FRAME TANKS The heavy duty fold out frame is made of 1” square tubular steel or aluminum. The liner is made of heavy 22 ounce PVC (Polyvinyl Chloride) coated nylon which resists chemical contamination, mildew, rot and ultraviolet exposure. The liner will withstand -40 degree temperatures and severe outdoor exposure. The seams are electronically heat sealed. The 10” discharge tube allows for fast emptying. CAPACITY DIMENSIONS STEEL WT 1000 gal 8’ x 8’ x 30” 1500 gal 10’ x 10’ x 30” 2100 gal 11’3” x 11’3” x 30” 2500 gal 12’ x 12’ x 30” 3000 gal 13’3” x 13’3” x 30” 3500 gal 14’ x 14’ x 30” 4000 gal 15’ x 15’ x 30” 5000 gal 17’ x17’ x 30
ALUM WT 112 lbs 129 lbs 160 lbs 171 lbs 188 lbs 202 lbs 220 lbs 252 lbs
80 lbs 95 lbs 116 lbs 125 lbs 137 lbs 150 lbs 165 lbs 187 lbs Yellow liner is standard, red available upon request.
2919-REPAIR Repair Kit..........................$2495 2919-SY1000AL Aluminum..................$87095 2919-SY1500AL Aluminum..................$96195 2919-SY2100AL Aluminum...............$107295 2919-SY2500AL Aluminum...............$116795 2919-SY3000AL Aluminum...............$128295 2919-SY3500AL Aluminum...............$135695 2919-SY4000AL Aluminum...............$143795 2919-SY5000AL Aluminum...............$161495
2919-SY1000 Steel................$59295 2919-SY1500 Steel................$66295 2919-SY2100 Steel................$78395 2919-SY2500 Steel................$91595 2919-SY3000 Steel...............$100595 2919-SY3500 Steel............$108695 2919-SY4000 Steel............$118795 2919-SY5000 Steel............$153195
SNAP TANK
2919-1000L Liner Only..........$31795 2919-1500L Liner Only..........$40195 2919-2100L Liner Only..........$45595 2919-2500L Liner Only..........$51395 2919-3000L Liner Only..........$57695 2919-3500L Liner Only..........$66595 2919-4000L Liner Only..........$70995 2919-5000L Liner Only..........$75795
PILLOW TANK
WATER SUPPLY
tank and carrying bag
Stores in a fraction of the space folding tanks require and deploys easily in minutes. Constructed of clear anodized aircraft quality aluminum. Liner is heavy duty 22 oz vinyl with 3” NPT female flange and plug. Vinyl carrying bag with zipper and carrying handles. CAPACITY IN GALLONS 1000 gal 1500 gal 2000 gal 2500 gal 3000 gal 3374-ST1000 3374-ST1500 3374-ST2000 3374-ST2500 3374-ST3000
134
KIT DIMENSIONS 39” x 16” x 16” 49” x 16” x 16” 56” x 16” x 16” 63” x 16” x 16” 69” x 16” x 16”
ASSEMBLED DIAM X DEPTH 100” x 33” 136” x 33” 150” x 33” 169” x 33” 185” x 33”
WEIGHT 67 lbs 77 lbs 87 lbs 92 lbs 107 lbs
1000 Gallon Snap Tank w/ Liner........$126695 1500 Gallon Snap Tank w/ Liner........$137495 2000 Gallon Snap Tank w/ Liner........$155595 2500 Gallon Snap Tank w/ Liner........$173595 3000 Gallon Snap Tank w/ Liner........$195395
1.800.831.8547
Rugged industrial grade product designed to carry and store water for use at fire scenes and incident sites. Made from fabric reinforced materials and comes complete with a 2” NPSH ball valve, removable 5.5” wide cap, fastened corner brackets for tie downs and a puncture repair kit. Not approved for potable water. Available in three different capacities: 66 gallon, (250 liter) empty dimensions: 36” x 59” 132 gallon, (500 liter) empty dimensions: 58” x 64” 264 gallon, (1000 liter) empty dimensions: 58” x 106”
3306-4550-250 66 Gallon Pillow Tank ................................... $40595 3306-4550-500 132 Gallon Pillow Tank . ............................... $49595 3306-4550-1000 264 Gallon Pillow Tank .............................. $54095 we accept:
