth 600 mm right 38 00 61-010

Bracket for wooden shelf, 2 grips, for light products For shelf 37 39 33 och 37 39 43

Depth

2. Wooden shelf outer corner 90° White For 25 x 50 mm upright

Depth 530 mm 37 27 53-010

3. Wooden shelf inner corner 45° White

Depth 430 mm 37 21 43-010

Depth 530 mm 37 21 53-010

5. Bottom fixture for wooden shelf

Two pcs are required per section when the wooden shelf is mounted at the bottom against the foot of the upright 38 30 01

6. Bottom fixture, rear Only needed on one-sided start module 38 30 02

7. Bottom reinforcement stay for wooden shelves For heavy loading 38 90 01

8. Base cabinet with soft-close hinges

Doors Drawers with soft-close, fully expanding mechanism for optimal ergonomics and function

White laminate, aluminium fittings. For 900 module. Depth 530 mm.

A. With doors Height 755 mm 41 09 32-1-010

B. With 1 drawer Height 404 mm 41 09 15-1-010

C. With 2 drawers Height 404 mm 41 09 30-1-010

Feet for base cabinet 4 pcs required/base cabinet

59 82 27

Bottom fixture for base cabinet included.

9. Label display strip for laminate shelf

Easy to fix to shelf edge with adhesive tape.

900 x 26 mm, angled 55 92 26

900 x 39 mm, angled 55 92 39

600 x 26 mm, angled 55 62 26

900 x 26 mm, straight 55 92 27

900 x 39 mm, straight 55 92 25

Coloured strip for label display

Height 26 mm Length 900 mm

Blue 55 90 00

Red 55 90 01

Green 55 90 02

White 55 90 03

Black 55 89 96

10. Rubber matting

Grey Prevents damage to shelves from heavy or sharp products and provides a non-slip surface

900 x 530 mm 56 49 53

900 x 600 mm 56 49 60

AIRY, ELEGANT? FUNCTIONAL AND EFFECTIVE!

Choose between plain or perforated. Glass, wire, wood/laminate or sheet metal. Use the product as your starting point. Decide what you want to achieve. Volume displays or signals using individual items. Once you have a clear idea, select the shelf that best meets your needs.

INFLUENCE YOUR CUSTOMERS

The majority of consumers are creatures of habit. Most of the time we act, think and purchase in the same way we’ve always done. There’s nothing strange about that, but in a store we have every opportunity to influence customers’ behaviour and direct their attention.

4. Bracket for wire and sheet metal shelf Made of 2.5 mm steel with an epoxy finish. The brackets can be positioned level or angled 20°

bracket Pack of 20 White

600 mm 38 14 60-010 Bracket, angled upwards

430 mm Adjustable 0°, 10°, 20° 38 11 43-010

5. Cover sheet for basket shelf Perforated Prevents small items from falling through

7. Wire shelf, dense.

Elegant wire shelf with denser wire spacing of c/c 10 mm, which keeps smaller products in place Pack of 10

Length 898 mm Depth 430 mm 32 39 43-118

Length 898 mm Depth 530 mm 32 39 53-118

8. Label display strip for wire shelf.

Pack of 25

870 x 26 mm

870 x 26 mm Blue 55 90 26-514

870 x 26 mm Red 55 90 26-316

Coloured strip for label display

10.

basket

9. Front guard and divider Wire spacing

11.

20

12. Label holder With

870 x 39 mm

SHEET METAL SHELVES

Modern metal shelves are fantastic! Choose a perforated shelf for low weight, attractive looks and easy cleaning, or plain shelves for a strong, solid, harmonious look. There are plenty of accessories available for both styles, allowing you to optimise your shelf display Contact us. We’ll be happy to help you optimise your project.

4. Bottom fixture For sheet metal and wire shelf 4 pcs required per

38 30 07-1-802

For sheet metal and wire shelf For shelf depth 600 mm (foot depth 480 mm) 2 pcs required per shelf + 2 pcs (38 30 07-1-802) 38 30 08-1-802

5. Brackets for wire and sheet metal shelf

Made of 2 5 mm lacquered steel The brackets can be positioned level or angled 20° White Pack of 20

Depth 200 mm 38 10 20-010

Depth 270 mm 38 10 27-010

Depth 330 mm 38 10 33-010

Depth 430 mm 38 10 43-010

Depth 530 mm 38 10 53-010

Depth 600 mm 38 10 60-010

Depth 430 mm 10° upward angle 38 11 43-010

Bracket for extra heavy loads

Depth 530 mm 38 14 53-010

Depth 600 mm 38 14 60-010

11. Front and rear rails. White Also stocked in silver (colour no. 118).

12.

7. Label display strip, curved

1. Panel for fittings

Suitable for shelves with front edge guard

50 09 14-125

Shelf stop Incl wing nuts 83 01 69

2. Holder for silicone tubes

For placing on a wire or sheet metal shelf

384x214 mm Max 4 pcs on 900 shelf 80 19 03

3. Screw bar for sheet metal/wire shelf

Front drawer 39 09 20 -803

Divider 38 11 06-803

Brackets

Right for 330 mm deep shelf 38 11 02

Left for 330 mm deep shelf 38 11 03

Right for 430 mm deep shelf 38 11 04

Left for 430 mm deep shelf 38 11 05

4. Roller holder

For hanging on wire shelf

Large 260 mm 32 00 02

Medium 180 mm 32 00 03

Small 80 mm 32 00 04

5. Divider module with backward-tilting shelf For mouldings, rods, etc Shelf with rubber mat Hanger bar with adjustable divider Hanger bar 53 09 00-801

Divider 53 00 04-801

Shelf Backward-tilting 50 00 31-010

6. Stand for pipes and mouldings

Made of wire With compartments for displaying different products in front of each other in an easily accessible way

Two brackets are required (38 10 53) 900 x 530 mm 50 09 45-801 7.

DISPLAY YOUR WHOLE STORE

Few stores succeed in getting customers to explore the whole store. This is usually because the actual distance walked by the customer in the store is too short. With a carefully designed store layout, you can display most of your range while also encouraging customers to explore every corner of the store.

