Universal Series, Vented 2
0462
3/2 Right-Angled Ball Valve with Vent, Female BSPP Thread C
Nickel-plated brass, NBR
G1/8 G1/4 G3/8 G1/2 G3/4 G1
6 6 9 12 18 23
0462 06 10 0462 06 13 0462 09 17 0462 12 21 0462 18 27 0462 23 34
1
3
E
F
H
H1 H2
J
L
L1
M
kg
8 12 12 15 16.5 19
19 19 24 27 38 46
38 38 45 47 59 63
31 31 43 44 51 55
22 22 25 29 39 48
37 38 46 49 60 72
27 28 31 34 39 47
48 48 69 69 108 108
0.192 0.185 0.261 0.312 0.698 1.066
20 24 27 33 40 47
Maximum working pressure: 20 bar 2
0461
3/2 Right-Angled Ball Valve with Vent, Male/Female BSPP Thread C
Nickel-plated brass, NBR
E
G1/8 G1/4 G3/8 G1/2 G3/4
6 6 9 12 18
0461 06 10 0461 06 13 0461 09 17 0461 12 21 0461 18 27
1
E1
F
H
H1 H2
J
L
L1
M
kg
8 7 12 9 12 11 15 12 16.5 12
19 19 24 27 38
38 38 45 47 59
31 31 43 44 51
22 22 25 29 39
37 38 46 49 60
27 28 31 34 39
48 48 69 69 108
0.182 0.186 0.257 0.304 0.648
20 24 27 33 40
Maximum working pressure: 20 bar
Operation of Right-Angled Vented Ball Valves
Operation of Lockable Vented Ball Valves
With pin-hole vent = purge to atmosphere without silencer Valve closed
Valve open
Valve open
removable lever: where the lever is obstructed in its movement, it can be refitted the opposite way.
Operation of 3/2 Lockable Valves Drilled below and square in the horizontal plane, these valves provide a connection between: either port 1 and port 2, or port 2 and port 3. Valve closed
Valve open
Feed
Usage
Vent
Usage
removable lever: where the lever is obstructed in its movement, it can be refitted the opposite way.
6-14
Valve closed
3
