TWINTUBE & SIXTUBE DIMENSIONS Twin Tube™ Body Panel Mount Dimensions COUPLING INSERTS
PANEL NUT HEX
PANEL NUT THREAD
13/16
11/16-24UNEF
Sixtube™ Insert Panel Mount Dimensions .13"
1.27"
Ø .688"
Maximum Panel Thickness: 1/2" Minimum Panel Thickness: 0.02"
Panel Thickness: 1/8" Ø 1.20"
+.010 -.000
Twintube Coupling Bodies • ACETAL/ABS TERMINATION PANEL MOUNT HOSE BARB
TUBING SIZE METRIC EQ. 1/16" ID 1.6mm ID 1/8" ID 3.2mm ID
ACETAL ABS STRAIGHT THRU STRAIGHT THRU PTC16010 PTC16020 PTC1602096
ABS part shown
Twintube Coupling Inserts • ACETAL/ABS TERMINATION IN-LINE HOSE BARB
TUBING SIZE METRIC EQ. 1/16" ID 1.6mm ID 1/8" ID 3.2mm ID
ACETAL ABS STRAIGHT THRU STRAIGHT THRU PTC22010 PTC22020 PTC2202096
Acetal part shown
Sixtube Coupling Bodies • ACETAL/POLYPROPYLENE TUBING SIZE METRIC EQ. 1/16" ID 1.6mm ID 3.0mm ID 1/8" ID 3.2mm ID
ACETAL ABS POLYPROPYLENE STRAIGHT THRU SHUTOFF STRAIGHT THRU SXM1701 SXM170112 SXM17M3 SXM1702 SXM170212
WITH FEMALE FITTING BODIES
1/16" ID 1/8" ID
SXF1701 SXF17M3 SXF1702
WITHOUT FITTINGS
SX17
TERMINATION WITH MALE FITTING INSERTS
Acetal part shown
1.6mm ID 3.0mm ID 3.2mm ID
SXFD1701 SXFD17M3 SXFD1702
SXF170112 SXF170212
Sixtube Coupling Inserts • ACETAL/POLYPROPYLENE TUBING SIZE METRIC EQ. 1/16" ID 1.6mm ID 3.0mm ID 1/8" ID 3.2mm ID
ACETAL ABS POLYPROPYLENE STRAIGHT THRU SHUTOFF STRAIGHT THRU SXM4201 SXM420112 SXM42M3 SXM4202 SXM420212
WITH FEMALE FITTING BODIES
1/16" ID 1/8" ID
SXF4201 SXF42M3 SXF4202
WITHOUT FITTINGS
SX42
TERMINATION WITH MALE FITTING INSERTS
Acetal part shown
Accessories
1.6mm ID 3.0mm ID 3.2mm ID
DESCRIPTION SIXTUBE PRESSURE PLUGS
SXFD4201 SXFD42M3 SXFD4202
SXF420112 SXF420212
PART NO. TMPMWHT
