ATTACHMENTS Products
Brandt Pin Grabber Coupler A dedicated pin grabber coupler has been added to the Hard-To-The-Core John Deere-optimized attachment lineup. • Features a rear wedge to keep the rear pin secured without relying on gravity • Internal safety lock is spring-engaged and hydraulically released to keep the rear wedge in place, securing the pin • Hydraulic interlock requires the coupler to be fully curled toward the cab in order to be disengaged to prevent accidental attachment drops • Hydraulic check valve maintains pressure in cylinders in the event of hydraulic hose breakage until proper function is restored • Works with all Deere excavator models from the 80-Series to 400-Series
www.forconstructionpros.com/21427390
Vacuworx Updated RC Series Vacuum Lifting Machines The RC10, RC12, RC16 and RC20 can grip up to 120-ft. triple pipe joints and hold the shape of limber pipes and long joints of flexible plastic pipe. • Single-cylinder diesel engine powers the rotary vane pumps on each attachment • Include an electronic ignition, remote operating control and a vacuum reservoir beam that doubles as a spreader bar • Control and alarm systems activate audio and visual warnings and prevent further lifts if the vacuum falls below a safe working level • Vacuum storage reservoir allows materials to be held for 15 minutes or more under no power
www.forconstructionpros.com/10417599
Allied Rammer Small Range Breakers The 555, 777 and 999 Rammer small range breakers are designed without tierods and incorporate the Constant Blow Energy (CBE) plus operating system. • For carriers between 7,500 to 27,600 lbs. • Integrated one-piece tool bushing design requires fewer parts and is easily field replaceable • Box-type housing with high-tech dampening material reduces noise and vibration and fully protects the power cell • Dual accumulator (High Pressure and Low Pressure) design provides maximum power with less pulsation in hydraulic lines
www.forconstructionpros.com/12138533
E-Z Drill 210 Series Concrete Drill Attachments This equipment-mounted, pneumatic concrete drill attachment series includes the three-gang Model 210-3 EQ MT, four-gang Model 210-4 EQ MT and fivegang Model 210-5 EQ MT. • Compatible with most models of backhoes and excavators • Capable of drilling 5/8- to 2 1/2-in.diameter holes at a depth of 18 in. • Each drill motor requires a minimum of 100 cfm for operation • Minimum of 300 cfm required to power the Model 210-3 EQ MT • User-friendly, easily accessible control panel mounted on drill
www.forconstructionpros.com/10278334
These buckets are built for heavy-duty applications with a main body built using AR 450 wear-resistant steel in all critical areas. • Designed to maximize capacity and reduce drag, extending bucket life • Folded top section gives greater structural strength and allows a greater opening for ease of loading and unloading material • Available in a range of widths and capacities for excavators from 4,500 to 112,000 lbs. • Manufactured to the relevant safety standards with high-strength steels for optimal quality and performance
www.forconstructionpros.com/21244748
CB Breakers are available for excavators, backhoes and skid steers ranging from .8 to 55 tons. • Compact, lightweight range for compact excavators and skid steers includes a unique valve system and plumbing design that provide power and efficiency while requiring less oil flow • Medium range for backhoes and excavators offers power and versatility for working with a wide range of operating pressures and oil flows • Heavy-duty range for excavators beyond 20 tons are fully box framed with damping materials to reduce noise and recoils to the carrier, and come pre-installed with an auto grease system
26 EQUIPMEN T TOD AY | June 2021
The TSWB concrete crushers include eight models weighing from 1,940 to 26,460 lbs. and suited for carriers from 13 to 330 tons. • Crushing force at tip ranges from 40 tons for the 620V to 242 tons for the 2400V • Seamless casting components and a custom tooth design enable faster material fractioning • Feature a large jaw opening, 360° hydraulic rotation, standard speed valve for shorter cycle times, built-in pressure relief valve and flat-mount design • High-pressure twin cylinders with cylinder rod covers (except TSWB 2200V)
www.forconstructionpros.com/21131869
Oriel Attachments Heavy-duty Excavator Buckets
Rockwater CB Hydraulic Breakers
www.forconstructionpros.com/21070427
Okada TSWB Series Primary Crusher
Montabert V7000 Breaker The V7000 fits in the 20,000-ft.-lb. impact energy class and is suited for carriers ranging from 70 to 120 tons. • Variable energy technology automatically adapts breaker energy according to the rock/material hardness • Automatic pressure regulator ensures optimal performance regardless of oil temperature or hydraulic conditions • Energy recovery valve captures recoil and converts it back into additional energy • Suspension system reduces vibration and wear • Includes blank fire protection, an automatic lubrication system and optional air pressurization kit for underwater applications
www.forconstructionpros.com/21131861
www.ForConstructionPros.com
Epiroc ES Hydraulic Breakers The ES hydraulic breaker attachments include the ES 60, ES 70 and ES 80 models for carriers ranging from 2,800 to 26,500 lbs. • Slim, compact design provides easy handling, good visibility and high maneuverability • Solid block of special casted material eliminates need for a separate guiding system, tie-rods or stud bolts • Removable piston liner increases serviceability • Integrated control valve optimizes efficiency while the Energy Recovery system increases operating efficiency and lowers vibrations
www.forconstructionpros.com/21201287
