JACKS • MARINE JACKS | STABILIZER JACKS Pull Pin Swivel Marine Trailer Jacks Pull Pin swivel marine jacks typically bolt on to the trailer frame, providing a mount for the jack to pivot - down for jacking and stabilizing, and up for towing. • Bolt On Style fits frame sections up to 3” Wide x 5” Tall • Pull pin holds jack in position - pin is pulled to release jack for changing positions • Capacity: 800 - 2,500 -LBS • Typically side wind crank style • Usually zinc coated for extra corrosion resistance from salt water exposure • Held in up or down position by pin • Most common fixture is a caster or double casters • Usually 10” or 15” Lift
9
1
2
3
4
5
BOLT ON
6
7
10
• ZINC • 600 HOUR SALT SPRAY RATING PER ASTM B117
8
MEASUREMENT IN INCHES ITEM NO.
CAPACITY
A
B
C
LEG
1
7950515-TT
1,200
12.70
22.70
10.50
SWIVEL
2
7950266-TT
1,500
12.70
22.70
12.50
SWIVEL
3
7950518
1,500
12.70
22.70
10.50
SWIVEL
4
7950038
1,200
12.25
22.50
10.50
SWIVEL
5
7950084
1,500
13.00
23.00
12.40
SWIVEL
6
7950228
1,500
13.10
25.10
12.40
SWIVEL
7
7950235
1,200
9.30
24.30
19.50
FIXED
9
7950232
1,600
14.00
24.00
12.40
SWIVEL
10
7950231
1,600
14.00
24.00
12.40
SWIVEL-SINGLE
8
7950539
2,500
7.00
22.00
18.50
DROP LRG-DUAL
11
12
13
14
15
16
17
18
19
MARINE JACK REPLACEMENT PARTS
22 23
• ZINC
20
21 25
REF NO.
ITEM NO.
DESCRIPTION
11
7950243
REPLACEMENT WHEEL KIT FOR 7950515
12
7950578
REPLACEMENT WHEEL KIT FOR 7950232
13
7950366
REPLACEMENT WHEEL KIT FOR 7950231
14
7950248
PLUNGER ASSEMBLY 1/2”
15
7950635
REPLACEMENT CAP RAM
16
7950641
REPLACEMENT CAP XP10 FOR 7950038
17
7950642
REPLACEMENT CAP XP15 FOR 7950084/228
18
7950096
REPLACEMENT HANDLE RAM
19
7950344
REPLACEMENT HANDLE XP10 FOR 7950038
STABILIZER JACKS
24
INCHES
REF NO.
ITEM NO.
CAPACITY
A
DESCRIPTION
20
7950151
3,000
27.00
INCLUDES SLEEVE AND PIN
21
7950600
2,000
20.00
INCLUDES SLEEVE AND PIN
22
7950023-TT
1,000
17.00
RETRACTED HEIGHT 11.50”
23
7950098
-
-
24
7950801
5,000
24.00
CAPACITY PER PAIR
25
7950800
-
-
HANDLE FOR 7950801
JACKS • MARINE JACKS | STABILIZIER JACKS
REF NO.
HANDLE FOR 7950023-TT
F7 TexTrail Trailer Parts • 1.844.TexTrail • www.TexTrail.com