1. LED shelf lighting

Fits Hestra sheet metal shelves

Shelf lighting 600 51 16 71

Shelf lighting 900 51 16 70

Transformer for up to 5 shelf light fittings. 51 16 80

Vertical connection, 5-way 51 16 96

2. Glass shelf 8 mm fine-ground edges.

900 x 270 mm 34 09 27

900 x 330 mm 34 09 33

900 x 430 mm 34 09 43

Bracket for glass shelf, white lacquered 2 5 mm steel

Depth 270 mm left 38 20 27-010

Depth 270 mm right 38 20 28-010 Depth 330 mm left

38 20 33-010

Depth 330 mm right 38 20 34-010

Depth 430 mm left 38 20 43-010

Depth 430 mm right 38 20 44-010

Suction cup Two pieces/shelf bracket are required 38 20 01

3. Shoe shelf

For wire shelf and rail panels Silver-coloured 210 x 120 mm 53 21 13-118

4. Shoe shelf, adjustable in two positions. 900 x 340 mm, white 50 09 34-010

900 x 340 mm, grey 50 09 34-125

430

900 mm 39 19 43-802

2 brackets are required (38 10 43)

530 x 900 mm 39 19 53-802

2 brackets are required (38 14 53)

7. Wallpaper shelves in white lacquered sheet metal. Angle 25° 598 mm 71 21 25-010 Angle 60° 598 mm 71 21 60-010 Hanger for wallpaper samples 598 mm 71 20 01-010

8. Angled support for shelves Used to lift forward-facing shallow shelves and tilt them upwards, angled 20° 900 module Height 876 mm 10 06 06-010

9. Plant shelf Zinc-plated sheet metal

x

10. Book and media shelf Made of lacquered sheet metal 900 x 180 mm 39 09 22-010 600 x 180 mm 39 06 22-010 Bracket, right 38 00 02-010 Bracket, left 38 00 01-010

11. Media shelf Length 898 mm Depth 90 mm 70 30 61-010

1. Hanger bar with star-shaped holes

Chrome-plated rectangular tubing The star-shaped holes (18 or 12 holes) allow hangers and other fittings to be placed at a variety of angles.

900 mm, 18 holes 52 09 00-801

600 mm, 12 holes 52 06 00-801

2. Hanger for hanger bar with star-shaped holes

Zinc-plated circular-section metal Fits the hanger bar above

300 x 8 mm 52 03 08-802

400 x 8 mm 52 04 08-802

450 x 8 mm 52 04 58-802

3. Hanger for hammers

Length 280 mm 52 00 34-802

4. Heavyweight hanger

Solid hanger for heavy loads, made of chrome-plated

rectangular tubing 10 x 30 mm For bar, 52 series

Length 400 mm 52 04 30-801

Length 500 mm 52 05 00-801

5. Helmet holder For protective helmets and sports helmets For hanger bar, 52 series 52 00 06-801

6. Rail and hanger for grinding plates

Rail Length 900 mm 52 09 05-802

Hanger Length 200 mm 52 00 33-802

7. Tool hanger

Length 400 mm, Ø10 mm 52 04 00-802 Length 500 mm, Ø10 mm 52 50 10-802

Label display strip for hangers 24 x 80 mm 54 26 80

8. Display fittings, rolls

Roll holder, with brakes (A) 52 00 40-802

Top arch for 52 00 40 (B) 52 09 40-802

Label display strip 898 x 26 mm With adhesive

tape 55 92 27

Spring brake (C) 52 00 41-802

Roll holder 210 mm (D) 52 00 21-802

Roll holder 530 mm (E) 52 05 30-802

Shaft 197 x 22 mm 52 02 22-802

Shaft 247 x 22 mm 52 02 47-802

Shaft 297 x 22 mm 52 02 97-802

Shaft Telescopic model 610–900 mm (F)

52 60 60-802

Also suitable for a variety of helmets Can be angled

For hanger bar, 52 series 52 00 05-801

Holder, incl sign holder 52 55 00-802

Hoop for long items

398 mm 52 55 01-802

498 mm 52 55 02-802

Label display strip 210 x 76 mm

With double-sided adhesive tape 55 22 76

Sign holder with magnet A4 55 50 84

Shelf Backward-tilting 50 00 31-010

Height 1632 mm Depth 800 mm 83 60 30-802

For sleeping bags, blankets, etc Chrome-plated circular section metal Can be rotated 745 x

380 mm Requires 2 hanger bars, 52 series 52 06 10-801

For hanger bar, 52 series 52 03 04-801

9. Soft hat holder

10. Holder for long items

11. Holder for horse blankets and saddle blankets

Requires 2 hanger bars, 52 series

12. Sleeping bag holder

13. Garment bracket

4.

7.

8.

6.

1. Heavyweight hanger

Length 250 mm 85 22 37-133

Length 340 mm 85 22 36-133

2. Garment bracket

Made of flat metal. Holds 10 hangers. Bracket for hanger bar, 53 series Length 360 mm

Chrome 53 03 04-801

Grey textured finish. 53 03 04-125

3. Divider hanger 300 x 6 mm 53 23 06-801

4. Product clip

Product clip 100 st/box 55 00 16

5. Floodlight holder

Chrome-plated metal Can be universally adjusted sideways

Fits hanger bar, 53 series 53 00 01-801

6. Divider arch 670 x 370 x 10 mm 53 00 04-801

1. Hanger, single pack of 20

13 x 5 mm 54 00 14-802

80 x 5 mm 54 00 84-802

200 x 5 mm 54 02 04-802

200 x 6 mm 54 02 06-802

250 x 6 mm 54 02 56-802

350 x 8 mm 54 03 58-802

Hanger, single, welded on lower edge

300 x 6 mm 54 03 16-802

2. Hanger for label

Pack of 20

Length 200 mm

Plate 26 x 80 mm 54 02 05-802

3. Hanger with angled plate. For portrait label Pack of 20

250 x 6 mm 54 02 58-802

300 x 6 mm 54 03 59-802

Label holder for hanger 26 x 80 mm 54 26 80

4. Hanger with straight plate

For landscape label Pack of 20

300 x 4 mm 54 03 04-802

250 x 6 mm 54 02 57-802

300 x 6 mm 54 03 05-802

Label holder for hanger . Pack of 100.

26 x 80 mm 54 26 80

39 x 80 mm 54 39 80

5. Hanger with rocker holder

For landscape label Pack of 20

250 x 6 mm 54 52 57-802

300 x 6 mm 54 53 07-802

6. Hanger, double

Pack of 20

80 x 5 mm, double 54 30 85-802

140 x 5 mm, double 54 31 45-802

200 x 5 mm, double 54 32 05-802

250 x 5 mm, double 54 32 55-802

300 x 5 mm, double 54 33 05-802

Hanger, single, welded on lower edge

300 x 5 mm 54 23 15-802

7. Double hanger with straight plate. For landscape label Pack of 20

200 x 5 mm, double 54 42 05-802

250 x 5 mm, double 54 42 55-802

300 x 5 mm, double 54 43 05-802

Label holder for hanger

Pack of 100 26 x 80 mm 54 26 80

8. Double hanger with rocker holder

For landscape label Pack of 20

200 x 5 mm, double 54 52 05-802

250 x 5 mm, double 54 52 55-802

300 x 5 mm, double 54 53 05-802

Label holder for rocker hanger

Pack of 100 26 x 80 mm 55 26 80

9. White plastic end cover for hangers

Pack of 100

Ø 4 mm 54 00 02

Ø 6 mm 54 00 03

Ø 8 mm 54 00 04

Label holder for hanger

Pack of 50 For label 26 x 80 mm

80 x 123 mm 55 00 80

10. Hanger stop

Fits hanger Ø 4-8 mm 54 00 05

11. Hanger for screwdrivers

Length 300 mm 54 03 00-802

12. Label strips for hanger display.

Pack of 20

Support for label display strip Adjustable 55 91 00-802

Label display strip 885 x 26 mm 55 89 26

Label display strip 885 x 39 mm 55 89 39

13. Holder for compressed air tools

Length 70 mm 54 00 70-802

Length 110 mm 54 01 10-802

14. Holder for power saws

Includes holders for the cutting bar 54 00 18-802

15. Holder for small products

Contains 2 fittings� 54 00 17-802

16. Holder for helmets

Chrome 54 00 48-801

17. Holder for glasses

Zinc 54 00 47-802

18. Display panel

small 138 x 106 mm 21 00 01-010

Large 408 x 106 mm 21 00 02-010

EFFECTIVE DISPLAY

Hanger bar displays are highly ef fective. There are endless variation on this sales-promoting fitting. Choose according to the attachment, load and volume requirements. There is an almost unlimited range of combinations.

