Edge Sanders
Next Article
Features
l The welded steel machine stand guarantees a high level of torsion stiffness and vibration-free processing l Sanding unit pivots up to 45° via lever for sanding straight and bevelled edges l Oscillating sanding belt with separate gear motor for improved sanding results l Oscillation can be optionally engaged l Sanding shoe graphite coated as factory standard for a longer service life of the sanding belt l Height-adjustable sanding table utilises the entire width of the sanding belt l Height-adjustable additional table with extraction unit for sanding radii l Automatically compensates for bend length differences through spring-loaded belt tensioner
Specification KSO 1500F
![](https://assets.isu.pub/document-structure/220331154412-e8a23ad2ab2e60f1f41fcd5515433e3e/v1/580025f66373100b51ceb9b500d099e4.jpeg)
Table height min / max 740 / 920 mm Table height adjustment 180 mm Longitudinal table Dims 750 x 300 mm Transverse table Dims 330 x 330 mm Sanding belt size 2600 x 150 mm Sanding surface 850 x 200 Sand roller Dia. 100 mm Belt speed 20 m / s Motor 400V. 50 Hz 3.0 kW Oscillating motor 0.25 kW Extraction port Ø 120 / 80m Dims LxWxH (cm) 172 x 70 x 103 Weight 180 Kg Height-adjustable additional table with extraction unit for sanding radii Height-adjustable sanding table helps to leverage the entire sanding belt width
Sanding belts Pack of 5
2600 x 150mm K60 2600 x 150mm K80 2600 x 150mm K100 2600 x 150mm K120 2600 x 150mm K180 2600 x 150mm K220
0537-2806 0537-2808 0537-2810 0537-2812 0537-2818 0537-2822
