spherical Plain Bearings RADIAL BEARINGS TYPE FS
AB
• Type FS spherical plain radial bearing is a unit assembly
• For tolerances of nominal dimensions see the tables 1 and
•
•
• • • •
consisting of a solid, spherical O.D. inner ring and a spherical I.D. outer ring. The outer ring has a single fracture to permit assembly. Both inner and outer rings are phosphate treated and then coated with molybdenum disulphide (MoS2). Bearings 16FS30 through 60FS90 are available with reinforced rubber seals. To order, add suffix “TT” to bearing designation Example: 16FS30-TT. Bearings 70FS105 through 300FS430 are available with synthetic resin seals. To order, add suffix “SS” to bearing designation - Example: 70FS105-SS. Before ordering any bearing, check for availability. Type FS bearings are a metric series which follows proposed International Standards Organization (ISO) standards. MetricInch conversions given are for the convenience of the user. The controlling dimensions are in millimeters.
2 on page B423. Dimensions listed are before coating with molybdenum disulphide. The axial internal clearance is approximately three times the radial internal clearance. α is the maximum tilting angle for sealed radial bearings. To utilize the maximum tilting angle for unsealed radial bearings the suggested shaft shoulder diameter da1 shown in the drawing on facing page must not be exceeded. Dimensions and locations of lubrication holes and grooves may be obtained from your Timken representative.
Radial Bearings Type SF
•
B1
B1
d1
d1 d
D
d
D
B
B
Type Type SF FS
Types SF-TT,FS-SS SF-SS Type FS-TT,
DIMeNSIONS - LOAD RATINGS Bearing Bore Outside Diameter I nner Ring Outer ring Spherical Diameter Radial Clearance* Number d D Width Width d1 (unmounted) B1 B (Ref.) mm in.
mm
mm
in.
mm
in.
mm
min. max.
min. max.
lbf.
lbf.
12FS22 14FS26 16FS30 20FS35
12 14 16 20
.4724 .5512 .6300 .7874
22 26 30 35
0.8661 1.0236 1.1811 1.3780
10 12 14 16
.394 .472 .551 .630
7 9 10 12
.276 .354 .394 .472
19 22 25 30
.748 .866 .984 1.181
0.10 0.10 0.10 0.12
0.22 0.22 0.22 0.24
.004 .004 .004 .005
.009 .009 .009 .010
8630 11600 14400 21500
2290 3210 4280 6110
24FS42 30FS47 35FS55 40FS62
24 30 35 40
.9449 1.1811 1.3780 1.5748
42 47 55 62
1.6142 1.8504 2.1654 2.4409
20 22 25 28
.787 .866 .984 1.102
16 18 20 22
.630 .709 .787 .866
36 41 48 55
1.417 1.614 1.890 2.165
0.12 0.12 0.12 0.12
0.24 0.24 0.24 0.24
.005 .005 .005 .005
.010 .010 .010 .010
31000 40200 55100 72300
9170 12600 16700 21400
45FS68 50FS75 60FS90
45 50 60
1.7717 1.9685 2.3622
68 79 90
2.6772 2.9528 3.5433
32 35 44
1.260 1.378 1.732
25 28 36
.984 1.102 1.417
60 67 81
2.362 2.638 3.150
0.12 0.12 0.14
0.24 0.24 0.26
.005 .005 .006
.010 .010 .011
86100 107000 157000
27500 33400 50400
70FS105 80FS120 90FS130 100FS150
70 80 90 100
2.7559 3.1496 3.5433 3.9370
105 120 130 150
4.1339 4.7244 5.1181 5.9055
49 55 60 70
1.929 2.165 2.362 2.756
40 45 50 55
1.575 1.772 1.968 2.165
94 107 117 134
3.701 4.213 4.606 5.276
0.14 0.14 0.14 0.14
0.26 0.26 0.26 0.26
.006 .006 .006 .006
.011 .011 .011 .011
211000 274000 327000 429000
65500 84100 103000 134000
110FS160 120FS180 140FS210 160FS230
110 120 140 160
4.3307 4.7244 5.5118 6.2992
160 180 210 230
6.2992 7.0866 8.2677 9.0551
70 85 90 105
2.756 3.346 3.543 4.134
55 70 70 80
2.165 2.756 2.756 3.150
143 160 187 206
5.630 6.299 7.362 8.110
0.14 0.14 0.16 0.16
0.26 0.26 0.28 0.28
.006 .006 .006 .006
.011 .011 .011 .011
489000 612000 836000 1020000
147000 195000 241000 321000
180FS260 200FS290 220FS320 240FS340
180 200 220 240
7.0866 7.8740 8.6614 9.4488
260 290 320 340
10.2362 11.4173 12.5984 13.3858
105 130 135 140
4.134 5.118 5.315 5.512
80 100 100 100
3.150 3.937 3.937 3.937
234 265 286 306
9.213 10.433 11.260 12.047
0.16 0.18 0.18 0.18
0.28 0.30 0.30 0.30
.006 .007 .007 .007
.011 .012 .012 .012
1300000 1680000 1960000 2240000
361000 497000 568000 642000
260FS370 280FS400 300FS430
260 280 300
10.2362 11.0236 11.8110
370 400 430
14.5669 15.7480 16.9291
150 155 165
5.906 6.102 6.496
110 120 120
4.331 4.724 4.724
333 360 386
13.110 14.173 15.197
0.20 0.20 0.20
0.32 0.32 0.32
.008 .008 .008
.013 .013 .013
2650000 3100000 3560000
745000 829000 946000
mm
in.
in.
* Prior to fracturing outer ring.
•
A
in.
Load Ratings Radial Dynamic Limit Radial Load Load Rating Rating