1. Shelf for circular saws 260 x 300 mm 75 25 01-120

2. Display shelf, large 300 x 300 mm 75 25 02-120

3. Display shelf, small 300 x 150 mm 75 25 03-120

4. Holder for angle grinders, large 248 x 80 mm 75 25 04-120

5. Holder for angle grinders, small 198 x 75 mm 75 25 05-120

6. Double hook for electric screwdrivers and tools Length 120 mm 75 25 06-120

7. Single hook for larger tools Length 120 mm 75 25 07-120

8. Cable holder, Ø 50 Length 200 mm 75 25 13-120

9. Strimmer and clearing saw holder 280 x 100 mm 75 25 14-120

10. Holder for hedge trimmers Length 160 mm 75 25 15-120

1. Perforated sheet metal panel

For

06 90-010

2. Display lattice

White lacquered 850 x 1750 mm 50 18 86-010

S-hook for hanging panels Chrome 51 00 25-801

Chain (price/metre) 55 90 08

S-hook for suspension 51 00 24

3. Panel for product coordination

Panel for displaying long products, e g threaded rods Combine with packs of washers and screw nuts Length 898 mm Height 898 mm Depth 182 mm 50 13 48-010

4. Castors

For simple moving of floor gondolas. Also available for rental

Castors 90 00 00-1 Lifting rod 90 00 01-1

5. Hanger for display lattice

Double White 200 x 4 mm 59 80 37-010

6. Rack for brochures, etc.

Made of wire Can be mounted on perforated metal panels or fixed to the wall with screws. Pack of 2. 240 x 1300 mm 10 A4 compartments (A)

50 13 24-801

240 x 390 mm 3 A4 compartments (B)

50 04 24-801

7. Added sales hanger with plate

Length 1130 mm 11 hooks 52 00 26-802

8. Display head

Ideal for displaying eyewear and headwear

Moulded styrofoam Fixes to shelf with screws

81 40 16

9. Sock display

Displays socks and supports Clear plastic fixes to shelf with screws. 81 40 17

10. Display panel

Grey perforated metal Great for displaying small items Hooks onto the uprights Can be grouped together Length 898 mm

Height 120 mm 51 39 12-118

Height 300 mm 81 40 65-118

11. Lower torso

For displaying underwear, trousers and tool belts

Moulded styrofoam Fixes to shelf with screws 81 40 18

12. Glove display

Shows the back and palm of gloves Posable fingers for a more vibrant impression. 81 40 62-118

hanging in front of each upright Hung forward-facing in the upright perforations Can be placed in front of an existing flat panel. 605 x 898 mm 21

Elegant fronts in natural anodised aluminium with lockable glass For mounting on bottom shelf or base cabinet Depth 485 mm Protects an entire 900 section against theft and highlights

merchandise

Upright height 2300 mm. For base cabinet. 41 09 25-010 Height 1961 mm 43 19 10-630

Upright height 1620 mm

Height 1400 mm 43 19 12-630

Upright height 1460 mm or upright height 2300 mm for base cabinet 41 09 32-010

Height 1225 mm 43 19 13-630

End panels in perf silver-grey sheet metal Easy to mount as start and end panels for grass fronts

Height 1961 mm right 43 19 20-133

Height 1961 mm left 43 19 21-133

Bracket for glass display case 2 pcs/glass display case front are required when end panel is not used

Right 43 19 26-133

Left 43 19 27-133

Glass top Used as a top cover for the glass fronts 43 19 35-133

Glass display case lighting, with LED fittings. 47 90 91

Base cabinet, see page 44

Glass display system incl rubber mat Lockable with

screws Width 900 mm

Depth 330 mm 50 10 33-010

Depth 530 mm 50 10 53-010

3. Free-standing glass display case, black

Length 600 mm Height 2000 mm

Depth 600 mm 47 06 20-111

Glass display case lighting 47 06 21-111

4. Hanging glass display case, black

Length 900 mm Height 900 mm

Depth 350 mm 47 90 90-111

Glass display case lighting 47 90 91-111

1. Glass display case fronts

2. Display shelf with glass top

A MAXI SOLUTION For strength and variety, choose Hestra Maxi.

A removable front upright absorbs and distributes the load effectively.

1. Wall upright

3. Wall panel

White-painted lattice Height 2100 mm 900 module 25 21 90-010

4. Wall panel Perforated 873 x 2100 mm 21 21 90-010

1. Floor-standing upright

5. Ceiling frame

mm White 23 27 60-010

(Can be equipped with 3 wire baskets 32 09 60-010

Length 1800 mm White 23 18 60-010

(Can be equipped with 2 wire baskets 32 09 60-010)

6. Sheet metal shelf

8. Bracket

For 555 mm support leg 38 10 61-010

For 480 mm support leg 38 10 51-010

9. Canopy

White lacquered For hooking onto front upright 2700 mm 59 27 20-010

1800 mm 59 18 20-010

10. Attachment for light fitting

2 pcs/light fitting are required. 59 70 22-010

11. End canopy Maxi Double White 51 24 18-010

Bottom fixture for sheet metal and wire shelf. 4

7. Wire shelf Silver-coloured

12. Front skirting

Length 900 mm 57 09 00-004

End skirting, double 57 11 03-004

End skirting, single, right 57 05 95-004

End skirting, single, left 57 05 94-004

13. Light fitting LED Osiris

White lacquered

900 module 26W 51 09 72

1800 module 50W 51 09 71

On/Off cord Osiris for light fitting, 2 5 m 51 04 00

Extension cord 2 m 51 09 73

2 attachments are required per light fitting. 59 70 22-010

14. Display panel

Small 138 x 106 mm 21 00 01-010 large 408 x 106 mm 21 00 02-010

1. End upright

Frame made of welded 50 x 50 poles For use in combination with appropriate Hestra 1000 fixtures.

