Technical Manual V-Belts
Special Purpose Conveyor Belts optibelt PKR Endless V-Belts and optibelt KB Kraftband with Patterned Top Surface
PKR 0
PKR 1
PKR 2
Table 78
PKR 5
Table 79 Heigth of top surface
Pattern
PKR 0
Standard (mm)
maximum (mm)
Pitch (mm)
Groove width (mm)
3
5
—
—
PKR 1
3
5
10
—
PKR 2
3
5
—
—
PKR 5
5
—
13
—
Temperature resistance (°C)
Design/Colour
SBR-NR/light CR/black
Hardness (Shore A)
– 40 to + 70 ≈ 55*/65** – 25 to + 100 ≈ 65
Oil resistance
Marking
no limited
no yes
SBR = styrene butadiene rubber NR = natural rubber * ≈ 55 for top surface above the standard height CR = chloroprene rubber ** ≈ 65 for top surface within the standard height
Table 80
Table 81 Top surfaces 3 or 5 mm above the standard height
Top surfaces above the standard height
StandSection ard height (mm)
Minimum order quantities for V-belts patterned top surfaces PKR 0; PKR 1; PKR 2; PKR 5
Pattern type
Standard inside length (mm) PKR 0
PKR 1
PKR 2 PKR 5
for standard range (as listed on pages 24 to 27)
for intermediate length (sizes not listed in this technical manual)
Top surface within the standard height
Standard inside length (mm)
Pattern type
PKR 0
PKR 2
Minimum quantitiy
8.0
1 200 ≤ 5 0001)
●
●
●
—
18 pcs
31 pcs
3 550 ≤ 10 0001)
●
●
10
B/17 11.0
1 200 ≤ 2 0001) 2 001 ≤ 7 1001)
● ●
● ●
● ●
— —
15 pcs 15 pcs
50 pcs 42 pcs
2 850 ≤ 21 0001)
●
●
10
20
12.5
1 850 ≤ 2 0002) 2 001 ≤ 8 0002)
● ●
● ●
● ●
— —
13 pcs 13 pcs
21 pcs 36 pcs
3 550 ≤ 21 0001)
●
●
8
C/22 14.0
1 850 ≤ 2 0002) 2 001 ≤10 0002)
● ●
● ●
● ●
— —
12 pcs 12 pcs
57 pcs 48 pcs
3 550 ≤ 21 0001)
●
●
8
25
16.0
1 850 ≤ 2 0002) 2 001 ≤10 0002)
● ●
● ●
● ●
— —
11 pcs 11 pcs
51 pcs 42 pcs
2 850 ≤ 21 0001)
●
●
8
D/32 20.0
2 850 ≤12 5002) 2 850 ≤12 5002)
● —
● —
● —
— ●3)
9 pcs 8 pcs
22 pcs 8 pcs
2 850 ≤ 21 0001)
●
●
6
—
—
—
—
on request
on request
4 000 ≤ 21 0001)
●
●
5
A/13
E/40 25.0
—
1) Maximum production length on request 3) Only available in CR/black
2) Maximum production length 21000 mm Section Z/10 on request
When ordering, please state the overall height of the V-belt including top surface. This is indicated by the section designation as follows.
Section B/17 – top surface within the standard height = 17 x 11 Section B/17 – with additional 3 mm top surface = 17 x 14 Section B/17 – with additional 5 mm top surface = 17 x 16
151
