DRAWING
007
NOTES NO.
CODE NO.
CYLINDERS - PISTONS
DESCRIPTION
VALIDITY
Q.TY
1
121.2.033.1A
Piston rings set
1
2
884.4.011.1A
Piston pin circlip
4
3
121.1.127.1A
Piston pin
2
120.2.081.1AB Vertical cylinder-piston fit
1
4 5
791.2.026.3A
Head-cylinder gaskets set
1
6
786.1.086.1A
Cylinder-crankcase gasket th. 0.4
2
711.1.172.1A
Bush
7 8
120.2.080.1AB Horizontal cylinder-piston fit
DESCRIPTION
VALIDITY
Q.TY
2
122.2.154.1A
Complete piston
2
10
786.1.064.1A
Head-cylinder gasket
2
11
711.1.126.1A
Bush
4
12
700.1.040.1A
Vibration damper pad
41
915.1.262.1B 05 - 07
CODE NO.
1
9