Height 2486 mm 80 00 01-1Height 2998 mm 80 00 02-1

2. Wedge

Length: 130 mm 80 00 08

3. Shelf

Sheet metal shelf for placing on beams

Length 890 mm 80 00 10

4. Divider hanger

Beam grip Length 600 mm 80 00 16-801

5. Column protector

Screws into the floor around the poles. Includes bolt for locking end upright Height 150 mm 80 00 09

6. Top beam

For placing on top of Hestra 1000 upright

Top beam 70 upright

2 x 900 module Length 1794 mm 80 00 29

3 x 900 module Length 2694 mm 80 00 30

7. Beam 100 x 30 tubing Hooks onto frames and wedges into place

Max load-bearing capacity 450 kg/beam pair

2

are required

8. Skirting

Hooks onto front edge of end upright

Length 2699 mm 80 00 20 Length 1799 mm 80 00 21 Length 899 mm 80 00 22

9. Canopy

For hanging on front edge of end upright

Height: 200 mm

Length 2699 mm 59 27 20

Length 1799 mm 59 18 20

Length 899 mm 59 09 20

Attachment for light fitting. 2 pcs/light fitting are required 59 70 22-010

10. Light fitting LED Osiris White lacquered

11

12

11. Image frame

Height 350 mm 51 09 35

12. Angled rail shelf Power

White 898 x 630 mm 84 03 18-010

Grey 898 x 630 mm 84 03 18-125

POWERFUL AND INSPIRATIONAL!

In the new Power line, capacity and storage functions can be combined with exiting and inspirational displays.

The basis is the advanced Hestra 1000 System, used for new solutions and applications. The powerful base tubing has high load-bearing capacity, while the traditional design fixtures meet requirements for enhanced flexibility and a wide choice of combinations.

1. Front upright

For mounting on Hestra 1000 L- or T-upright Height 2902 mm 814243-1

2. Distancing stay

Galvanised metal 2 x 900 mm (A) 70 82 23

Galvanised metal 3 x 900 mm (B) 70 82 24

3. Upper sign profile

2 x 900 mm 814246

3 x 900 mm 814247

4. Lower sign profile Black

2 x 900 mm 814244

3 x 900 mm 814245

5. Filling for sign profiles Contact us for options

6. Crossbeam Black

7. Stay for 480 leg

Stay for use with 480 leg 814242

8. Universal stay Adjustable for 380/480/555 legs 814257

9. Light fitting LED Osiris White

CREATE VOLUME AND SPACE WITH VPR

Hestra VPR offers you the opportunity, with a minimum of effort, to give your store a feeling of volume and space. Fully compatible with our basic Hestra 1000 system and with excellent potential for signage and integrated lighting.

Hestra VPR is available in a range of colours.

1. End for budget shelf

White Set of screws included Depth 696 mm

Height 2268 mm 14 21 63-010 Height 1620 mm

14 16 63-010

Height 1620 mm Depth 800 mm 14 16 80-010

2. Cross stay

White Requires 2 pcs/module

Length 875 mm for 900 module 14 09 00-010

Length 1325 mm for 1350 module 14 13 50-010

SMART, SIMPLE CHOICE! Strength and simplicity. That sums up Hestra Budget. Few components and carefully considered basic functionality. Choose Hestra Budget for fittings that are highly effective without being seen.

3. Budget shelf, hung forward facing, with rear edge

Depth 630 mm Zinc

900 mm 14 09 63-802

1350 mm 14 13 63-802

Length 1350 mm Depth 800 mm 14 13 80-802

Distancing stay. For shelves 1350 mm 14 13 48 - 802

Divider. Height 120 mm 32 12 67-802

Label display strip. 1300 x 26 mm 55 91 26

4. Budget shelf without rear edge

900 mm 14 09 62-802

1350 mm 14 13 62-802

Divider for Budget shelf without rear edge

Height 120 mm 32 12 68-802

5. Front rail for Budget shelf 20 mm

For shelf 900 mm 14 09 20-802

For shelf 1350 mm 14 13 20-802

6. Display panel

Canopy. White C-profile.

1A.

1B. Wall upright

4. Gondola, perforated panel

7. End panel Frontwall White

8.

5. Gondola, Frontwall panel

9.

2.

3. Gondola without panel

12. Top sign with graphic holder

White DL Graphic dimensions 740 x 150 mm

Thickness up to 3 mm 63 30 71-010

13. Gondola top cover White DL 1200 x 250 mm 63 30 17-010

14. Bottom shelf

10.

15. Wooden shelf

16. Brackets for wooden shelf

White 330 mm left 38 00 33-010

White 330 mm right 38 00 34-010

White 430 mm left 38 00 43-010

White 430 mm right 38 00 44-010

Grey 330 mm left 38 00 33-125

Grey 330 mm right 38 00 34-125

Grey 430 mm left 38 00 43-125

Grey 430 mm right 38 00 44-125

1A. Fitting room, San Remo Oak Right-hanging Length 1170 mm Depth 1170 mm Height 2100 mm Incl 2 mirrors, 4 garment hooks

Door in fluted wood laminate. 80 87 24-553

1B. Fitting room bench, San Remo OakLength 800 mm Depth 270 mm Height 450 mm Wood laminate seat 80 87 25-553

Fitting room lighting LED panel 80 87 26-553

2.

8C.

Omni

An easier way to create appealing displays. Omni fittings are smart and simple with an essential, attractive look, offering countless display options for a wide variety of product areas.

The colour of the fittings is grey-black -553 (NCS 8500), and they come in two heights: a tall height for wall installation and a low height for floor installation. There are also two smart mobile units and a multifunctional display unit that makes the store more versatile and creates dynamic displays. A base cabinet with doors or drawers provides storage, with a wide range of accessories to meet all conceivable needs.

Choose Omni to optimise your display!

WALL FITTINGS

Tall wall fittings provide a wide range of options for creating a complete store interior.

1. End frame

Height 2486 mm 80 86 05-553

2. Top rail

4 pcs/section required

1200 mm 80 86 26-553

900 mm 80 85 01-553

600 mm 80 86 06-553

3. Front skirting

Can also be used as top sign

1200 mm 80 86 25-553

900 mm 80 85 16-553

600 mm 80 86 10-553

4. End skirting 80 85 17-553

5. Bracket 80 85 21-553

6. Metal shelf

If used as bottom shelf, there is no need for bracket 80 85 21

1200 mm 80 86 04-553

900 mm 80 85 22-553

600 mm 80 86 07-553

7. Wooden shelf, laminate, Acacia

If used as bottom shelf, there is no need for bracket 80 85 21

900 mm 80 86 30-083

600 mm 80 84 15-083

8. Shelf with rear edge

900 mm Can also be tilted 5°/10° with bracket 80 85 21 or hanger bar as described in point

12 80 86 08-553

9. Stepped shelf

Reversible 900 mm 80 86 52-553

10. Acrylic sign

2 S-hooks are required for 25x25 tubing

1200 mm 80 86 28

900 mm 80 86 15

600 mm 80 86 14

11. Base cabinet Incl anti-tip system

900 with drawers 808623-083

900 with doors 808622-083

12. Hanger bar

Used to tilt shelf 80 86 08, 35-55° Can also be used as a garment rail when hung on the front upright Length 900 mm Depth 150 mm 53 09 15-553

