Gated Wye Valves WILDLAND
Rugged lightweight wye valves divide one line into two; female inlet with two male outlets. Constructed of high-quality aluminum and plastic with hard-coated threads. Valves are quarter turn. Meet or exceed GSA requirements for use by the US Forest Service. Ship. wt. 4 lbs.
Specify any thread combination: NST or NPSH AM076 Gated Wye, 1" Inlet x 2-1" Outlets AM077 Gated Wye, 11/2" Inlet x 2-1" Outlets AM075 Gated Wye, 11/2" Inlet x 2-11/2" Outlets AM078 Gated Wye, 21/2" x 2-11/2" Outlets
Wildland 2-Way Ball Valves These valves are made primarily of aluminum alloy in a heat-treated, fire engine red finish. The other major components are made of stainless steel and galvanized brass. Some of the major characteristics of these ball valves include: anti-freezing assembly, the visual indicators for "open" and "close", friction loss reduced by up to three times, light weight and smaller design. BC030 BC031 BC032 BC033
1.5" FNST Inlet x (2) 1" MNST Outlet Short Handle 1.5" FNST Inlet x (2) 1.5" MNST Outlet Short Handle 1.5" FNPSH Inlet x (2) 1" MNPSH Outlet Short Handle 1.5" FNPSH Inlet x (2) 1.5" MNPSH Outlet Short Handle
1" Self-Educting Forestry Nozzle Heavy-duty Pyrolite construction Self-Educting for ease of use with agent application Dual shutoff for better performance: Bail shutoff to stop the water flow, twist shutoff to allow back-flush Eductor back-flush for easy cleaning of agents out of the eductor Check valve in eductor to prevents water from entering the agent Static mixer in throat for better gel mixing for better performance Variable pattern control for straight stream to fog pattern 15 gpm at 100 psi: Ideal setting for gel applications BG536
1" Self-Educting Forestry Nozzle
Hose Clamp Made from high-quality cast aluminum and brass. Off-set handle allows the user to more easily operate while wearing gloves. Designed to be used with today’s lightweight single jacket wildland 1" and 11/2" fire hose. When clamped on the hose, it locks securely and safely in the closed position. Ship. wt. 2 lbs.
Hose Clamp
10-24 gpm
Designed to be installed at intervals in long lines to provide independently controlled outlets for 1" branch lines with full 1/2" waterway. When used in fire-line sprinkler systems, these valves provide the ability to adjust water flow to each sprinkler in the line. Valuable for mop-up work and for filling canteens and backpumps. Meets U.S. Forest Service specifications. 11/2" NH x 1" NH. Ship. wt. 2 lbs. AJ478
AM096
Wildland Nozzle Dual Gallonage
Water Thief In-Line Tee Valve
Water Thief In-Line Tee Valve
BC034 BC035 BC036
1" FNST Inlet Tip 3 /4" FGHT Inlet Tip 1" FNPSH Inlet Tip
