4 Actuation systems Linear actuators
Linear actuators
Figure 9
CAT The CAT (➔ figure 9) modular design concept makes it easy to interchange critical components such as motors, gears, screws, attachments, etc. Custom built actuators are easily and cost efficiently built from standard parts. The CAT range flexibility makes it suitable for an infinite number of applications. Benefits: ● Small ● Robust ● Highly efficient ● Maintenance-free
Type
Force push
pull
N
Max. speed no load full load
Stroke (S)
Retr. Length* (L)
Voltage
Protection
Weight
mm/s
mm
mm
V
IP
kg
S + 100
12 / 24 DC
X4
0.7 - 1.5
CAT 21B
600
600
10
5
50 - 300
CAT 33H
1200
1200
174
150
100 - 400
S + 150 / 158 / 189
12 / 24 DC 120 / 230 / 400 AC
20 / 44 / 54 / 65
2 - 2.7
CAT 33
3000
3000
48
38
100 - 400
S + 150 / 158 / 189
12 / 24 DC 120 / 230 / 400 AC
20 / 44 / 54 / 65
2 - 2.7
CAT 32B
4000
4000
67
50
50 - 700
S + 167 / 175 / 206
12 / 24 DC 120 / 230 / 400 AC
20 / 44 / 54 / 65
2 - 3.5
* Dimension depends on selected front attachment