13. Display case Length 868 mm Depth 376 mm Height 568 mm 80 86 34-083

14. Back

2 backs are required per module, plus 2 S-hooks for 25x25 tubes and 2 S-hooks for connection Greyblack board

1200 mm (1160x1160 mm ) 80 84 17-738

900 mm (860x1160 mm ) 80 87 15-738

600 mm (560x1160 m ) 80 87 17-738

15. End cover

2 end covers are required per module, plus 2 S-hooks for 25x25 tubes and 2 S-hooks for connection Greyblack board

330 x 1160 mm 80 87 18-738

16. S-hook for 25x25 tubes

80 86 09-553

17. S-hook for connection Grey-black 77 30 09-436

75W 80 86 93

Metal clips with metal shelf With magnets 80 86 97

Wall bracket, round plate Length 70 mm 19 00 21-553

Wall bracket/Upright bracket

19 00 20-802

FREE-STANDING, WITH OR WITHOUT WHEELS

A low floor unit that displays items from both sides. This mobile unit offers greater versatility and opportunities for a vibrant, dynamic store interior.

TALL MOBILE DISPLAY TROLLEY

Trolley on wheels for versatile, mobile front-hanging and side- hanging displays. Merchandise is visible from both directions, creating an excellent focal point in-store or in a window display. Can be divided and equipped as needed using shelves or garment rails with width of 1200 mm.

Trolley, double, with wheels, in width of 600, 900 or 1200 mm.

1. End frame, double Height 1400 mm 80 85 20-553

2. Stay plate For use on alternate sections only

1200 mm 80 86 02-553

900 mm 80 86 16-553

600 mm 80 86 37-553

3. Wooden top shelf, double, Acacia For 900 section only

Start/end section80 86 31-083

Mid-section 80 86 32-083

Single module 80 86 33-083

4. End frame

900x1400 mm 80 86 39-553

5. Panel for end frame 900x1400 mm 80 86 40-553

6. Upright extension 128 mm 90 34 103-553

7. Display panel 900 mm 51 09 11

8. Mobile display trolley 1230x400x2000 Height 2000 mm plus wheels (approx 100 mm) For use with 1200 mm accessories 80 86 74-553

9 Garment rail/Hanger bar

For mobile display trolley 80 86 03-553

10, Wheels 75 mm

Black 4 pcs required for display trolley, 6 pcs required for double floor unit on wheels. Use screw M10x25 (item no 500291) (screws are not included) 49 10 75

11. Hanger bar

600 mm 53 06 00-553

900 mm 53 09 00-553

1200 mm 53 12 00-553

12. Heavyweight hanger

For hanger bar

250 mm 85 22 37-553

340 mm 85 22 36-553

13. Hanger For hanger bar

250 mm Double with straight plate 53 25 45-553

250 mm Double 53 22 54-553

250 mm Single 53 02 56-553

MULTI-FUNCTIONAL DISPLAY UNIT

Multi-functional display table on wheels, displays merchandise from both sides. Can be divided and equipped as needed using shelves or garment rails. A hanging shelf or signs can be added as optional accessories. Makes an ideal focal point in the store.

1. Display table

W 1272 L 900 mm H 2300 mm Wooden panel in Acacia 80 86 78-553

Accessories for display table:

2. Upright frame Requires 3 pcs 80 85 37-553

3. Bracket 330

2 pcs per shelf are required 38 10 33-553

4. Sheet metal shelf Length 600 mm Depth 330 mm 39 06 33-553

5. Hanging shelf Acacia Incl 4 suspension rods 80 84 16-083

Double wheels Ø50

See picture to the right Requires 4 pcs 49 10 62-111

Also use:

4 washers 90 33 474

4 screws MC6S M10x25 50 02 91

1. Frontwall

FRONTWALL

Hestra Frontwall is available in a wood or a metal finish.

Can be fixed to the wall with screws or hung on upright. Contact us for a good suggestion. See design of Frontwall to the right:

3. Frontwall metal, between uprights

576 x 2400 mm. With alu. profile in grooves. White DL 10

Black DL 60 24 02-114

Available to order in other colours (see page 7) and types of wood

2. Frontwall Metal for suspension profiles

Width Frontwall cc 96 mm

Length 900 x 104 mm 60 09 11-010

Length 1800 x 104 mm 60 18 11-010

On outside

Length 450 x 104 mm 60 04 10-010

Length 600 x 104 mm 60 06 11-010

Inner corner on outside

Length 671 x 104 mm 60 07 11-010

Narrow Frontwall cc 48 mm

Length 450 x 52 mm 60 04 10-52-010

Length 600 x 52 mm 60 06 11-52-010

Length 900 x 52 mm 60 09 11-52-010

Length 1800 x 52 mm 60 18 11-52-010

Inner corner on outside

Length 671 x 52 mm 60 07 11-52-010

Outer corner on outside

Length 745 x 52 mm 60 07 10-52-010

4. Wall base Grey Height 175 mm Length 1800 mm 60 20 17-004

5. Support strip for wall base No surface finish. Length 400 mm. 60 00 59-000

6. Cover strips

Inner corner 90° 20 x 20 mm 60 00 05-010

Outer corner

mm

8. Suspension profile for mounting between uprights For mounting directly to the wall or with distancing stays. Hestra 1000 fittings, 3 bars are required per 900 module, compatible with both 50 and 70 uprights

For upright 11 11 00 and 11 11 50

Length 056 mm for 11 / 22 panels 60 11 00-48

Length 1152 mm for 12 / 24 panels 60 13 00-48

Length 1248 mm for 13 / 26 panels 60 13 01-48

Length 1344 mm for 14 / 28 panels 60 14 00-48

Length 1444 mm for 15 / 30 panels 60 14 01-48

For upright 10 23 00, 10 23 51, 10 23 71

Length 2112 mm for 22 / 44 panels 60 22 01-48

Length 2208 mm for 23 / 46 panels 60 23 00-48

Length 2592 mm for 27 / 54 panels 60 26 01-48

Length 2688 mm for 28 / 56 panels 60 27 00-48

7. Mounting frame

For mounting between uprights, for Hestra 1000 floor fittings. Requires 1 frame per module. Frontwall can be assembled on both sides: Fits both 50 and 70 uprights Two hight options: 1460 mm and 1620 mm

900 module for 28 / 56 panels 60 14 90-48

600 module for 28 / 56 panels 60 14 60-48

1. Top cover for Frontwall frame

White 1 pc/mounting frame is required

900 module 60 01 61-010

600 module 60 01 60-010

2. Suspension profile

For mounting in front of uprights

Length 1248 mm For 13 panels 60 13 01-48

Length 1440 mm For 15 panels 60 14 01-48

Length 2112 mm For 22 panels 60 22 01-48

Length 2592 mm For 27 panels 60 26 01-48

3. Mounting fittings

For suspension profile. 2 pcs/section are required. 60 01 33

4. Floor support

For suspension profile. For heavy loading. 60 01 34

5. Frontwall upright (I)

With mounting profiles fitted on one or two sides. Available as I- and L-upright

Length 2292 mm One side FW (23 pcs) 61 23 00

upright

1. Hanger bar

2.

