a)
Legend: a) For O-ring Size 15: Ø 4 × 1.0 (mm) Size 20 - 35: Ø 5 × 1.0 (mm) Open the lube hole if required.
L6 L2
SU
b) W2 a)
M0B
Lubricating nipples form part of the delivery and have been included. When using other lubricating nipples, it is imperative to observe the correct screw depth of 8 mm.
L6
L2
2
b) Lube nipple, size 15 and 20: Funnel-type nipple Type A – Thread size M3, DIN 3405 B2 = 1.6 mm Size 25 to 35: AM 6 DIN 71412 B2 = 9.5 mm
L3
Installation is possible at all sides.
U, LU
b) W2
Designations
Dimensions M1 H7
d2
d3
M2
Emin
F
Basic load ratings C C0 M0A/0B
Mass M0C
± 0.5
mm
N
Nm
kg
LLRHS 15 SU LLRHS 15 U LLRHS 15 LU
10.30 10.30 10.30
M4 × 6.0 M4 × 6.0 M4 × 6.0
7.4 7.4 7.4
4.4 4.4 4.4
M2.5 - 3.5 deep M2.5 - 3.5 deep M2.5 - 3.5 deep
10 10 10
60 60 60
5400 7800 10000
8100 13500 20200
28 71 150
80 130 190
0.10 0.15 0.20
LLRHS 20 SU LLRHS 20 U LLRHS 20 LU
13.20 13.20 13.20
M5 × 7.5 M5 × 7.5 M5 × 7.5
9.4 9.4 9.4
6.0 6.0 6.0
M3 - 5 deep M3 - 5 deep M3 - 5 deep
10 10 10
60 60 60
12400 18800 24400
13600 24400 35200
58 165 330
170 310 450
0.25 0.35 0.45
LLRHS 25 SU LLRHS 25 U LLRHS 25 LU
15.20 15.20 15.20
M6 × 9.0 M6 × 9.0 M6 × 9.0
11.0 11.0 11.0
7.0 7.0 7.0
M3 - 5 deep M3 - 5 deep M3 - 5 deep
10 10 10
60 60 60
15900 22800 30400
18200 30400 45500
94 240 510
260 430 650
0.35 0.50 0.65
LLRHS 30 SU LLRHS 30 U LLRHS 30 LU
17.00 17.00 17.00
M8 × 12.0 M8 × 12.0 M8 × 12.0
15.0 15.0 15.0
9.0 9.0 9.0
M3 - 5 deep M3 - 5 deep M3 - 5 deep
12 12 12
80 80 80
22100 31700 40000
24800 41300 57800
150 380 715
430 720 1000
0.60 0.85 1.10
LLRHS 35 SU LLRHS 35 U LLRHS 35 LU
20.50 20.50 20.50
M8 × 13.0 M8 × 13.0 M8 × 13.0
15.0 15.0 15.0
9.0 9.0 9.0
M3 - 5 deep M3 - 5 deep M3 - 5 deep
12 12 12
80 80 80
29300 41900 55600
32400 54000 81000
220 565 1215
700 1160 1740
0.90 1.25 1.70
LLRHS 45 U* LLRHS 45 LU*
23.50 23.50
M10 × 18.0 M10 × 18.0
20.0 20.0
14.0 14.0
M4 - 7 deep M4 - 7 deep
16 16
105 105
68100 90400
85700 128500
1130 2425
2310 3470
2.40 3.20
© SKF 2005
71
