3800/3900
Push-In Fittings
Stud Fittings Cartridge Stainless steel 316L, FKM
ØD 3800 04 00 3800 06 00 3800 08 00 3800 10 00 3800 12 00
4 6 8 10 12
3900 04 00 3900 06 00 3900 08 00 3900 10 00 3900 12 00
L
G
G1
9.8 12.1 14.8 17.5 20
8 10 13 15 17
17 19 21 24.5 25
H
H1 H2
8.5 8.5 11 10.5 8.5 13.5 12.5 8.5 16 14 10.5 20 14.5 10.5 22.5
kg 0.006 0.008 0.012 0.019 0.023
Cavity dimensions are available in Chapter 2. 3800: collet in stainless steel 303 3900: collet in stainless steel 316L
3809/3909
Stud Elbow, Male BSPT Thread Stainless steel 316L, FKM
ØD
C
4
R1/8 R1/8 R1/4 R1/8 R1/4 R1/4 R3/8
6 ØG
8 10
F 3809 04 10 3809 06 10 3809 06 13 3809 08 10 3809 08 13 3809 10 13 3809 10 17
3909 04 10 3909 06 10 3909 06 13 3909 08 10 3909 08 13 3909 10 13 3909 10 17
G
H
L
kg
10 12 12 15 14.5 17.5 17.5
23.5 27.5 27.5 32 34 37.5 37.5
16.5 20 25 25 25 27.5 27.5
0.020 0.031 0.036 0.041 0.046 0.068 0.069
F
G
H
L
kg
11 13 14 14 14 19 19
10 12.5 12.5 15 15 17.5 17.5
25.5 29 29 34 34 39.5 39.5
18.5 22.5 22.5 24 24 30 30
0.021 0.025 0.030 0.041 0.046 0.057 0.071
10 13 14 14 14 19 19
The body swivels for positioning purposes.
3809
Stud Elbow, Male NPT Thread Stainless steel 316L, FKM
ØD
C
4
NPT1/8 NPT1/8 NPT1/4 NPT1/8 NPT1/4 NPT1/4 NPT3/8
6 ØG
8 10
3809 04 11 3809 06 11 3809 06 14 3809 08 11 3809 08 14 3809 10 14 3809 10 18
The body swivels for positioning purposes.
Stud Elbow, Male BSPP and Metric Thread Stainless steel 316L, FKM
ØD 4
6
8
10
C M5x0.8 G1/8 G1/4 M5x0.8 G1/8 G1/4 G1/8 G1/4 G3/8 G1/4 G3/8
3899 04 19 3899 04 10 3899 04 13 3899 06 19 3899 06 10 3899 06 13 3899 08 10 3899 08 13 3899 08 17 3899 10 13 3899 10 17
3999 04 19 3999 04 10 3999 04 13 3999 06 19 3999 06 10 3999 06 13 3999 08 10 3999 08 13 3999 08 17 3999 10 13 3999 10 17
F
G
10 13 17 13 6 17 14 17 21 19 21
10 10 10 12 12 12 15 15 15 17 17
H 26 27 27 33 33 32 35 35 34.5 43 42
L 18 19 19 24 24 24 25 25 25 31 31
kg 0.019 0.021 0.018 0.031 0.031 0.035 0.039 0.044 0.048 0.068 0.072
The body swivels for positioning purposes.
Stud standpipe 3821, 3921, 3831, 3931 can be used as illustrated, allowing: • stock optimisation • installation of tees and elbows where required
