Valves >
Manually actuated directional control valves: Pushbutton valves
Type
Valve function
Type of control
Standard nominal flow rate
Pushbutton valve F-3-M5
3/2-way, single solenoid, closed
Direct
80 l/min
M5
-0.95 ... 10 bar
With pedal Suitable for vacuum operation Directly actuated Sturdy die-cast zinc design f-3-m5 online:
Pushbutton valve K/O-3-PK
3/2-way, single solenoid, open/closed
Direct
80 l/min
PK-3
0 ... 8 bar
With button switch Polymer design Ducted exhaust air k/o-3-pk online:
Pushbutton valve K-3-M5
3/2-way, single solenoid, closed
Direct
80 l/min
M5
-0.95 ... 8 bar
With button switch Suitable for vacuum operation Sturdy die-cast zinc design k-3 online:
Pushbutton valve T-5/3-1/4
5/3-way, closed
Piloted
680 l/min
G1/4
2 ... 10 bar
With pushbutton For positioning, for stopping in the event of an EMERGENCY-STOP and for holding a double-acting cylinder in any position Aluminium design t-5/3-1/4 online:
Robust palm operated valve PV-3-1/8
3/2-way, single solenoid, closed
Direct
80 l/min
G1/8
-0.95 ... 8 bar
With large actuating surface For heavy duty actuation Suitable for vacuum operation pv-3 online:
Pneumatic working line
Operating pressure
Description
Manually actuated directional control valves: Finger lever valves
Type
Valve function
Type of control
Standard nominal flow rate
Finger lever valve TH/O-3-PK-3
3/2-way, single solenoid, closed
Direct
80 l/min
PK-3
0 ... 8 bar
With finger lever Polymer design Ducted exhaust air th* online:
Finger lever valve TH-3-M5, TH-3-1/4-B, TH-5-1/4-B, THO-3-1/4-B
3/2-way, single solenoid, closed, 3/2-way, single solenoid, open, 5/2-way, single solenoid
Direct
80 ... 600 l/min
G1/4, M5
-0.95 ... 10 bar
With finger lever Suitable for vacuum operation Die-cast zinc or die-cast aluminium design th-3-m5 online:
04/2012 Subject to change Product overview
Pneumatic working line
Operating pressure
www.festo.com/catalogue/...
Description
