PARALLEL
Exceeds 72 hr sal t spray. 8,000 psi Max pressure.
5/16" thread sizes allow for these fittings to be used in heavier duty applications than smaller 1/4"-28 threads. The fine threads of the 6-40 and 10-32 UNF fittings offer added thread engagement in thin materials, and are designed for lightduty applications where conservation of space is a primary concern.
1711-B
1631-B
1648-B1
Straight 5/16"-24 UNF Standard Shank
Straight 5/16"-32 UNEF Standard Shank
65° Angle 5/16"-32 UNEF Standard Shank
IH 18541R91
3018
369616
3016
Straight 6-40 UNF Standard Shank
Straight 10-32 UNF Short Shank
Straight 10-32 UNF Standard Shank
No Ball Check
ALEMITE Item #
HUYETT Order #
No Ball Check
Thread
Angle (E)
Overall Length (A)
Shank Length (B)
No Ball Check
Min. Thread Length (C)
Overall Width (D)
Thread Diameter (F)
Swing Clearance (G)
Hex (H)
1711-B
A1711
5/16"-24
Straight
.66"
.25"
.16"
—
.31"
—
3/8"
1631-B
A1631
5/16"-32
Straight
.66"
.23"
.14"
—
.31"
—
3/8"
1648-B1
A1648
5/16"-32
65°
.80"
.22"
.17"
.67"
.31"
.48"
3/8"
3018
A3018
6-40
Straight
.50"
.16"
.12"
—
.13"
—
1/4"
369616
A369616
10-32
Straight
.47"
.12"
.08"
—
.18"
—
1/4"
3016
A3016
10-32
Straight
.50"
.13"
.11"
—
.18"
—
1/4"
Common Parts
Parts with this designation are in wide distribution.
GM
General Motors®
General Motors® is a registered trademark of General Motors Corp., Detroit, MI.
GM/CH
General Motors®/CH
General Motors® is a registered trademark of General Motors Corp., Detroit, MI.
F
Ford®
Ford® is a registered trademark of Ford Motor Company.
IH
Case IH®
Case IH® is a registered trademark of CNH America LLC., Racine, WI.
