Intake Manifolds for Ford 429/460 R-Series A460 Intake Manifolds for Ford 429/460 with Trick Flow PowerPort® A460 Cylinder Heads
Track Heat® and R-Series Intake Manifolds for Ford 429/460
Intended for 500-plus cubic inch, high-rpm engines, the Trick Flow R-Series single plane intake manifold features a one-piece, spider-type design with high-flow, extended individual runners and a raised plenum floor for significant horsepower and torque increases. Other features include A319 aluminum construction, extra material for custom port work, and bosses for nitrous or fuel injection. The manifold is designed to use Holley 4500 Dominator-style carbs. Overall height to carburetor mounting pad is 8.600". The R-Series A460 tunnel ram manifold is ideal for all large cubic inch, high-rpm applications such as drag racing or tractor pulling. Highlights of the manifold include thick-wall A319 aluminum construction plus bosses for nitrous and fuel injection. The available top covers mount single or dual Holley 4500 Series Dominator-style carbs. Overall height to the top of carburetor mounting pad is 10.480" with the dual carb top; overall height with the single carb top is 13.100".
Trick Flow’s Track Heat single plane intake manifolds for Ford 429/460 are designed for street/strip engines that operate in the 3,500-8,000 rpm range. Features include a high-rise, one-piece spider design with high-flow, extended individual runners, A319 aluminum construction, a raised plenum floor for increased flow velocity and fuel atomization, integral bosses for nitrous or fuel injection nozzles, and extra material for custom port work. The manifold is designed to use Holley 4150 and other square bore-style carbs. The overall height to the carburetor mounting pad is 6.800". The Trick Flow R-Series single plane intake manifold is intended for 500-plus cubic inch, high-rpm engines using single Holley 4500 Dominatorstyle carbs. The manifold is a one-piece, spider-type design with high-flow extended runners and a raised plenum floor for a significant power boost. A319 aluminum construction, extra material for custom port work, and bosses for nitrous or fuel injection round out the features. Overall height to carburetor mounting pad is 6.800".
A460 Single Plane Intake Manifold TFS-54400111
Manifold, single Holley 4500 Dominator-style carburetor, each
A460 Tunnel Ram Intake Manifold and Accessories TFS-54494000 TFS-54494001
Manifold, lower only, each Manifold top cover, for single Holley 4500 Dominator-style carburetor, each TFS-54494140 Manifold top cover, for dual Holley 4500 Dominator-style carburetors, each TFS-54494140-G Top cover replacement gasket, each TFS-54494140-LK Linkage kit, for dual Holley 4500 Dominator-style carburetors, each
Track Heat Intake Manifold and Bolt Kit TFS-53400111 TFS-534INTBK
Manifold, each Manifold bolt kit, fits Track Heat intake manifolds only, each
R-Series Intake Manifold TFS-53400112
Manifold, each
TFS-53400111
TFS-54400111
TFS-53400112
Ford 429/460
TFS-54494000
TFS-54494001
