BIG BMX
BMX/RACE
MODEL
650 BMX
SPEED SERIES PRO 24”
SPEED SERIES PRO XL
SPEED SERIES PRO
PRO SERIES PRO 24”
PRO SERIES PRO XL
PRO SERIES PRO
FRAME
2014 GT Design w/Pierced Top Tube, Hi-Ten w/Cr-Mo Seat Tube, American BB, 3/8” Dropouts, Downtube Gusset, Under-Seatstay V-Brake, Coaster Brake Tab, External 1-1/8” H/T
2014 GT Speed Series BMX Race Design, Alloy Hydro Formed and Butted Speed Metal Tubes, Internal Quick Release Seat Clamp Wedge, CNC/Forged Reverse Style Dropouts, BB30, Taper 1-1/8”-1-1/2” Integrated H/T
2014 GT Speed Series BMX Race Design, Alloy Hydro Formed and Butted Speed Metal Tubes, Internal Quick Release Seat Clamp Wedge, CNC/Forged Reverse Style Dropouts, BB30, Taper 1-1/8”-1-1/2” Integrated H/T
2014 GT Speed Series BMX Race Design, Alloy Hydro Formed and Butted Speed Metal Tubes, Internal Quick Release Seat Clamp Wedge, CNC/Forged Reverse Style Dropouts, BB30, Taper 1-1/8”-1-1/2” Integrated H/T
2014 GT Pro Series BMX Race Design, 6061-T6 AL, Euro BB, Reverse Dropouts, 1-1/8” Integrated H/T
2014 GT Pro Series BMX Race Design, 6061-T6 AL, Euro BB, Reverse Dropouts, 1-1/8” Integrated H/T
2014 GT Pro Series BMX Race Design, 6061-T6 AL, Euro BB, Reverse Dropouts, 1-1/8” Integrated H/T
FORK
GT 100% Cr-Mo, 1-1/8” Steerer, 31.8mm O.D. Blades w/Angle-Cut Ends, 3/8” Axle
GT BMX Pro Race, 100% Cr-Mo 1-1/8” Steerer, Tapered 31.8-28.6mm Blades, 365mm A/C, 3/8” Dropouts
New GT Full Carbon Fork w/Carbon Taper Steerer Tube, 15/10mm Axle Dropouts
New GT Full Carbon Fork w/Carbon Taper Steerer Tube, 15/10mm Axle Dropouts
GT BMX Pro Race, 100% Cr-Mo 1-1/8” Steerer, Tapered 31.8-28.6mm Blades, 365mm A/C, 3/8” Dropouts
GT BMX Pro Race, 100% Cr-Mo 1-1/8” Steerer, Tapered 31.8-28.6mm Blades, 320mm A/C, 3/8” Dropouts
GT BMX Pro Race, 100% Cr-Mo 1-1/8” Steerer, Tapered 31.8-28.6mm Blades, 320mm A/C, 3/8” Dropouts
CRANK
GT Tubular Cr-Mo 3Pc., 170mm Arms, Cold Forged Cr-Mo 19mm x 8T Spline Spindle, 34T Alloy Chain Wheel
FSA Assault GT Wing Logo Hollow Forged Alloy 2pcs, 175mm Arms, BB30 Cr-Mo Hollow Axle, 36T 7075 AL Chain Ring
FSA Assault GT Wing Logo Hollow Forged Alloy 2pcs,. 175mm Arms, BB30 Cr-Mo Hollow Axle, 44T 7075 AL Chain Ring
FSA Assault GT Wing Logo Hollow Forged Alloy 2pcs,. 170mm Arms, BB30 Cr-Mo Hollow Axle, 44T 7075 AL Chain Ring
Tubular Cr-Mo 2 Pcs, 175mmArms, 8 Splined Spindle w/Single Pinch Bolt, Recessed Axle Bolt, 36T GT CNC AL Chain Wheel
GT Tubular Cr-Mo 2 Pcs, 175mm Arms, 19mm x 8T Splined Spindle, Recessed Axle Bolt, 44T GT CNC AL Chain Wheel
GT Tubular Cr-Mo 2 Pcs, 170mm Arms, 19mm x 8T Splined Spindle, Recessed Axle Bolt, 44T GT CNC AL Chain Wheel
BOTTOM BRACKET
American Sealed Bearing
BB30 Sealed Bearings
BB30 Sealed Bearings
BB30 Sealed Bearings
Euro Sealed Bearings
Euro Sealed Bearings
Euro Sealed Bearings
PEDALS
GT Low Profile Large Size Platform Design, PP Material, Boran Axle
GT Slim Profile Large Size Platform, PP Material
GT Slim Profile Large Size Platform, PP Material
GT Slim Profile Large Size Platform, PP Material
GT Slim Profile Large Size Platform, PP Material
