Waterproof∙ 210 AFC
MONO-COMPONENT ACRYLIC-BASED FLEXIBLE WATERPROOF COATING PACKAGING
PRODUCT
Waterproof.210 AFC are packed in 15 kg plastic pails.
Waterproof.210 AFC is elasticized, acrylic, water-based, waterproof membrane. Waterproof.210 AFC is designed for under tile use in demanding internal & external waterproofing applications. Properly applied, Waterproof.210 AFC cures to form a durable, elastic, seamless odorless and impervious membrane that will not re-emulsify once it has fully cured even if continually immersed in water. It has a good resistance to alkalis, salt solutions & diluted acids, non hazardous composition with excellent strength & flexible characteristics.
STORAGE
Can be stored up to 6 months from manufacturing date, in original packaging, non open, protected from humidity, hot or freezing temperature.
SAFETY PRECAUTIONS
Avoid prolonged contact with skin. Wear protective gear for hands & eyes. Splashes on the skin should be washed away by cleaning with soap and water. In case of contact with eyes, wash thoroughly with clean water. If swallowed, do not induce vomiting. In both cases seek medical attention. The product is non-flammable.
SCOPE OF USE
Waterproof.210 AFC has been specifically designed for the long term waterproofing of wet areas inc. shower, bathrooms, laundries, exterior decks, terraces and balconies.
DISCLAIMER
While the company guarantees its products against defective materials, the use and application of these products are made without guarantee since the conditions of their application are beyond its control. It is recommended to verify with the company that the product is suitable for the intended use, and that this Data Sheet version is the latest one. The company may modify it without prior notice. Technical characteristics are listed for guidance only. For more information, please contact the company’s office in your location.
CHARACTERISTICS Paste Appearance Paste Density Ideal application temperature Pull off Strength @ 14 days ( ASTM D4541)
Pink 1.560 5 to 35°C 1.2 MPa
INSTRUCTIONS FOR USE
PREPARATION OF THE SUBSTRATE Substrates should be dry, smooth, sound and free from oil, grease, waxes, dust, laitance and all loose matter. Any surface defects should be repaired prior to application of membrane.
HIGH-THICKNESS NON-WOVEN GEOTEXTILE FOR SOIL STABILISATION CHARACTERISTICS / PERFORMANCES
PRODUCT
Geotextile.800 P is a nonwoven high performances geotextile consisting of a first choice polypropylene staples, produced by mechanical needling, without using any glues or chemical binders. This geotextile is produced in Western Europe. The porosity level of Geotextile.800 P is tailored to meet specific application requirements.
Please refer to the attached table. Over lapping: depends on the application and requirements from consultants on site.
PACKAGING
Delivered by roll of 3.9 m x 25m.
SCOPE OF USE
• • • • •
Road and railway soil stabilization, Waterways and seashore erosion control, Drainage systems, Waterproofing membrane protection, Landscaping…
PROPERTIES Unit weight Thickness MECHANICAL PROPERTIES Tensile strength resistance Elongation at max load
NOTE
Static puncture test (CBR test) Dynamic puncture test (cone drop test) HYDRAULIC PROPERTIES Velocity index
Edition: 11/07-A
Permeability coefficient In-plane flow capacity (MD) Opening size DURABILITY PROPERTIES Weathering resistance
The information included on this Technical Data Sheet is the sole property of SODAMCO Holding. The unauthorized disclosure, use, dissemination or copying (either whole or partial) of this data sheet or any information it contains, is prohibited and subject to legal pursuit.
PRODUCT APPLICATION Apply the 1st layer of Waterproof.210 AFC with sufficient thickness to plug pores, cracks, and holes. Allow to dry and apply the second layer. All corners, cracks or construction joints should receive 20 cm wide fiber Mesh reinforcement between the 1st and 2nd layer. Wherever tiling on Waterproof.210 AFC is required, it is recommended that the tiling must start 24 hours after the application of Waterproof.210 AFC.
Geotextile∙800 P
Oxydation resistance
STANDARD UNIT (EN ISO 9864) 2 kPa (EN ISO 9863-1) 20 kPa (EN ISO 9863-1) 200 kPa (EN ISO 9863-1) MD CMD MD CMD
(EN ISO 10319) (EN ISO 10319) (EN ISO 10319) (EN ISO 10319) (EN ISO 12236) (EN 918)
Tolerances
g / m² mm mm mm
A d d d
kN / m kN / m % % kN mm
(EN ISO 11058) mm / s m/s (EN ISO 11058) 10-3 m / s 20 kPa (EN ISO 12958) 10-6 m² / s (EN ISO 12956) microns
800 6.2 5.5 3.8
+/+/+/+/-
10% 20% 20% 20%
Tmax 50 Tmax 60 85 85 Fp 9 Dc 0
+/+/+
10% 10% 20% 20% 10% 20%
v-index 15 v-index 0.015 Kv qp 11.0 O90 70
+/-
30% 30% 30% 30% 30%
(EN 12224)
To be covered within 15 days from the day of installation Forecast minimum durability of 25 years for every application in in natural grounds with 4<pH<9 (EN ISO 13438) and soil temperature < 25°C
The values given are average obtained in our laboratories and in official testing institutes. They can change according to certain tolerances; further information are available contacting our Commercial Department. The tolerance is indicated according to the 95% confidence level. Tolerances in hydraulic properties also result from the variation of test results from internal and external laboratories. The right is reserved to make changes at any time without notice.
NOTE
The information included on this Technical Data Sheet is the sole property of SODAMCO Holding. The unauthorized disclosure, use, dissemination or copying (either whole or partial) of this data sheet or any information it contains, is prohibited and subject to legal pursuit.
CONSUMPTION
0.260 kg/m² over smooth substrate.
Edition: 11/07-A
