04
Devices raised mounting Selector switch actuator 2 positions, short lever
Essential Accessories: d Switching element page 51
M
IP 65 IP 65
MA M
Plastic grey Aluminium natural
Plastic black Plastic black
IP 65
MA
Aluminium natural
Plastic black
Circuit drawing
Selector switch actuator 2 positions, short lever Position A : Basic position Position B : Momentary action 42° Position C + B : Maintained action 90° Position A : Basic position Position B : Momentary action 42° Position C + B : Maintained action 90°
Lever Plastic black
Technical drawing
IP 65
Frontbezel/-ring Plastic grey
0
Mounting dimensions
Switching action
Front protection
Continuation see next page
e
5
11
37
0.034
704.410.0 704.413.0
5 5
11 11
38 37
0.034 0.037
704.411.0
5
11
38
0.037
b 30 x 30 mm Typ-Nr. 704.512.0
Ø 29 mm Typ-Nr. 704.412.0
704.510.0
Switching action: M = Momentary action, MA = Maintained action Mounting dimensions from page 91, Technical drawing from page 95, Circuit drawing from page 115
Selector switch actuator 2 positions, short lever, 12 o'clock
Essential Accessories: d Switching element page 51
Selector switch actuator 2 positions, short lever, 12 o'clock Position C + B : Maintained action 90°
MA
Frontbezel/-ring Plastic grey Aluminium black Aluminium natural
Lever Plastic black Plastic black Plastic black
b 30 x 30 mm Typ-Nr. 704.510.0.12
Ø 29 mm Typ-Nr. 704.410.0.12 704.411.0B.12 704.411.0.12
Circuit drawing
IP 65
0
Technical drawing
B
Switching action
C
Front protection
Maintain 90 °
Mounting dimensions
Continuation see next page
e
5 5 5
11 11 11
38 38 38
0.034 0.037 0.037
Switching action: MA = Maintained action Mounting dimensions from page 91, Technical drawing from page 95, Circuit drawing from page 115
27 07.2010
