Bearing data
Tolerance class P5 Outer ring1) Tolerances in m
D
⌬Dmp
VDsp2) Diameter series
mm
Deviation
9
over
30
TPI 205
incl.
VDmp3) Kea
SD
Sea4) VCs
0, 1, 2, 3, 4
upper lower max. max.
max.
max. max. max. max.
180
250 0
–15
15
11
8
15
11
15
10
250
315 0
–18
18
14
9
18
13
18
11
315
400 0
–20
20
15
10
20
13
20
13
400
500 0
–23
23
17
12
23
15
23
15
500
630 0
–28
28
21
14
25
18
25
18
630
800 0
–35
35
26
18
30
20
30
20
800 1 000 0
–40
44
34
23
35
25
35
24
1 000 1 250 0
–50
54
40
30
40
30
45
28
1 250 1 600 0
–65
70
54
35
45
35
55
32
1 600 2 000 0
–85
82
64
45
55
40
65
38
2 000 2 500 0
–110 110
84
55
65
50
75
45
2 500 3 150 0
–140 140
104
70
75
60
90
50
3 150 4 000 0
–170 170
130
85
85
70
110
60
1)
⌬Cs is identical to ⌬Bs for the inner ring of the corresponding bearing, see table Tolerance class P5 Inner ring, page 29.
2)
No values are given for radial ball bearings with shields or seals.
3)
Applies before assembly of the bearing and after removal of internal and/ or external snap rings.
4)
Only for deep groove and angular contact ball bearings.