GT Slim Profile Large Size Platform, PP Material
GT Slim Profile Large Size Platform, PP Material
FREEWHEEL
16T Coaster Cog
16T Shimano Cog
16T Shimano Cog
16T Shimano Cog
DNP 30 Point x 16T
DNP 30 Point x 16T
DNP 30 Point x 16T
CHAIN
KMC Z410
KMC Z610HX
KMC Z610HX
KMC Z610HX
KMC Z610
KMC Z610
KMC Z610
RIMS
BX-32, 36H, Double Wall
Alienation Deviant 36H Front, Alienation 440 36H Rear
Alienation Deviant 36H Front, Alienation 440 36H Rear
Alienation Deviant 32H Front, Alienation 440 36H Rear
Alienation Deviant 32H Front, Alienation 440 36H Rear
Alienation Deviant 32H Front, Alienation 440 36H Rear
Alienation Deviant 32H Front, Alienation 440 36H Rear
TIRES
Innova 650b x 2.1” F/R
Tioga Power Block 24” x 1.75” F/R
(F) Tioga Power Block 20” x 1.95”, (R) Tioga Power Block 20” x 1.75”
Tioga Power Block 20” x 1.75” F/R
Tioga Power Block 24” x 1.75” F/R
(F) Tioga Power Block 20” x 1.95”, (R) Tioga Power Block 20” x 1.75”
Tioga Power Block 20” x 1.75” F/R
HUBS
(F) 36H Alloy Body, Sealed Bearing 3/8 Axle, (R) KT Coaster Brake, 36 Hole, 3/8 Axle, 16T Cog
(F) GT Superlace Design, Sealed Bearings, 3/8” Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Superlace 120 Point Cassette Design, CNC GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/ Allen Thread-In Bolts, AL Washers
(F) GT Superlace Design, Sealed Bearings, 3/8” Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Superlace 120 Point Cassette Design, CNC GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers
(F) GT Superlace Design, Sealed Bearings, 3/8” Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Superlace 120 Point Cassette Design, CNC GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers
(F) GT Mohawk Design, Sealed Bearings, 3/8” Axle, 32 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Mohawk Flip/Flop Design, GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/Allen Thread-In Bolts, AL Washers
(F) GT Mohawk Design, Sealed Bearings, 3/8” Axle, 32 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Mohawk Flip/Flop Design, GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/Allen ThreadIn Bolts, AL Washers
(F) GT Mohawk Design, Sealed Bearings, 3/8” Axle, 32 Hole, w/Allen Thread-In Bolts, AL Washers, (R) GT Mohawk Flip/Flop Design, GT Logo, Low Flange, 2 x Sealed Bearings, 3/8” x AL Axle, 36 Hole, w/Allen ThreadIn Bolts, AL Washers
SPOKES
Stainless Steel
15g Stainless Steel Polished
15g Stainless Steel Polished
15g Stainless Steel Polished
15g Black
15g Black
15g Black
BRAKES/LEVERS
Promax V-Brake and Coaster Brake / Promax Alloy 2-Finger V-Brake
(R) Promax Cold Fodge Arms w/31mm Brake Pad Adj, 108mm Arms V-Brake / Promax V-Point Click Lever AL 2 Finger Lever w/Reach Adjust
(R) Promax Cold Fodge Arms w/31mm Brake Pad Adj, 108mm Arms V-Brake / Promax V-Point Click Lever AL 2 Finger Lever w/Reach Adjust
(R) Promax Cold Fodge Arms w/31mm Brake Pad Adj, 108mm Arms V-Brake / Promax V-Point Click Lever AL 2 Finger Lever w/Reach Adjust
(R) Tektro 930AL, Cold Forged AL 95mm, V-Brake / Promax Xl-91 Mini V-Type AL 2 Finger Lever w/Reach Adjust
