34 HP Briggs & Stratton Vanguard -Diesel Also av ailable in 33 hp
Kubota
Dependable Briggs & Stratton Vanguard diesel engine 2-year engine, 3-year pump, Stainless steel shaft and bronze impeller
Features: 4 cycle, 3 cylinder, 34 HP Turbo Briggs & Stratton Vanguard diesel engine, with electric start, 6-gallon fuel tank, mechanical seal, water cooled, fly wheel alternator, fuel and oil pump filters, hose and adapter. Options: Dual remote controlled panels, adapters and caps, electric primer, spark arrest muffler, 6 gallon steel fuel tank, skid base. Other options available. 2-1/2AGE 34BS
Model 1-1/2AGE 34BS (Liquid-Cooled) 2-1/2AGE 34BS (Liquid-Cooled) HE 34BS (Liquid-Cooled)
Uses Performance Inlet Outlet Pressure 180 gpm @ 130 psi 2" NPT 2-11/2" NPT 130 gpm @ 200 psi 80 gpm @ 275 psi Pressure 300 gpm @ 85 psi 21/2" NPT 2-11/2" NPT and Volume 200 gpm @ 135 psi 1-21/2" NPT 50 gpm @ 215 psi Volume 500 gpm @ 30 psi Assembly #1 - 4" NPT 3" NPT 300 gpm @ 100 psi Assembly #2 - 4" NH 1-21/2" & 2-11/2"NPT 100 gpm @ 153 psi Assembly #3 - 4" NH 2-21/2" NH
Dimensions Length: 38" Width: 25" Height: 28" Length: 40" Width: 28" Height: 28" Length: 37" Width: 20" Height: 31"
Weight 370 lbs. (168 kg)
Price $12,860.00
380 lbs. (173 kg)
$13,930.00
490 lbs. Assembly #1 - $13,600.00 (222 kg) Assembly #2 - $14,210.00 Assembly #3 - $14,760.00
HSE 250 Kubota
PUMPS
Meets 250 gpm @ 150 psi for type 3 structure engines Can also meet 150 gpm @ 250 psi for wildland engines
Features: 59HP turbo diesel engine, stainless steel shaft, aluminum alloy gear case & engine adapter, heat treated alloy steel helical gears, diesel, 4 cycle, liquid cooled, mounted control panel, mechanical seal Options: Dual panels with electronic throttles, relief valve with pilot light, both 12V and 24V fluidless primers are available.
Model HSE 250 Kubota
304
Performance 360 gpm @ 150 psi 250 gpm @ 200 psi 175 gpm @ 255 psi 125 gpm @ 294 psi
1.800.323.0244 | www.edarley.com/pumps
Inlet 4" NH
Outlet 3" NPT
Dimensions Length: 50" Width: 23" Height: 47"
Weight 800 lbs. (363 kg)
Price $17,550.00
