4 Actuation systems Control units CAEN Type
10R
Ordering key:
Control
Basic functions
Max. motor connections
Input
Output
n°
V AC
V / A DC
1
230 / 120
24 / 1 - 10
Max. motor connections
Input
Output
n°
V AC
VA
1
230 / 120
400 / 200
Max. motor connections
Input
Output
n°
V DC
V/A
1 1
22 - 28 22 - 28
24 / 5 24 / 9
CAEN10R
CAEV Type
110/220
Control
Basic functions
Available start capacitors: values = 3 µF / 4 µF / 6 µF / 8 µF or 12 µF
Ordering key:
CAEV 110/220
CAED ANR Type
5-24R-PO 9-24R-PO
Ordering key:
Control
Encoder processing Encoder processing
CAED ANR 5-24R-PO CAED ANR 9-24R-PO
