PTO
KDM-HD-PTO DIMENSIONS
28"L x 9"W x 22"H, 225 lbs. (102 kg)
APPLICATIONS
• Drives rear mounted pumps • Driveline for foam, generator, and hydraulic systems • Pumper
FEATURES
• 21/2" shaft • Complete mounting kit and lock-on universal joint for front and rear shafts • Air shift • 1410 companion flange on output shaft • Opposite engine rotation - gear ratio: 0.93 to 1 thru 1.20 to 1 • Engine rotation - gear ratio: 1:62 to 1 thru 3.19 to1
OPTIONS
• Electric shift • Hydraulic drive flange • Parking brake
LDM-XHD-PTO - MAGNATRANS™
300 HP Split Shaft PTO, Torque Rating Up to 19,300 ft. lbs.
DIMENSIONS
30"L x 14"W x 27"H, 290 lbs. (132 kg)
APPLICATIONS
• Drives rear mounted pumps • Driveline for foam, generator, and hydraulic systems • Pumper
FEATURES
• 21/2" shaft • Complete mounting kit and lock-on universal joint for front and rear shafts • Air shift • 1410 companion flange on output shaft • Opposite engine rotation - Gear ratio: 0.93 to 1 thru 1.27 to 1 • Engine rotation - gear ratio: 1:34 to 1 thru 2.67 to1
OPTIONS
• Electric shift • Hydraulic drive flange • Parking brake
ZSM-XHD-PTO - MEGATRANS™
50
300 HP Split Shaft PTO, Torque Rating Up to 19,300 ft. lbs.
DIMENSIONS
16"W x 33"H x 25"D, 314 lbs. (143 kg)
APPLICATIONS
• Industrial • Pumper • Crash Truck • Fire Boat
FEATURES
• Rotation: Engine or opposite engine • 1610 or 1710 full round yokes standard • Air shift • Midship or split-shaft transmission
OPTIONS
• Electric shift • Belt-driven auto primer
1.800.323.0244 | www.darley.com
500 HP PTO, Torque Rating Up to 19,300 ft. lbs.
