Powerful hydraulics for tough jobs.
Hydraulic power you can rely on. That‘s because these days even a lower horsepower tractor has to handle a wide variety of jobs. With a pump capacity of 54 l / min and a separate hydraulic circuit for the steering, the Agrofarm‘s hydraulic system is a match for any requirement.
10
The Agrofarm is supplied with a mechanical or electronic lower link control. The electronic control is particularly efficient and offers application-specific advantages for all types of farms.
Advantages Mechanical or electronic lower link hydraulic hitch control
Remote valves for all demands The hydraulic system ensures practical implement use. Up to four precision-metered, double-acting remote valves can be supplied for the Agrofarm. They are controlled using three single levers + one electrohydraulic control for the 4th valve
Actuation of the PTO on both rear mudguards
Integrated front hitch with single or double action upon request
Independent electro-hydraulically operated PTO
Ground-speed PTO for special applications upon request
4 PTO speeds: 540 / 540 E / 1,000 / 1,000 E
External control of electronic lift on both the rear mudguards.
Easily accesible and clearly identified hydraulic connections. Up to four remote valves upon request.
Electronic rear lift controls.
The powerful rear linkage with 5,300 kg lift capacity for operating the heaviest implements (6,200 kg with additional lifting rams for 430 model).
and, depending on the version, also feature a flow rate control system. The oil flows to easily accessible hydraulic connections, which can be coupled under pressure and are equipped with oil spill collectors.
Electro-hydraulically operated PTOs All Agrofarm tractors come with a comprehensive PTO selection as standard. The following combinations are available: 540 / 1000 or 540 / 540 E / 1000 / 1000 E. The required speeds are preselected in the cab and activated electro-hydrauli-
Mechanical rear lift controls.
cally. To protect the implements and the transmission train, PTO start-up is softly modulated. DEUTZ-FAHR also offers a ground-speed PTO with a second PTO stubshaft for trailers with driven axles. The PTO can also be operated externally at the rear fender.
11