3.

4.

11. Tyre holder

dark grey 60 01 04-124

12. Wheel rim holder

Black rubber paint 60 01 05-109

13. Wheel rim stand

Zinc 60 01 12-802

14. Floodlight holder

Zinc 60 01 11-802

15. Bracket for Frontwall

White With larger attachment, 2 holes 60 00 02-010

5.

6.

16. Adapter, wall upright

White Allows accessories from the Hestra 1000 system to be used 60 00 39-010

17. Frontwall gondola

Height 1460 mm White DL With wheels Slots reinforced with aluminium profiles.

Length 1225 mm 63 30 45-010

Length 1825 mm 63 30 46-010

8. Label holder for rocker hanger 100 pcs/bag 26 x 80 mm 55 26 80

9. Hanger, double with label holder

Pack of 20 Ø 5 mm

Length 200 mm 60 42 05-801

Length 250 mm 60 42 55-801

Hanger with label holder

Length 250 mm 60 02 55-802

Label holder for rocker hanger

Pack of 100 26 x 50 mm 54 26 80

10. Heavyweight hanger

300 x Ø 18 mm 60 30 18-802

450 x Ø 18 mm 60 45 18-802

1. Frontwall glass shelves 900 x 270 mm 34 09 27-1 600 x 270 mm 34 06 27-1

Shelf fittings. For 270 shelf only. Requires 3 fittings per 900 module and 2 fittings per 600 module. 34 00 11

2. Front and rear guard for sheet metal shelf White

8. Frontwall bracket, angled

Not intended for upright Angled 20°

wire basket/sheet metal shelf

9. Frontwall bracket, straight

Not intended for upright For wire shelf/sheet

13. Book support

14. Brochure shelf

15A. Display shelf with label display strip White 300 x 150 mm 63 11 16-010

15B.

3. Divider for sheet metal shelf

19.

4. Wire divider White lacquered

11. Frontwall wooden shelf bracket

For wooden shelf Not intended for upright

5. Wire shelf

6. Front guard for wire shelf

7.

Width 200 mm Depth 150 mm

Height 100 mm 60 02 17-2

2. Large display basket

Width 310 mm Depth 180 mm

Height 160 mm 60 02 18-2

3. Rounded display basket

Width 180 mm Depth 130 mm

Height 200 mm 60 02 13

4. Brochure holder For A4 60 02

6. Media shelf Angled White

7. Brochure stand For A4 Stand-alone 60 02 10

1. Small display basket

holder

SMART WALLS!

The ideal screening solution that covers everything.

Ready to use as supplied or in combination with other Hestra systems. Choice of metal or wood. Choose between basic colours or customised for a supplementary charge.

Hestra 6-60

1. Upright, free-standing With lower flange and top. Length 1670 mm 64 00 02-999

Length 2054 mm 64 00 03-999

2. Base foot

Ø 480 mm 64 05 53 -999

3. Wheeled chassis For 6-60 upright

500 x 500 mm 64 00 32

4. Skirting base For 6-60 upright

600 x 600 x 150 mm 64 00 33-004

5. Display shelf

300 x 400 mm (A) 64 00 20-999

320 x 230 mm (B) 64 00 22-999

6. Hanger

Ø 6 mm Length 250 mm 64 00 86-801

Ø 8 mm Length 300 mm 64 00 85-801

7. Top sign A4 64 00 87-999

8. Round shelf Ø 800 mm Birch DL 64 01 51-082

Hestra 40-40

9. Upright 40 x 40 x 3800 mm 11 40 00

10. Ceiling fitting 100 mm 11 40 01 800 mm 11 40 02

11. Foot

For fixing to floor with screws. Ø 100 mm 11 40 03

12. Fixed wall fitting 100 mm 11 40 04

13. Adjustable wall fitting Max 700 mm A complete fitting set includes: 1 wall fitting 11 40 05

1 upright fitting 11 40 06 The fittings are inserted into each other and can be adjusted to the desired length

14. Shelf

1190 x 430 mm, c/c 600 mm 11 40 12-010

Can also be combined with other wooden and metal shelves c/c 600-900 mm

HESTRA 40-40

Hestra 40-40 can also be attached between the floor and the ceiling with the aid of ceiling attachments – perfect for display windows!

The design is ideal for light products.

Dumper and display units

With dumpers, podiums and baskets, you can create an exciting store display. These products give you endless opportunity to enhance the store experience.

1. Display table

display table

2. Nesting tables

Sleek and slender tables that can be arranged in groups or individually Legs in zinc-plated tubing

Zinc-plated perforated cover panels

800 x 600 x 800 mm 70 03 19-802

700 x 300 x 500 mm 70 04 21-802

600 x 300 x 185 mm 70 04 73-802

3. Acrylic box

Can be combined in many different ways: in display bins, on shelves and podiums, or on other activity and display surfaces Supplied with adhesive silicone pads 3 mm transparent acrylic 274 x 274 mm

Fits 600 x 600 mm display bin

Height 260 mm 55 80 15-000

Height 420 mm 55 80 16-000

The height of the base can be raised and lowered and can

Square White DL,

Width 600 mm Height 740 mm 55 80 80-010

Acrylic rim for dumper bin Transparent Width 565 mm Height 210 mm 55 80 55-000

Height 770 mm With perforations 25 x

Square 600 x 600 mm 55 76 60-010

600 x 600 mm, adjustable base with handle 55 76 61-010

Hexagonal

4. Dumper bin Dumper bin, with or without acrylic rim and boxes

excl rim and boxes

5. Dumper bins

25 mm

also be used as a top cover to create a podium.

1. Stackable display basket

Made from chrome-plated wire Foldable basket Height 450 mm

880 x 600 mm 55 09 59-802

1180 x 600 mm 55 12 59-802

Trolley with wheels 900 mm 55 09 20-802

1200 mm 55 12 20-802

Basket divider 55 05 40-802

Top basket Height 150 mm 55 09 15-802

Label display strip 840 x 26 mm 55 94 26

2. Hexagonal dumper basket Grey lacquered wire Height 800 mm Ø 550 mm 55 06 80-125

Wire sign holder A4 55 06 83-125

3. Dumper bin with acrylic

Made of grey lacquered metal tubing and acrylic Square Height 900 mm Width 500 mm 55 50 50-125

4. Dumper basket 580 x 580 mm Height 670/870 mm 47 06 67-553 Divider for display basket 47 06 68-553

5. Hook-on basket

Suitable for stackable display baskets, full-pallet baskets and the above display basket 470 x 150 x 200 mm 70 50 23-801

Label holder with suspension attachments

x 26 mm 55 02 26

6. Display dummy Full body, male Value-for-money model in polyethylene

7. Clothes rack

Black textured surface. Adjustable in fixed positions between 1200–1800 mm

Two arms Width 825 mm (A) 55 05 01-120

Revolving Ø 825 mm (B) 55 05 03-120

Four arms Width 710 mm (C) 55 05 04-120 Length 1820 mm (D)

55 05 05-120 Sign

PALLETS AND COLLARS

Pallets and pallet collars are great for dumping items in to create a quick, simple and attractive display. Choose the colour that best suits your concept: Black -111 is kept in stock. Natural -000, White -010 and Brown -197 are available to order.

