4 Actuation systems Linear actuators CAT 33
29
55
L=S+ (150/158/189)*
Legend: S = stroke L = retracted length 23
24
73
See drawings of front and rear attachments and motor options on page 190
Type
Force push
pull
N CAT33
3000
3000
Max. speed no load full load
Stroke (S)
Retr. Length* (L)
Voltage
Protection
Weight
mm/s
mm
mm
V
IP
kg
100 - 400
S + 150 / 158 / 189
12 / 24 DC 120 / 230 / 400 AC
20 / 44 / 54 / 65
2 - 2.7
48
38
* Dimension depends on selected front attachment
186