(R) Tektro 930AL, Cold Forged AL 95mm, V-Brake / Promax Xl-91 Mini V-Type AL 2 Finger Lever w/Reach Adjust
(R) Tektro 930AL, Cold Forged AL 95mm, V-Brake / Promax Xl-91 Mini V-Type AL 2 Finger Lever w/Reach Adjust
HANDLEBARS
GT Retro Hi-Ten, 690mm Width, 142mm Rise, 19° Backsweep, 2° Upsweep
GT Cr-Mo Interceptor 5.5” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
GT Cr-Mo Interceptor 8.25” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
GT Cr-Mo Interceptor 8.25” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
GT Cr-Mo Interceptor 5.5” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
GT Cr-Mo Interceptor 8” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
GT Cr-Mo Interceptor 8” x 27.5” Rise Taper Cross Bar, 11° Back x 3° Up
STEM
GT Top Load Design w/Cold Forged Clamp, 50mm Ext, GT CNC Logo
Promax 100% Cold Forged 1-1/8”, 50mm Ext
Promax 100% Cold Forged 1-1/8”, 50mm Ext
Promax 100% Cold Forged 1-1/8”, 50mm Ext
GT 100% Cold Forged 1-1/8” Machined GT Logo On Front Cap, 50mm Ext
GT 100% Cold Forged 1-1/8” Machined GT Logo On Front Cap, 50mm Ext
GT 100% Cold Forged 1-1/8” Machined GT Logo On Front Cap, 50mm Ext
GRIPS
GT Wings Logo 130mm Single Compound
GT DOHC Design 140mm
GT DOHC Design 140mm
GT DOHC Design 140mm
GT DOHC Design 140mm
GT DOHC Design 140mm
GT DOHC Design 140mm
HEADSET
1-1/8” Threadless, Steel
FSA 1-1/8”-1.5” Taper Integrated Design, 45° x 45° Sealed Bearings
FSA 1-1/8”-1.5” Taper Integrated Design, 45° x 45° Sealed Bearings
FSA 1-1/8”-1.5” Taper Integrated Design, 45° x 45° Sealed Bearings
FSA Integrated Design, 45° x 45° Sealed Bearings
FSA Integrated Design, 45° x 45° Sealed Bearings
FSA Integrated Design, 45° x 45° Sealed Bearings
SADDLE
Old-School Inspired GT Padded
SDG Patriot, I-Beam Kevlar w/Embossed GT Wing Graphic
SDG Patriot, I-Beam Kevlar w/EmbossedGT Wing Graphic
SDG Patriot, I-Beam Kevlar w/EmbossedGT Wing Graphic
SDG Patriot, I-Beam Kevlar w/Embossed GT Wing Graphic
SDG Patriot, I-Beam Kevlar w/Embossed GT Wing Graphic
SDG Patriot, I-Beam Kevlar w/Embossed GT Wing Graphic
SEATPOST
Steel, 27.2mm x 350mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SDG I-Beam Micro Adj. AL 6061, 27.2mm
SEAT CLAMP
Alloy, 28.6mm
Alloy, 28.6mm
GT Quick Release Integrated Internal Wedge
GT Quick Release Integrated Internal Wedge
GT BMX Race Design, Aluminum, Single Bolt
GT BMX Race Design, Aluminum, Single Bolt
GT BMX Race Design, Aluminum, Single Bolt
SIZES
650b Wheel / 23” Top Tube
24” Wheel / 21.75” Top Tube
20” Wheel / 21” Top Tube
20” Wheel / 20.5” Top Tube
24” Wheel / 21.75” Top Tube
20” Wheel / 21” Top Tube
20” Wheel / 20.5” Top Tube
COLOR(S)
Trans Blue, Matte Black
Black/White 2-Tone
Black/White 2-Tone
Black/White 2-Tone
Black/White 2-Tone
Black/White 2-Tone
Black/White 2-Tone
EXTRAS
N/A
GT Design CNC Machine Chain Tensioners
GT Design CNC Machine Chain Tensioners
GT Design CNC Machine Chain Tensioners
GT Design CNC Machine Chain Tensioners
GT Design CNC Machine Chain Tensioners
GT Design CNC Machine Chain Tensioners