1. Pallet

Full pallet 1200 x 800 mm 79 90 10-xxx

Half pallet 800 x 600 mm 81 41 72-xxx

Quarter pallet, 600 x 400 mm 81 43 75-xxx

2. Pallet collar

Full pallet collar, 1200 x 800 mm 79 90 11-xxx

Half pallet collar, 800 x 600 mm 81 41 73-xxx

Long and narrow pallet collar, 1200 x 400 mm 81 43 73-xxx

Quarter pallet collar, 600 x 400 mm 80 85 44-xxx

Half pallet collar, 400 x 300 mm 88 23 99-xxx

3. Wire pallet collar

Stocked in black (colour code -120) and zinc (colour code -802)

600 x 800 x 200 mm 55 06 85-xxx

1200 x 800 x 200 mm 55 12 85-xxx

1200 x 800 x 400 mm, 55 12 83-xxx

1200 x 400 x 200 mm 55 12 45-xxx

600 x 400 x 200 mm 55 06 45-xxx

400 x 300 x 200 mm 88 24 02-120 (Note: only black)

4. Base section

Blind base section, 1200 x 800 mm 81 41 70-xxx

Blind base section, 800 x 600 mm 81 41 71-xxx

Blind base section, 1200x400 mm 81 43 71-xxx

Blind base section, 600 x 400 mm 80 85 42-xxx

Blind base section 400 x 300 mm 88 24 00-xxx

5. Divider for full pallet Wire divider, zinc 55 12 86-802

Pallet divider, wood 81 41 77-xxx

Attachment for pallet divider, wood 2 pcs/divider 81 43 12-111

6. Pallet display rack

For fitting over a pallet. 81 42 68-120

Metal rim for acrylic box for hanger bar 81 42 69-111

Acrylic box, 395 x 145 x 100 mm 81 42 70, Hanger bar, 1200 x 30 mm 53 12 00-801 Hanger, 140 x 5 mm, double 53 21 44-801

7. Base panel with wheels 1200 x 400 mm 81 43 70-xxx 400 x 300 mm 88 20 61-xxx

8. Pallet display table

For placing under a pallet Used to display the contents of the pallet Height adjustable 900–1200 mm Table top in Grey Twist, base in black, 550 x 500 mm 55 80 90-120

9. Sign holder for pallet

For placing under a EUR pallet 210 x 1400 mm, zinc 70 11 19-802

incl A5 top sign, acrylic 70 11 20

10. Pallet display rack

For placing under a pallet. 600 module. Can be fitted with a shelf, hanger rail, etc H 1400 mm B 630 mm 50 12 79-120

11. Hook-on basket

Suitable for display basket, full-pallet basket and wire pallet collars

470 x 150 x 200 mm 70 50 23-801

12. Sign holder

A4, zinc 70 11 21-803

A3, zinc 70 11 22-803

A4, acrylic front, 1 mm 70 11 28

A3, acrylic front, 1 mm 70 11 30

13. Label holder with suspension attachments

Suitable for wire display basket, full-pallet basket and wire pallet collars

105 x 26 mm 55 02 26

105 x 39 mm 55 02 39

100 x 200 mm 55 80 20

14. Set of castors

Screws into the pallet collar, pallet not needed

Set of castors incl 4 wheels with brakes 81 41 74-802

15. Height-adjustable sign holder with foot

A4, zinc 55 50 04-802

A5, zinc 55 50 05-802

16. Full pallet basket

Stackable and foldable Zinc

1200 x 800 mm, height 500 mm, 50 12 80-1-802Divider, zinc, 50 12 81-1-802

17. L Placard holder

For placing under pallet Height adjustable 1900–2300 mm Movable hooks For placard width max 50

cm Zinc Length 500 mm, 55 50 01-802

Plastic pocket 500 x 700 mm, 55 50 07

18. T Placard holder

For placing under pallet Height adjustable 1900–2300 mm Movable hooks For placard width max

cm

20. Podiums in half and full pallet sizes

Designed to give you many combination options

Robust tubing construction protects panels and trays Choose between grey textured lacquer and zinc

mm 55 50 03-802 Plastic pocket 500 x 700 mm 55 50 07

19. Flat foot

x

Foot only 100 x 600 mm For 50 upright Can be combined with our standard uprights and standard panels 71 12 53 -553

Lighting design

Efficient and effective lighting is more important now than ever. Lighting provides so many opportunities. With the aid of light, you can make the store more inviting and exciting. The right lighting enhances your merchandise, while inspiring and enthusing customers.

Hestra has solutions integrated into its shop fittings, as well as a separate range of additional lighting.

1. Calypso

2. Calypso Midi

5. Mars

6. Brics

7. Benu Pullswitch

3. Calypso Mini

4. Sirius

Height 295

Black 59 20 30-111

Dark grey 59 20 30-355

Light grey 59 20 30-005

White 59 20 30-010

Re 59 20 30-313

Orange 59 20 30-326

Terracotta 59 20 30-323

Mustard 59 20 30-231

Blue 59 20 30-513

Green 59 20 30-424

Yellow 59 20 30-207

Height 230 mm Ø 125

Black 59 20 48-111

Dark grey 59 20 48-355

Light grey 59 20 48-005

White 59 20 48-010

Red 59 20 48-313

Orange 59 20 48-326

Terracotta 59 20 48-323

Mustard 59 20 48-231

Blue 59 20 48-513

Green 59 20 48-424

Yellow 59 20 48-207

Swing

Height 185 mm Ø 210 mm

Grey 59 20 49-017

White 59 20 49-010

Natural 59 20 49-1

Black 59 20 49-111

Red 59 20 49-313

Green 59 20 49-428

4. Halo

Circular LED light

delivers comfortable, attractive light 3000 K Ø 800 mm 3200 Lumen 59 20 70-111 Ø 1200 mm 5050 Lumen 59 20 71-111 Ø 1500 mm 6100 Lumen 59 20 72-111

1. Pendant light fitting Muuto Unfold Made of silicone rubber with a plastic cable For a light source with an E27 fitting, max 100W. Swing range approx 3500 mm

mm Ø 325 mm

2. Pendant light fitting Muuto E27 Attachment and cable in silicone LED light source included Swing range approx 4000 mm

mm

3. Pendant light fitting Muuto Grain Made of a special mixture of bam boo and plastic composite LED light source included

range approx 4000 mm

fitting made of black lacquered aluminium The opal surface

WELCOMING AND SAFE

Welcoming and safe entrances are crucial to a store’s profitability nowadays. Below are two examples from a larger range. Contact us for the solution that is best for you.

