Rubber hoses | Air and water hoses
RX® Breafixx Black
Breathing air hose EN 14593/ EN 14594
Application ◾◾ extremely flexible rubber breathing air hose ◾◾ silicone and fat free ◾◾ kink proof
Branding imprinted text: “ATEMLUFT EN 14593 / EN 14594 B - H - S - F year” Approvals/regulations ◾◾ EN 14593 ◾◾ EN 14594
Temperature range -30 °C to +120 °C Burst pressure ◾◾ minimum 40 bar ◾◾ safety factor 1:4
Connections quick disconnect CEJN breathing air couplings Assembly RX® FIXXED hose clamps or ferrules
Tube ◾◾ black EPDM rubber ◾◾ taste and odorless ◾◾ exceptional quality for breathing air systems ◾◾ smooth, homogeneous and seamlessly extruded
Comments The hose must be rinsed before use.
Reinforcement spiral-plied textile fabrics
Complete assembly ERIKS can assemble the RX® Breafixx Black with your required breathing air couplings.
Cover ◾◾ black EPDM rubber ◾◾ wear resistant ◾◾ electrically conductive 103 < R < 106 Ω
Options ◾◾ hydrostatic test report ◾◾ excellent laser engraving on marking ferrule
Table 1: RX® Breafixx Black I.D.
Wall thickness
Working pressure
Bending radius
Weight
Roll length
mm
mm
bar
mm
kg/m
m
9,5
4,5
10
50
0,28
40
Article no.
11259465
Technical data at 20 °C
18