In addition to our fixed cashier counters, we also provide a wide range of conveyor belt counters..

We can tailor a solution to suit your needs. Ask for a quote.

DIY/Building supplies

1. Max shopping trolley

Trolley with a folding 40 litre wire basket The Max trolley has a board holder, a polished zinc-plated chassis and a black handle Short stacking length of 200 mm Load capacity of lower shelf 200 kg Wheels 125 mm Length 1085 mm, width 644 mm, height 1010 mm

Max trolley, garden 57 95 71

Max trolley, DIY/building supplies 57 95 72

2. Junior shopping trolley

Stable, robust trolley with folding upper shelf Polished, zinc-plated finish. Payload max. 300 kg. Stacking length 260 mm Wheels 125 mm Length 970 mm, width 520 mm, height 995 mm 57 90 50

3. Compact Plus shopping trolley, 90 litres Stable trolley with compact dimensions and short stacking length Ideal for small shops or for supplementing larger trolleys Polished, zinc-plated chassis and powder-coated basket Oval handles made of black, transparent plastic, anthracite protective corners Stacking length 190 mm, 10 stacked trolleys 2460 mm Wheels 125 mm Length 745 mm, width 530 mm, height 995 mm 57 95 95

High-capacity trolley designed for bulky, heavy loads Length 1000 mm Height 1000 mm Width 700 mm 57 95 62 -1

FACILITATE YOUR SALES!

Trolleys and baskets really only have one purpose – to make things easier for your customers and your store.

4. Exact bulky items trolley

Most trolleys and baskets can be printed with advertising text. If you require a different solution, we can tailor one to your exact needs and provide a quote.

7.

I EAB Lagerinredningar ingår: Pallställ, Djupstapling, Maxipacker, Rullbanor, Utdragsenhet, Grenställ, Virkesställ, Listställ, Hyllställ, Plastlådor, Påkörningsskydd och Arbetsplatsutrustning.

Fakta

EAB:s hyllställ uppfyller alla säkerhetskrav den INSTA 251, svensk beteckning SS 2241, samt den den EN-15635.

Hyllplanen levereras galvaniserade alternati rlack i ljusgrå färg . Gavelplåt, ryggplå ljusgrå sockelplåt och

Leveranser

eras komplett med stolpar, stagplåt, hyllplan, hyllhakar samt skruv. Med hjälp av den bifogade monteringsanvisningen är det enkelt att montera ett EAB hyllställ.

EAB Det Håller

Hållbarheten är ett signum för EAB. Vår noggrannhet och vårt kvalitetstänkande nns med i allt från materialval till tillverkning, leverans och montage. Hållbarheten

inkluderar även de relationer vi har till våra kunder, leverantörer och medarbetare.

CERTIFIERATLEDNINGSSYSTEM

1. Pallet rack end, depth 800 mm

Height 3000 mm 88 01 00-803

Height 3500 mm 88 01 01-803

Height 4000 mm 88 01 02-803

Height 4500 mm 88 01 03-803

Pallet rack end, depth 1100 mm

Height 3000 mm 88 01 10-803

Height 3500 mm 88 01 11-803

Height 4000 mm 88 01 12-803

Height 4500 mm 88 01 13-803

2. Load-bearing beam, working from the side

Length 1350 mm/Z100 mm

1 x 1000 kg 88 01 20

Length 2650 mm/Z115 mm

2 x 1150 kg 88 01 21

Load-bearing beam, working from the end

Length 1850 mm/Z100 mm

2 x 1000 kg 88 01 30

Length 2750 mm/Z100 mm

3 x 500 kg 88 01 31

Length 2750 mm/Z115 mm

3 x 750 kg 88 01 32

Length 2750 mm/Z140 mm

3 x 1050 kg 88 01 33

Also available in other heights Contact a sales representative

3. End stop

For fitting to rear edge of pallet rack.

Length 2750 mm 88 01 50

Length 1850 mm 88 01 51

4. Upright protector For fitting to concrete floor.

Height 200 mm 88 01 60

Height 400 mm 88 01 61

5. Beam sheeting For picking items Zinc

Width 455 mm Depth 800 mm

88 01 70

Width 455 mm Depth 1100 mm

88 01 71

6. Perforated beam sheeting

For picking items, with/without pallet Retaining shelf approved for use with sprinklers

Max load 400 kg

Width 910 mm Depth 800 mm

88 01 80

Width 910 mm Depth 1100 mm

88 01 81

PALLET RACKS

Pallet racks are available in heights from 1500 to 8000 mm. In stores, work is most commonly done from the side of the pallet, and here the pallet rack ends are 800 mm deep. In warehouses work is most commonly done from the end of the pallet, and there the ends are 1100 mm deep.

Information, terms and conditions

You can reach us by e-mail, info@hestra.se. You can also call us on +46 370 33 98 00 from 8 am–4 pm (closed for lunch 12–1 pm) on weekdays, except on Fridays when we close the switchboard at 2 pm.

The Hestra brand, like our products, designs and other solutions, are the property of Hestra Any infringement of our rights is strictly forbidden and could result in liability for damages

Price

Prices do not include VAT, shipping or packaging Terms of payment are 30 days net from the invoice date Interest on overdue payments is 1 5% per month We reserve right of ownership to property sold until full payment is received, as well as the right to make price and design changes

Delivery

The acknowledged order date means the date on which the goods leave Hestra’s warehouse Installation

Hestra’s fixtures and fittings are easy to install, but in some instances we recommend enlisting the help of a fitter. Hestra has its own fitters and collaborates closely with independent fitters nationwide.

Warranty and right of return

All products are covered by a one-year warranty We want you to be satisfied with the delivery and with us, so please contact us immediately if you have comments or questions Returns are subject to a return fee of 15% The right of return is valid for 30 days from the time of accepted delivery It is valid for unopened packages that are not damaged Before you make a return we request that you contact your project manager at Hestra Products in special colours and materials, large quantities, and articles from and including page 96, are not covered by the right of return

Damage during transport

If transport damage occurs, the buyer must notify the shipping agent within 8 days

Disclaimer

We disclaim responsibility for any printing errors or colour deviations, and we reserve the right to make changes to our range

Hestra Inredningar AB Box 112, 335 03 Hestra, Sweden Visiting address Flodalavägen 11

Tel +46 370 33 98 00 info@hestra.se www.hestra.com

Hestra Innredninger A/S Holterveien 4 B 1440 Drøbak, Norway.

Tel +47-64 90 75 90 info@hestra.no www.hestra.no

Hestra Denmark

Hjulmagervej 4a 7100 Vejle, Denmark.

Tel +45 20 41 10 66 info@hestra.dk www.hestra.dk

Hestra Suomi Vesijärvenkatu 25 B 15140 Lahti, Finland.

Tel +358 45 77 31 71 99 info@hestra.fi www.hestra.fi
